TIS TITAN TIT-TFT-BUS-K Installation Manual

INSTALLATION MANUAL
TIS TITAN / TITANIA SERIES
2.4" Touch Switch
Model: TIT-TFT-BUS-k (3R), TIT-TFT-BUS-S-(3R)
BARCODE (UPC-A) BARCODE (UPC-A)
6 58921 79984 0 6 58921
Size
Resolution
LCD
Contrast
Viewing direction
Active area
Touch
Touch type
Temp sensor
Input
Dry inputs
Output
Model with relay -3R
Number of devices on 1 line
TIS Bus``
Bus voltage
Current consumption
Protection
Data and digital inputs
Connection terminal
Relay channels
LCD
Touch buttons
Operation
Backlit
TIS bus
Upgrading
1 Press
Functions
Long press
Double click
Dimensions Titan with the cover
(Width × Length × Height)
Titania with the cover
Materials
Casing color
Housing
Internal Parts color
IP rating
79982 6
PRODUCT INFORMATION
This product is a wall switch with touch LCD
and buttons designed for lights, climate, music,
security, and motorized curtains control. It offers
customizable backlit color and frame covers for an
easy combination with interior schemes.
P R O D U C T S P E C I F I C AT I O N S
2.4"
240*320 Pixels
600
120 degree
2.5"
Capacitive
Resistive temp sensor
2 Digital inputs
3 Relay outputs 5A
Max. 64
12-32 V DC
<60 mA / 24 V DC
Reverse polarity protection
ESD Protection
6 pushing pin type 1.5mm
4 pushing pin type 2.5 mm
TFT full color
2 touch buttons for menu selection
2 LED indicators
TIS protocol messages & commands
Rs485 upgrade kit
ON/OFF/Scene
Adjust lights brightness
Extra scene
29mm × 90mm × 86mm
29mm × 66mm × 110mm
Fireproof PC / Glass in front
Aluminum, glass, or plastic frame
Black
IP 50
