FITTING INSTRUCTION
WESTBO WeRa
Westbo of Sweden

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WeRa and is the answer not in the manual?

Questions and answers

Related Manuals for Westbo WeRa

Summary of Contents for Westbo WeRa

  • Page 1 FITTING INSTRUCTION WESTBO WeRa Westbo of Sweden...

  • Page 2: General Instructions

    Westbo WeRa General instructions Building notification Please read this brochure carefully and the chimney Before installation of the fireplace and construction of a suppliers instructions before starting assembly. chimney, it is a demand to do a building notification. For piece of advise, contact your local authorities.
  • Page 3 Westbo WeRa Fitting instruction Legs and Chamotte bricks must be mounted in the firebox. Use mounting option one or two. Includning: 4 Legs and screws 6 Chamotte bricks 1 Air box 1 Handle 1 Smoke pipe 125 mm in diameter Chamotte bricks Combined with the stove there are six Chamotte bricks.
  • Page 4 Westbo WeRa Fire advise Safety First fire Westbo WeRa is tested according to the DIN standard DIN We advise you to use ignition pads or equivalent. With 13240. the help of these, there will be a quick over ignition of the The stove is room air dependent, i.e., the combustion air is...
  • Page 5 Westbo WeRa Wood handling Preparation We recommend a diameter of 6-10 centimetre and that the wood logs are 6 centimetre shorter than the fireplace. This will help the air to circulate in the best possible way. If the diameter is bigger, the wood logs must be splitted. Wood logs that are splitted will dry better.

  • Page 6: Technical Data

    Westbo WeRa Technical data Technical data Weight 150 kg Height 69 cm Width 43,5 cm Deep 59 cm Cooking plate 270 mm diameter Smoke channel 125 mm diameter Material Cast iron Medium power 7,0 kW Efficency Distance to combustable wall/side...

  • Page 7: Eu-Declaration

    EU-declaration Westbo WeRa...

  • Page 8: Warranty

    Westbo WeRa Guarantee WARRANTY Westbo of Sweden has a 10 year stove casting warranty and a 1 year warranty concerning natural wear and tear of articles of consumption such as firebricks, vermiculite, grates, glass, handles and rope seal. The warranty is only valid if the stove has been used in a proper way...
