Summary of Contents for Bruno ELITE CRE-2110CAN
- Page 1 Operator Manual ELITE CURVED STAIRLIFT CRE-2110CAN 05-30-2023 P/N 2110CAN-O www.bruno.com...
-
Page 2: Table Of Contents
We encourage you to keep this information. Authorized Bruno Dealer Bruno stairlifts must be installed and maintained by an authorized Bruno dealer or the warranty will be null and void . Table of Contents Regulatory Information and Specifications . -
Page 3: Regulatory Information And Specifications
Seat Swivel: 0, 60 and 90 degrees at top Power Supply: 24VDC battery charger powered by 120V outlet Armrest with key switch (if so equipped) Armrest control switch Positioning belt Swivel release handle Footrest lever Obstruction sensors Bruno Independent Living Aids CRE-2110CAN OPERATOR 05-30-2023... -
Page 4: Safety
(See image at right.) Barrier arm switch: Seat armrests contain a safety switch that will only allow travel when the down stair side armrest is in the down position. E-Stop Button CRE-2110CAN OPERATOR 05-30-2023 Bruno Independent Living Aids... -
Page 5: Operation
OPERATION Bruno’s stairlift features a “soft-start,” preventing the unit from moving abruptly after the armrest control switch is pressed. Press and hold the armrest control to begin the gentle acceleration of the stairlift to operating speed. The stairlift will automatically stop at the upper or lower end of the rail or when the armrest control is released. -
Page 6: Standard Swivel Seat
Note: If jam occurs when raising/lowering the footrest, clear the jam and move the seat up and down until the footrest moves again. If normal operation is not restored, please contact your Bruno dealer for service. Mid-Park Position Option The mid-park position option allows you to park and charge the stairlift at a position between the two ends of the rail –... -
Page 7: Charging
CHARGING and DIAGNOSTIC CODES (under the seat) Keeping Stairlift Charged Bruno curved stairlifts are powered by two 12v batter- ies that charge when the lift is parked tightly against the brackets at either end of the rail. If the stairlift carriage does not contact the upper or lower charge brackets, the batteries will slowly drain. -
Page 8: Battery Charger Leds
LED occasionally turns off BLINKS BLINKS low voltage indication ALTERNATELY ALTERNATELY BLINKS BLINKS battery defective or heavily ALTERNATELY ALTERNATELY sulfated FAST BLINK partially open circuit; bad contact or battery sulfation battery connector reversed CRE-2110CAN OPERATOR 05-30-2023 Bruno Independent Living Aids... -
Page 9: Maintenance Tips
• Keep battery charger plugged into a live outlet . • Contact your Bruno dealer annually to have the stairlift examined, cleaned and lubricated. Remote Battery Replacement • Remove access panel on back. • Replace two AA alkaline batteries. -
Page 10: Troubleshooting
Stairlift Beeps When Stopped on Rail The Bruno Elite curved stairlift charges when the stairlift is stopped at either end of the rail. The unit will beep if the stairlift is stopped short of the charging position, so you are alerted that the stairlift batteries are not receiving a charge. -
Page 11: Warranty
• All Major Components, which includes the motor, gearbox drivetrain and rail system of the Bruno Stairlift, are/ will be free of defects in material and workmanship for the lifetime of the Bruno Stairlift and as long as the Original Purchaser owns the Stairlift. Major components do not include optional equipment.
