Transceiver Solutions 380 MHz to 6 GHz S9108A-001 S9108A-002/003/006 Describes the Keysight S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions which are streamlined, non-signaling measurement systems that enable automated testing of 5G New Radio (5G NR) infrastructure equipment: •...
3. 2. 1 Connectors, 10 MHz Ref In/Out on the Rugged Front Panel 3. 2. 2 Connectors, Trig 1 and Trig 2 on the Rugged Front Panel 3. 2. 3 Connectors, S9108A-001, -002, -003 and -006 on the Rugged Front Panel 26 3. 2. 4 Connectors, M9038A PXIe Embedded Controller 3.
5G New Radio (5G NR) infrastructure equipment. The figure below shows the block diagram of the S9108A-001, S9108A-002, S9108A- 003, and S9108A-006 5G FR1 multi-port solution with Blocker. These systems provide a Main VXT for generating the wanted signal and a blocker VXT for generating the interfering signal for testing the receiver of a base station.
Page 6
This document describes the installation process to start up and prepare the Keysight S9108A-001, -002, -003, and -006 5G FR1 Multi-port Transceiver Solutions. 1. Review this Overview Review Safety Requirements on page 7 Review Hardware on page 23 Install Hardware on page 31 Install Software on page 35 Verify Operation MIMO on page 47 S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
Do not proceed beyond a WARNING notice until the indicated conditions are fully understood and met. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
Canada: CSA C22.2 No. 61010-1 USA: UL std no. 61010-1 2. 2. 2 Acoustic Statement (European Machinery Directive) Acoustic noise emission LpA <70 dB Operator position Normal operation mode per ISO 7779 S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
Page 9
AC Mains because it serves as a ground and helps protect the chassis and modules from electrostatic damage. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
Depth: 568.9 mm (22.4 in); with rugged panel Weight: 24 kg (53 lbs); maximum (option dependent) 2. 4 Handling and Lifting Use both side handles when lifting the S9108A Base System. Use a rolling cart when transporting the S9108A Base System. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
2 Review Safety Requirements 2. 5 Cleaning Clean the outside of Keysight products with a soft, lint-free, slightly dampened cloth. Do not use detergent or chemical solvents. To prevent electrical shock, disconnect from Mains before cleaning. Use a dry cloth or one slightly dampened with water to clean the external case parts.
Transceiver Solutions are designed for use in the following conditions: For indoor use only Altitude up to 6,561.68 ft (2,000 m) Operating Temperature 10 to 40° C, Maximum Relative Humidity (non-condensing): 85% RH S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
10°C from the lowest, of the maximum operating temperature of a single instrument. If there are any concerns or special requirements, a Keysight Field Engineer should be consulted to assure instrument(s) temperature compliance and performance.
Consider ergonomics when locating any keyboard or mouse which will be used in connection with an instrument. Install the Keysight S9108A-001, -002, -003, and -006 5G FR1 Multi-port Transceiver Solutions so that the detachable power cords are readily identifiable and is easily reached by the operator. The detachable power cord is the disconnecting device.
This instrument has auto-ranging line voltage input. Before switching on the instrument, be sure the supply voltage is within the specified range and voltage fluctuations do not exceed 10 percent of the nominal supply voltage. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
Page 16
2. 9. 4 Do Not Use Extension Cords DO NOT use extension cords to power your equipment. 2. 9. 5 Do Not Use Converters or Adapters DO NOT use any converters or adapters. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
Page 17
2. 9. 7 Avoid Loose Connection DO NOT use outlet if the power cord makes a loose connection. 2. 9. 8 Make Proper Connection DO NOT allow plug to bend down or become loose. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
002, -003, and -006 5G FR1 Multi-port Transceiver Solutions cabinet when connected to an appropriate power line outlet. Use the Keysight supplied power cord or one with the same or better electrical rating. The cable appropriate to the original shipping location is included with the Keysight S9108A-001, -002, -003, and -006 5G FR1 Multi-port Transceiver Solutions.
Shipping Materials and ESD Keysight’s chassis and instrument modules are shipped in materials which prevent static electricity damage. These instruments should only be removed from the packaging in an anti-static area, ensuring that correct anti-static precautions are taken.
2 Review Safety Requirements 2. 12 Front and Rear Panel Symbols Symbols that may be on the exterior of S9108A-001, S9108A-002, S9108A-003, and S9108A-006 hardware components are: Symbol Description This symbol is used to indicate power ON and to mark the position of the instrument power line switch.
Page 21
GB 18455-2001 as required by the China RoHS regulations for paper/fiberboard packaging. The CSA mark is a registered trademark of the CSA International. This symbol indicates that anti-static precautions should be taken. This symbol indicates earth ground. This mark designates Direct Current. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
Should it become necessary to return the system for repair or service, follow these steps: 1. Review the warranty information shipped with the product. 2. Contact Keysight to obtain a Return Material Authorization (RMA) and a return address. For assistance finding Keysight contact information, go to: www.keysight.com/find/assist...
Before installing hardware or software, review the following hardware components: Hardware Components on page 24 Connector Descriptions on page 25 Connectors, 10 MHz Ref In/Out on the Rugged Front Panel on page 25 Connectors, S9108A-001, -002, -003 and -006 on the Rugged Front Panel on page 26 Connectors, M9038A PXIe Embedded Controller on page 27 Connectors, S9108A-001, -002, -003, and -006 on the PXIe Chassis Rear Panel on page 28 S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
The S9108A is available in four standard configurations. Keysight S9108A-001 5G FR1 Multi-port Transceiver includes: one PXIe chassis one M9411A PXIe VXT Vector Transceivers) The S9108A-001 system contains 300 MHz bandwidth, 8 ports for connecting DUT, operating in FR1 RF frequencies ranging from 380 MHz to 6 GHz. Keysight S9108A-002 5G FR1 Multi-port Transceiver includes: one PXIe chassis one M9410A PXIe VXT Vector Transceiver)
The 10 MHz Ref In connector frequency range, on S910xA systems, is different from the M9300A PXIe Frequency Reference Data Sheet. The S910xA systems only support 10 MHz or 100 MHz inputs. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
3 Review Hardware 3. 2. 3 Connectors, S9108A-001, -002, -003 and -006 on the Rugged Front Panel TRX1/TRX2 RF I/O Connector Type-N (f), 50 Ω, nominal Frequency Range 380 MHz to 6 GHz Amplitude 30 VDC, +33 dBm Maximum Safe Input Power HD Port...
GPIB Connector GPIB (Micro-D 25-pin) PCIe Connector x8 Gen 3 PCIe IPASS connector for controlling a second PXIe or AXIe chassis or RAID storage See the Data Sheet for the Keysight M9038A. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
3 Review Hardware 3. 2. 5 Connectors, S9108A-001, -002, -003, and -006 on the PXIe Chassis Rear Panel AC Line Input (Use the AC line cord supplied with the S9108A.) Connector, Three- 100-120 V, 50/60 Hz, Prong 1200 W MAX (Lower range) 220-240 V, 50/60 Hz,...
Page 29
System Timing Module. To provide a 10 MHz Clock to the S9108A, Connectors, 10 MHz Ref In/Out on the Rugged Front Panel on page 25. For additional information, see the Data Sheet for the Keysight M9019A, 5992-1481EN. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
M9410A transceiver as a blocker solution, operating in the FR1 RF frequency ranging from 380 MHz to 6 GHz with 600 MHz bandwidth. This system can be configured for 2x2 MIMO measurements in the FR1 RF frequency range. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
one 5063-1530 RF Cable, SMA (m) to SMA (m), 152.4 mm (6.0 one 1250-1250 Adapter, SMA (f) to Type-N (m) Remove this loop-back cable from all RF I/O ports during normal use. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
3. Connect a Display, Keyboard & Mouse (Not included with S9108A). 4. 2. 2 Connect AC Power Cords & Power On Equipment Power on the S9108A AC Power Switch, located on the right front panel. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
5 Install Software 5 Install Software Each S9108A-001, S9108A-002, and S9108A-006 standard configuration includes an M9038A PXIe Embedded Controller; all required software comes pre-installed. Proceed to Verify Operation. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
S9108A Base System; they both power on and initialize automatically when the S9108A Base System is powered on. Verify X-Apps Controls of TRX 1 RF Ports at 3 GHz on page 38 Verify X-Apps Controls of TRX 2 RF Ports at 3 GHz on page 41 S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
6. 1 Verify X-Apps Software Controls an S9108A This process must be repeated for each M9410A/M9411A PXIe VXT Vector Transceiver and its selected X-Apps software pair in the system; the S9108A-001 5G FR1 Multi port Transceiver contains one M9411A PXIe VXT that are labelled on the Rugged Front Panel as Transceiver 1; the S9108A-002/003/006 5G FR1 Multi-port Transceiver contains one M9411A PXIe VXT and one M9410A PXIe VXT that are...
Page 39
Each Mode runs within a screen (there can be multiple screens). Screens are shown as tabs across the top of the interface. IQ Analyzer Mode is included with the S9108A-001 and appears as a tab with the label IQ Analyzer 1.
Page 40
Select Input/Output from the drop-down menu panel (top-right corner), select RF Source tab, select RF Output Port drop-down menu, and select RF Output. b. Set RF Power to –10 dBm, Frequency to 3 GHz, and RF Output to On. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
RF Transceiver .380 - 6 GHz, HD ➀ RF I/O #3 ➁ of the S9108A-001 are working properly. (The power level is only approximate because there is loss in the cable being used and this loss is not being corrected during the measurement.) 6.
Page 42
Screens are shown as tabs across the top of the interface. IQ Analyzer Mode is included with the S9108A. and appears as a tab with the label IQ Analyzer 1. 3. Select the IQ Analyzer 1 drop-down selector. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
Page 43
4. Set the Mode / Measurement / View for IQ Analyzer 1: a. Select Mode as IQ Analyzer (Basic). b. Select Measurement as Complex Spectrum. c. Select View as Normal. d. Select OK. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
Page 44
Select Input/Output from the drop-down menu panel (top-right corner), select RF Source tab, select RF Output Port drop-down menu, and select RF Output. b. Set RF Power to –10 dBm, Frequency to 3 GHz, and RF Output to On. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
Page 45
S9108A TRX 2 are working properly. (The power level is only approximate because there is loss in the cable being used and this loss is not being corrected during the measurement.) S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
To set up and run MIMO on the , S9108A-003, or the S9108A-006. Refer to the Keysight MIMO Measurement Guide, M9410-90016 for the Keysight M9410A/M9411A VXT PXIe Vector Transceiver For DUT IF MIMO measurements, select the DUT IF ports. S9108A-001, -002, -003 and -006 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
Page 48
Is your product software up-to-date? Periodically, Keysight releases software updates to fix known defects and incorporate product enhancements. To search for software updates for your product, go to the Keysight Technical Support website at: www.keysight.com/find/techsupport Contacting Keysight Assistance with test and measurements and information on finding a local Keysight office are available at: www.keysight.com/find/assist...
