TIS -AVIP-MTX44 Installation Manual

INSTALLATION MANUAL
AV MATRIX 4X4
Model: TIS-AVIP-MTX44
Output
TIS Bus``
Protection
Operating and display
elements
Functions
Dimensions
Housing
BARCODE (UPC-A)
6 58921 79879 9
P R O D U C T S P E C I F I C AT I O N S
Operating Temperature Range
Storage Temperature Range
Operating Humidity Range
Bus voltage
Current consumption
Input Video Signal
Input DDC Signal
Bandwidth
Video Format Supported
HDCP Compliant
Output Video
Audio Format Supported
Maximum Transmission Distance
Power Consumption
Dimensions
Mass (Main Unit)
PRODUCT INFORMATION
This device is a professional 4-input, 4-output
HDMI matrix helping with streaming shared
media from different devices. It enables switching,
controlling and managing options through remote
control, computer, or your smart touch-panel.
Using this audio splitter, you can take control of
multiple digital and analog HDMI AV signals from
one location.
-5 to +40°C(23 to +104 °F)
-10 to +60°C(-14 to +140 °F)
5 to 90 % RH (no condensation)
12-32 V DC
<25 mA / 24 V DC
0.5-1.0 volts p-p
5 volts p-p (TTL)
18Gbit/s
4K@60Hz,YUV4:4:4
4k@30Hz/1080P/1080i/720P/576P/480P/576i/480i
HDCP2.2 and HDCP1.4
HDMI2.0 and HDMI 1.4
PCM, Dolby5.1, DTS5.1 digital audio
1080P 90m, 4K 70m
68 watts (Max.)
L438 x W394 x H44 mm
3 KG
