S-5188, S-9924
CORRUGATED
BALLOT BOX
1.
Fold the bottom flaps in following the numbers 1-4.
(See Figure 1) After folding flap 4, allow all flaps to
spring back into locked position.
2. Stand the box upright and fold in the top side flaps.
Close the lid. (See Figure 2)
3
Figure 1
PAGE 1 OF 3
1-800-295-5510
uline.com
4
2
1
ASSEMBLY
3. Fold the locking tab into corresponding slot.
(See Figure 2, Inset A)
4. If optional header is used, insert the header into
appropriate slots. (See Figure 3)
Figure 2
Para Español, vea página 2.
Pour le français, consulter la page 3.
Inset A
Figure 3
0321 IS-5188
Advertisement
Related Manuals for U-Line S-5188
Summary of Contents for U-Line S-5188
- Page 1 Para Español, vea página 2. Pour le français, consulter la page 3. S-5188, S-9924 1-800-295-5510 uline.com CORRUGATED BALLOT BOX ASSEMBLY Fold the bottom flaps in following the numbers 1-4. 3. Fold the locking tab into corresponding slot. (See Figure 1) After folding flap 4, allow all flaps to (See Figure 2, Inset A) spring back into locked position.
- Page 2 S-5188, S-9924 800-295-5510 uline.mx URNAS DE CORRUGADO ENSAMBLE Doble las solapas en forma secuencial del 1 al 4. 3. Inserte la lengüeta de bloqueo en la abertura (Vea Diagrama 1) Después de doblar la solapa 4, correspondiente. (Vea Diagrama 2, Anexo A) permita que todas las solapas regresen a la posición...
- Page 3 S-5188, S-9924 1-800-295-5510 uline.ca URNE DE CARTON ONDULÉ MONTAGE Repliez les rabats de fond en suivant l'ordre des 3. Pliez la languette de fermeture de sorte qu'elle numéros 1-4. (Voir Figure 1) Après avoir plié le s'insère dans la fente correspondante.
