MENEGOTTI TECHNICAL MANUAL
CONCRETE MIXER
PROFESSIONAL 11 CuFt
PROFESSIONAL 7 CuFt
QR-Code:
Point your mobile phone camera to
access Technical Manuals and Parts
Catalogs online.
www.sites.google.com/view/menegotti-engenharia-docs
Attention:
Before operate Menegotti equipament,
read this technical manual, itself will inform and
instruct the operator about the operation.
By the way, you avoid possible working accidents
and early maintenance on at the equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROFESSIONAL 11 CuFt and is the answer not in the manual?

Questions and answers

Related Manuals for MENEGOTTI PROFESSIONAL 11 CuFt

Summary of Contents for MENEGOTTI PROFESSIONAL 11 CuFt

  • Page 1 MENEGOTTI TECHNICAL MANUAL CONCRETE MIXER PROFESSIONAL 11 CuFt PROFESSIONAL 7 CuFt QR-Code: Point your mobile phone camera to access Technical Manuals and Parts Catalogs online. www.sites.google.com/view/menegotti-engenharia-docs Attention: Before operate Menegotti equipament, read this technical manual, itself will inform and instruct the operator about the operation.
  • Page 2 Welcome, you are part of the huge Menego� “customers familiy”. Product Warranty Term of Warranty A�er sales Departament and Technical Assistance MENEGOTTI. A�en�on: For be�er comodity, store and keep this manual in a properly spot so it can be easily checked.
  • Page 3 • Before using this equipment, carefully read this manual and follow the Manufacturer`s instructions, such as how to reduce the risk of accidents in operation. • It is expressly prohibited to remove or alter any safety device or characteristic, should this occur MENEGOTTI will not be held responsible. • Use the equipment according to the instructions in this manual.

  • Page 4: Specifications

    • Avoid contact with hot surfaces. • Before performing any activity or maintenance, first let the engine cool down. • Avoid contact with rotating parts. Technical Specifica�ons SPECIFICATIONS PROFESSIONAL 11 CuFt PROFESSIONAL 7 CuFt Total Drum Volume 14 Cu Ft 9 Cu Ft...

  • Page 5: Main Parts

    CONCRETE MIXER Main Parts Extension electric 0 a 20m 20 a 30m above de 30m Diameter of the electric wire 4,0 mm² 6,0 mm² not recommended Equipment supplied without Electric Engine The engine installa�on, electrical appliances and their installa�ons and grounding must be made in accordance with current standards in the POS.
  • Page 6 Opera�on Condi�ons Earthing the Equipment • Concrete mixers can be used in both indoor and outdoor environments; • Correct earthing of the concrete mixer is vitally important in reducing • When filling a concrete mixer with a spade, do not place the spade inside the risk of electrical shocks;...
  • Page 7 Equipment Lubrica�on Transport, Li�ing and Storage • Keep machine rota�ng parts lubricated, such as: pinion, rack gear, • It has yoke just to raise a few cen�meters of soil and carry through the bushings, and bearings; movement of the wheels; •...

  • Page 8: Wiring Diagram

    Wiring Diagram Eletric Engine 220/380V Ground point exis�ng machine. 3P + T Ground point Eletric Engine 110/220V exis�ng machine. 2P + T...
  • Page 9 Equipment Opera�on • Posi�on the mixer on a flat, firm surface, so that facilitates the process of loading and unloading; • Turn the switch that is a�ached to the engine enclosure; • �l�ng the drum to the desired angle. This movement should be done by turning the steering wheel and at the same �me stepping on the pedal, unlocking the swivel rocker;...

  • Page 10: Equipment Maintenance

    Assembly Procedures Equipment Maintenance Check List Rack Gear Replacement Check list - Concrete mixer Check list - Concrete mixer Cha s s i Motor s upport Cha s s i motor s upport Pul l ey • Remove the damaged rack gear screws (07), and replace them Wheel rubber s ol i d Top cover according to assembly recommenda�ons;...
  • Page 11 2) Assemble the chassi motor support (1) on lower column (2), fasten with 4) Posi�on the steel yoke (1) in 30° angle. Place the drum (2) on the steel the hexagonal bolt 3/8’’x 1’’ (3). Then, fasten the lower guide (4) and larger yoke (1) and �ghtening the hexagonal bolt 7/8’’x2.1/4’’...

  • Page 12: Warranty

    6) Fit pulley (1) on the pinion sha� (2), securing with retaining ring E-20 (3) and key 6x6x30. Characteris�cs 7) Complete assembly. CONCRETE MIXER PROFESSIONAL 11 CuFt PROFESSIONAL 7 CuFt DIFFERENTIAL PAINTING BLUE BLUE DRUMS BODY THICKNESS 2,65 mm THICKNESS 2,65 mm...

  • Page 13: Parts List

    Parts List POS. DESCRIPTION QTY. CODE DRAWING Motor Box 7/11 CuFt Bea m Rubber 24030221 4122071 Stop Rubber 24030222 4122072 Fl a t Wa s her 5/16” 21030252 Hex. Bol t 5/16”X3/4” 21010268 Spri ng Wa s her 5/16” 21030112 Hex Nut 5/16”...
  • Page 14 Steel Yoke 11 CuFt POS. DESCRIPTION QTY. CODE DRAWING Fl a t Wa s her DN26 30100079 4122006 Bea ri ng 30210 22020608 Bea ri ng 30209 22020607 Co�er Pi n 3/16”X1.1/2" 21050106 Steel Yoke 400L Profes s i ona l 32460056 3106047 Steel Yoke 400L Renta l 32460057 3106049...
  • Page 15 Drum 11 CuFt POS. DESCRIPTION QTY. CODE DRAWING Drum 400L Profes s i ona l 34600034 2107002 Drum 400L Renta l 34600038 2107004 Segmented Crown Ra ck Gea r 31180004 2124011 Hex Bol t 3/8”X2” 21010241 Fl a t Wa s her 3/8” 21030230 Hex Nut 3/8”...
  • Page 16 Rack Gear Protec�on 11 CuFt POS. DESCRIPTION QTY. CODE DRAWING Screw M5x25mm 21011022 Hex Bol t M6x16mm 21012986 Hex Nut M6 21021208 Hex Nut 1/4" 21021004 Fl a t Wa s her 1/4" 21030214 Hex Bol t 1/4“X4” 21010184 Ri ght - Ra ck Gea r Protec� on 24110200 3119146 Le�...
  • Page 17 Chassi 11 CuFt...
  • Page 18 POS. DESCRIPTION QTY. CODE DRAWING POS. DESCRIPTION QTY. CODE DRAWING Cha s s i 400L Profes s i ona l 2105084 La rger Gui de 600mm 32180016 3112011 Bea ri ng s upport 31140055 3116001 Motor Suport X 400mm 32060144 3112013 Grea s e Fi �...
  • Page 19 Steel Yoke 7 CuFt POS. DESCRIPTION QTY. CODE DRAWING Fl a t Wa s her DN48 21030803 4.122.106 Bea ri ng 30208 22020606 Bea ri ng 30207 22020605 Co�er Pi n 3/16”X1.1/2" 21050106 Steel Yoke 250 Profes s i ona l 32460018 2.106.067 Centra l Axi s 31020348 3.114.019...
  • Page 20 Drum 7 CuFt POS. DESCRIPTION QTY. CODE DRAWING Drum 250 Profes s i ona l 34600053 3.107.023 Segmented Crown Ra ck Gea r 31180116 2.124.024 Hex Bol t 3/8”X2” 21013820 Fl a t Wa s her 3/8” 21030230 Hex Nut 3/8” 21021059 Drum Wa s her 30100070 4.107.003...
  • Page 21 Chassi 7 CuFt...
  • Page 22 POS. DESCRIPTION QTY. CODE DRAWING POS. DESCRIPTION QTY. CODE DRAWING Cha s s i 250 Profes s i ona l 3105044 Hex Bol t 3/8" X 2" 21010241 Bea ri ng s upport 31140055 3116001 Hex Bol t 5/16”X2” 21010228 Grea s e Fi �...
  • Page 23 This warranty replaces any other warranty, implicit or explicit, as well as all any obliga�on or responsibility on the part of our company in rela�on to Customer: the above men�oned product. Model: Serial Number: City: Date: MENEGOTTI Post Sales Department and Technical Assistance. Customer Menegotti Authorized Service...
  • Page 24 Solid values, sustainable future. Unit • Unidad Menmaq Unit • Unidad Mentec Unit • Unidad Menfer Unit • Unidad MNA United States...
