  • Page 1 M1742A Transceiver 10 - 32 GHz GETTING STARTED GUIDE...
  • Page 2 Notices CONTAINED HEREIN. SHOULD commercial computer software KEYSIGHT AND THE USER HAVE A documentation. No additional SEPARATE WRITTEN AGREEMENT government requirements beyond © Keysight Technologies, Inc. 2023 WITH WARRANTY TERMS those set forth in the EULA shall No part of this manual may be...
  • Page 3 Documentation is updated periodically. For the latest information about this instrument, including firmware upgrades, application information, and product information, click the website link below. http://www.keysight.com/find/m1742a To receive the latest updates by email, subscribe to Keysight Email Updates at the following URL: http://www.keysight.com/find/MyKeysight Information on preventing analyzer damage can be found at: www.keysight.com/find/PreventingInstrumentRepair...

  • Page 5: Table Of Contents

    Contents Table of Contents Safety & Environmental Information 7 Warning Statements and Symbols 8 Safety 9 Safety Compliance 9 Safe Installation 9 Acoustic statement (European Machinery Directive) 9 General Safety Notices 9 Environmental Conditions (Operating) 10 Environmental Information 10 EMC (Electromagnetic Compatibility) 11 South Korean Class A EMC declaration 11 Declaration of Conformity 11 Ventilation 12...
  • Page 6 Functionality 33 Simplified Block Diagram 34 Signal Routing 35 Control 37 Troubleshooting 39 Where to get technical help 40 Identifying Problems 40 Returning the M1742A for Service 41 Calling Keysight Technologies 41 Locations for Keysight Technologies 42 Getting Started Guide...

  • Page 7: Safety & Environmental Information

    Keysight M1742A Transceiver Getting Started Guide Safety & Environmental Information The following topics can be found in this section: “Warning Statements and Symbols” on page 8 “Safety” on page 9 “Environmental Conditions (Operating)” on page 10 “EMC (Electromagnetic Compatibility)” on page 11 “Ventilation”...

  • Page 8: Warning Statements And Symbols

    Safety & Environmental Information Warning Statements and Symbols Warning Statements and Symbols Caution and Warning notices are used in this document are described below. A CAUTION notice denotes a hazard. It calls attention to an operating procedure, practice, or the like that, if not correctly performed or adhered to, could result in damage to the product or loss of important data.

  • Page 9: Safety

    Safety & Environmental Information Safety Safety This product has been designed and tested in accordance with accepted industry standards, and has been supplied in a safe condition.The documentation contains information and warnings that must be followed by the user to ensure safe operation and to maintain the product in a safe condition.

  • Page 10: Environmental Conditions (Operating)

    POLLUTION DEGREE 2, per IEC 61010-1 Third Edition and 664 respectively. Environmental Information Samples of this product have been type tested in accordance with the Keysight Environmental Test Manual and verified to be robust against the environmental stresses of Storage, Transportation and End-use; those stresses include but are not limited to temperature, humidity, shock, vibration, altitude and power line conditions.

  • Page 11: Emc (Electromagnetic Compatibility)

    This equipment has been conformity assessed for use in business environments. In a residential environment this equipment may cause radio interference. Declaration of Conformity The Declaration of Conformity for any Keysight product can be found on the website: http://www.keysight.com/go/conformity Getting Started Guide...

  • Page 12: Ventilation

    10°C from the lowest, of the maximum operating temperature of a single instrument. If there are any concerns or special requirements an Keysight Field Engineer should be consulted to assure instrument(s) temperature compliance and performance.

  • Page 13: Power Requirements

    This input does not represent a risk of personal injury. Do not remove the DC input plug from the M1742A while it is in an active state. Make sure the Status LED on the DUT-facing side of the M1742A is dark before disconnecting the DC input.

  • Page 14: Weight And Dimensions

    Safety & Environmental Information Weight and Dimensions Weight and Dimensions The weight and dimensions of the M1742A are as follows. — Weight: 3.5 kg — Height: 70 mm — Width: 175 mm — Length: 345 mm Protecting against electrostatic discharge...

  • Page 15: Instrument Maintenance

    Safety & Environmental Information Instrument Maintenance Instrument Maintenance Cleaning the Instrument Disconnect the M1742A from all cables before cleaning. Use a dry cloth or one slightly dampened with water to clean the external case parts. Do not attempt to clean internally. Connector Care...

  • Page 16: Connector Cleaning

    Safety & Environmental Information Instrument Maintenance Connector Cleaning Cleaning connectors with isopropyl alcohol shall only be done with all cables disconnected, and in a well-ventilated area. Allow all residual alcohol moisture to evaporate, and the fumes to dissipate prior to energizing the instrument. Keep isopropyl alcohol away from heat, sparks, and flame.

  • Page 17: Quick Start

    Keysight M1742A Transceiver Getting Started Guide 2 Quick Start The following topics can be found in this section: “Purpose and Function” on page 18 “Initial Inspection” on page 20 “Location and Mounting” on page 21...

  • Page 18: Purpose And Function

    Figure 2-1 M1742A used as an RF interface On the left side of the M1742A in the diagram, the Tx IF In port takes an input from the test system and upconverts it to the higher range of the DUT. Signals received from the DUT are downconverted and returned to the test system from the Rx IF Out port.
  • Page 19 USB controller and trigger lines shown in the illustration. The supplied AC/DC adapter provides a 19 VDC power input to the M1742A (this can also be done by a DC power supply, if one is included in the system setup).

  • Page 20: Initial Inspection

    — Contact the nearest Keysight Technologies office. — Keep the shipping materials for the carrier’s inspection. — If you must return a test set to Keysight Technologies, use the undamaged original or comparable shipping materials. See “Returning the M1742A for Service”...

  • Page 21: Location And Mounting

    Quick Start Location and Mounting Location and Mounting It is recommended to suspend the transceiver above the Device Under Test (DUT), with the RF port pointed downwards at the DUT, so that heat given off by the transceiver will rise away from the DUT. Leave a minimum clearance of 2.5 inches (7 cm) around the transceiver.
  • Page 22 Quick Start Location and Mounting Getting Started Guide...

  • Page 23: Exterior Features

    Keysight M1742A Transceiver Getting Started Guide 3 Exterior Features The following topics can be found in this section: “DUT-Facing Side” on page 24 “Instrument-Facing Side” on page 26 “Labels and Symbols” on page 29...

  • Page 24: Dut-Facing Side

    Figure 3-1 M1742A, DUT-facing side The DUT-facing ports are shown on the right in the block diagram below. Figure 3-2 M1742A, DUT-facing ports (on right) The features of this side of the M1742A are illustrated and described on the following page. Getting Started Guide...
  • Page 25 These LEDs are lit when the named port is in use. RF Tx/Rx 2 Status This LED is lit to indicate that the M1742A is in an active state (this is determined by inputs received at the Control port on the instrument-facing side of the M1742A). Getting Started Guide...

  • Page 26: Instrument-Facing Side

    Exterior Features Instrument-Facing Side Instrument-Facing Side The photograph below shows the instrument-facing side of the M1742A; the block diagram shows the instrument-facing RF ports (on the left). Figure 3-4 M1742A, instrument-facing side Figure 3-5 M1742A, instrument-facing ports (on left) Getting Started Guide...
  • Page 27 These SMB connectors carry trigger inputs and output to the external controller. These ports are Trig 2 required if the M1742A is controlled by way of the USB port. They are not required if the M1742A is controlled by way of the Control port, which incorporates trigger signals (however, even if the Control Trig 1 port is used, these trigger ports remain available for use).
  • Page 28 This 3.5 mm connector accepts a variable-frequency input from the LO Out connector of the external Tx LO In basebox. This input is mixed with another input to the M1742A (Tx IF In) to generate the LO input to the transmitter upconverter. Torque wrench required.

  • Page 29: Labels And Symbols

    Exterior Features Labels and Symbols Labels and Symbols Figure 3-7 M1742A regulatory labels Labels and symbols which may be shown on the M1742A (mainly on the rear panel of the chassis) are described in the table below. Symbol Description This symbol marks the standby position of the power line switch.
  • Page 30 UK conformity mark is a UK government owned mark. Products showing this mark comply with all applicable UK regulations. The Keysight email address is required by EU directives applicable to our product. The CSA mark is a registered trademark of the CSA international.
  • Page 31 EU DIRECTIVE and other National legislation. Please refer to www.keysight.com/go/takeback for information about your trade-in options with Keysight, in addition to product takeback instructions. China Restricted Substance Product Label. The EPUP (environmental protection use period) number in the center indicates the time period...
  • Page 32 Exterior Features Labels and Symbols Getting Started Guide...

  • Page 33: Functionality

    Keysight M1742A Transceiver Getting Started Guide 4 Functionality The following topics can be found in this section: “Simplified Block Diagram” on page 34 “Signal Routing” on page 35 “Control” on page 37...

  • Page 34: Simplified Block Diagram

    Simplified Block Diagram The simplified functional block diagram below shows how signals to and from the S9110A-F32 system front panel (the left side of the M1742A in the illustration below) interface with the Tx upconverter and Rx downconverter, and how the upconverted and downconverted signals interface with the DUT-facing ports of the test head (the right side of the illustration).

  • Page 35: Signal Routing

    — Red: variable-frequency LO input to the M1742A, used in generating an LO input to the upconverter and downconverter. — Brown: 4.8/9.6 GHz input to the M1742A, used in generating an LO input to the upconverter and downconverter. — Orange: generated LO signal to the upconverter and downconverter.
  • Page 36 Functionality Signal Routing The Tx/Rx ports are half-duplex: each one can function as a transmit port or a receive port (although not simultaneously). In the illustration below, the green transmit path can be routed either to RF Tx/Rx 1 (as in the upper picture) or to RF Tx/Rx 2 (as in the lower picture).

  • Page 37: Control

    (source) port is designated in the application interface as Head 1 RFHD 1, this is equivalent to RF Tx/Rx 1 on the M1742A. In the diagram below, the port names are designated in blue (as they appear in the application interface menus) and also in red (as they are identified in SCPI commands.)
  • Page 38 Functionality Control Getting Started Guide...

  • Page 39: Troubleshooting

    Keysight M1742A Transceiver Getting Started Guide 5 Troubleshooting The following topics can be found in this section: “Identifying Problems” on page 40 “Returning the M1742A for Service” on page 41...

  • Page 40: Where To Get Technical Help

    No operator serviceable parts inside. Refer servicing to qualified personnel. To prevent electrical shock do not remove covers. If the status indicator on the M1742A is not lit, or if it appears that the signals are not being exchanged with the Device Under Test check the following: 1.

  • Page 41: Returning The M1742A For Service

    Calling Keysight Technologies Keysight Technologies has offices around the world to provide you with complete support for the M1742A. To obtain servicing information, or to order replacement parts, contact the nearest Keysight Technologies office listed under “Locations for Keysight Technologies” on page 42.

  • Page 42: Locations For Keysight Technologies

    Troubleshooting Returning the M1742A for Service Locations for Keysight Technologies http://www.keysight.com/find/assist For online assistance: To contact Keysight Technologies: http://www.keysight.com/find/contactus Alternately, contact the nearest Keysight sales office: Americas Canada Brazil Mexico (877) 894 4414 55 11 3351 7010 001 800 254 2440...
