- Page 1 MANUAL AND INSTRUCTION WESTBO ANKARSRUM Westbo of Sweden...
-
Page 2: General Information
Before setting it up, check whether the load-bearing capacity of the substructure can withstand the weight of your Westbo kitchen stove (e.g. plate for load distribution) to reach it.) The Ankarsrum weighs 130 kg and can be placed on the floor without any additional reinforcements. Westbo of Sweden... -
Page 3: Unpacking And Checking
In the event of damage in transit, please report it to the freight forwarder or your dealer. Connection The Ankarsrum kitchen stove can be connected upwards or connected to the rear. If a chimney breakthrough is necessary, be sure to seek professional help. There is a risk that the chim- ney could be damaged if installed improperly. - Page 4 Westbo Ankarsrum Instructions for construction Adjustment screws 85-95 cm adjustable socket Connection to the top Loosen the oval closure at the top and use it to close the outlet at the back. Seal well. Use the adapter (from oval to round) to connect the stove to the top.
- Page 5 Westbo Ankarsrum Instructions for construction Winter - Summer Presets The position of the smoke deflection plate can be changed, see picture. In the winter setting (W), the flue gas path is longer and the stove emits more heat into the room. To change the setting, you need to remove the stovetop.
- Page 6 As a result, the stove loses its approval. Operation of several fireplaces The Ankarsrum stove corresponds to the conventional design 1 (multiple occupancy). Thus, several devices can be connected to one chimney. When operating several fireplaces in one installation room or in an air network, sufficient combustion air supply must be ensured.
- Page 7 Westbo Ankarsrum Notes Note in case of chimney fire In the event of a chimney fire, close all air intakes on the stove and inform the fire brigade. After the chimney has burned out, have it checked by a specialist for cracks or leaks.
- Page 8 Westbo Ankarsrum Heating, Maintenance, Warranty Do not leave the stove unattended during this burning phase. For the first operation, please insert a maximum of two small logs and use fixed fireplace lighters if necessary. During commissioning, odours may form, as the paint must first dry out.
- Page 9 During the warranty period, your specialist dealer is responsible for all warranty services. Any goodwill requests can be made through your specialist dealer. No legal claim arises from goodwill granted. We thank you for your trust and wish you pleasant hours at your new stove. Westbo of Sweden, Reftele Westbo of Sweden...
-
Page 10: Useful Tips
Westbo Ankarsrum Useful Tips Disturbance Through? Solution: Oven smells First start-up, furnace paint dries Fire does not burn Deduction bad Open air damper Smoke Bad weather conditions Burn the newspaper and thus preheat the chimney Fire pane sooty Insufficient wood quality... -
Page 11: Dimensions And Technical Data
Westbo Ankarsrum Dimensions and technical data View from the front You can find more information about lighting and heating with the Westbo Standard/Ornament on the pages Specifications DIN/EN-12815 approved 15a B-VG DINplus/2. BImSchV fulfilled Nominal Heat 8,0 kW Efficiency 75,2 %... - Page 12 Westbo Ankarsrum Dimensions combustible wall Brännbar vägg fireproof wall Brandvägg combustible wall 500 mm brännbar vägg Bottom plate Eldstadsplan 500 mm Westbo of Sweden AB Industrigatan 8, 333 75 Reftele/ Sweden, info@westbo.net, www.westbo.net Issue 24-01...
