Dustbunny
FX TYPE: Fuzz
Based on the Tonebender™
Enclosure Size: 1590A
"Softie" compatibility: none
© 2020
madbeanpedals
The DustBunny is a simple, negative ground silicon Tonebender fuzz fitted for a 1590A enclosure.
•
FUZZ: Fuzz from min to max.
•
VOL: Output
Terms of Use:
You are free to use purchased Dustbunny circuit boards for both DIY and small commercial operations. You may not
offer Dustbunny PCBs for resale or as part of a "kit" in a commercial fashion. Peer to peer re-sale is fine, though.
Technical assistance
for your build(s) is available via the
assistance on builds. This is because (1) I'm not always available to respond via email in a timely and continuous manner, and (2)
posting technical problems and solutions in the forum creates a record from which other members may benefit.
Overview
Controls
madbeanpedals
forum. Please go there rather than emailing me for
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Mad Bean Pedals Dustbunny
Summary of Contents for Mad Bean Pedals Dustbunny
- Page 1 You are free to use purchased Dustbunny circuit boards for both DIY and small commercial operations. You may not offer Dustbunny PCBs for resale or as part of a “kit” in a commercial fashion. Peer to peer re-sale is fine, though.
- Page 2 Dustbunny Parts madbeanpedals...
- Page 3 Dustbunny Values madbeanpedals...
- Page 4 Dustbunny Traces madbeanpedals...
- Page 5 Dustbunny B.O.M. Resistors Caps Diodes 1N4001 470k Transistors 100k 100n Q1 - Q3 NPN -Si Trimmer 47pF BIAS 100k Pots 100k 47uF FUZZ 470R 100n 100kA 100R madbeanpedals...
-
Page 6: Shopping List
Dustbunny Shopping List Value Type Rating 100R Metal / Carbon Film 1/4W 470R Metal / Carbon Film 1/4W Metal / Carbon Film 1/4W Metal / Carbon Film 1/4W Metal / Carbon Film 1/4W 100k Metal / Carbon Film 1/4W 470k... - Page 7 Dustbunny Parts Guide Low profile Electrolytic caps: http://smallbear-electronics.mybigcommerce.com/electrolytic-radial-low-profile-16v-1-f-100-f/ 9mm PC Mount pots (1kC, 100kA): http://smallbear-electronics.mybigcommerce.com/alpha-single-gang-9mm-right-angle-pc-mount/ Bourns 3362p (25k): https://www.mouser.com/ProductDetail/Bourns/3362P-1-253LF?qs=sGAEpiMZZMvygUB3GLcD7vRb QqL9uMLMqIpepdvyyRc%3D Bourns 3362p (20k): https://www.taydaelectronics.com/potentiometer-variable-resistors/cermet-potentiometers/3362p/20k- ohm-trimmer-potentiometer-cermet-1-turn-3362p.html Thinline DC Jack: http://smallbear-electronics.mybigcommerce.com/dc-power-jack-all-plastic-unswitched-2-1-mm/ Enclosed Mono: http://smallbear-electronics.mybigcommerce.com/1-4-in-mono-enclosed-jack/ http://smallbear-electronics.mybigcommerce.com/1-4-in-mono-enclosed-switchcraft-111x/ Lumberg Mono: http://smallbear-electronics.mybigcommerce.com/lumberg-1-4-compact-shrouded-mono-jack/ madbeanpedals...
- Page 8 Dustbunny Notes • There are a variety of NPN silicon transistors that will work in this build. For mine I did the following - Q1: BC108, Q2, Q3: BC207B (140hFE and 160hFE, resp.) You could use all BC108/109 or find a cool mojo mix. Smallbear has plenty to offer for Tonebender types. Generally smaller gain buckets are better (300 hFE and below).
- Page 9 Wiring Diagram Dustbunny madbeanpedals...
- Page 10 Dustbunny 1590A Drill Guide Note: Drill Guides are approximate and may require tweaking depending on the types of jacks, switches and pots you use. • This template will work for either mono enclosed jacks or the “Lumberg” style. • It uses the “Thinline” style DC Jack.
- Page 11 Voltages Dustbunny 1.04 0.57 1.35 0.52 0.72 • 9.42vDC One Spot • Current Draw: ~ 2mA madbeanpedals...
- Page 12 Build Pic Dustbunny madbeanpedals...
- Page 13 Schematic Dustbunny madbeanpedals...
