Dragonfish
Dragonfish
F
DELAY
X Type:
Build Level: Intermediate
Based On: madbeanpedals original
The Dragonfish is a compact, analog-voiced PT2399 delay with modulation. Whereas the two
existing Standard Series PT2399 delay projects (the Degenerator and Transponder) have dynamic-
based modulation, the Dragonfish has a full complement of LFO modulation with rate and depth
controls.
•
TIME: The delay range is around 50ms to 600ms.
•
RPT: Delay repeats from 1 to "infinity" or self-oscillation.
•
MIX: Delay signal volume.
•
RATE: Sets the speed of the delay modulation from a slow chorus effect (CCW) to a ridiculously
fast choppy one (CW)
•
DEPTH: The intensity of the modulation effect. Setting this CCW turns the modulation off
completely.
Terms of Use:
You are free to use purchased Dragonfish circuit boards for both DIY and small commercial operations. You may not offer Dragonfish PCBs for
resale or as part of a "kit" in a commercial fashion. Peer to peer re-sale is fine, though.
Technical assistance
for is available via the
available to respond via email in a timely and continuous manner, and (2) posting technical problems and solutions in the forum creates a record from which other
members may benefit.
All copyrights and registered trademarks are property of their original owners. Any mention of trademarked or intellectual properties in this documents is purely for
comparative purposes.
Overview
Controls
madbeanpedals
forum. Please go there rather than emailing me for personal assistance. This is because (1) I'm not always
Last Updated:
February 14, 2025 6:20 PM
© 2024
madbeanpedals
Advertisement
Table of Contents
Related Manuals for Mad Bean Pedals Dragonfish
Summary of Contents for Mad Bean Pedals Dragonfish
- Page 1 Terms of Use: You are free to use purchased Dragonfish circuit boards for both DIY and small commercial operations. You may not offer Dragonfish PCBs for resale or as part of a “kit” in a commercial fashion. Peer to peer re-sale is fine, though.
-
Page 2: Parts Layout
Parts Layout Dragonfish pg. 2... -
Page 3: Component Values
Component Values Dragonfish pg. 3... - Page 4 Trace Layout - Outer Layers Dragonfish pg. 4...
- Page 5 Trace Layout - Inner Layers Dragonfish pg. 5...
- Page 6 Wiring Unless otherwise noted, all Standard Series projects have the same wiring regardless of which 3PDT bypass board is used. A 6-pin, 2” ribbon cable is recommended for soldering the connections between the two PCBs. Dragonfish pg. 6...
- Page 7 220k 1n914 220k 1n5817 Regulator 78L05 100k TL072 100n PT2399 100n TL022 Pots 10kA 10kB DEPTH 50kB 100n TIME 50kB RATE 100kC 10uF 220k 10uF 100k 10uF 220k 100uF 220k 100n 47uF 100n 100n 100uF 100n 10uF Dragonfish pg. 7...
-
Page 8: Shopping List
PCB Right Angle 16mm 50kB PCB Right Angle 16mm 100kC PCB Right Angle 16mm Additional Hardware (1) 1590B enclosure (2) Lumberg 1/4” Compact mono jacks (1) Slim 2.1mm DC jack (1) Standard 3PDT footswitch (1) 5mm LED Dragonfish pg. 8... - Page 9 “original” since I only added the modulation and a few tweaks. Point being, you can use the Dragonfish PCB to build a Rebote 2.5 with modulation by using the Rebote values where applicable. Both projects sound great, but a little different from one another.
-
Page 10: Circuit Voltages
4.59 varies 4.58 varies 4.49 varies varies varies 4.61 varies 9.21 9.21 PT2399 78L05 5.69 9.21 2.85 5.69 3.04 2.82 0.61 0.94 2.85 2.85 2.85 2.85 2.85 2.85 2.85 2.85 9.52vDC One Spot supply Current Draw: ~22mA Dragonfish pg. 10... - Page 11 Link to Tayda Standard Series master drill template Hardware 1590B enclosure 16mm pots Lumberg 1/4” Compact mono jacks Slim 2.1mm DC jack Standard 3PDT footswitch 5mm LED NOTE: Different 1/4” and DC jack styles may require different sized drill holes. Dragonfish pg. 11...
- Page 12 Build Pic Dragonfish pg. 12...
- Page 13 Schematic Dragonfish pg. 13...
