Motorola Moto G54 5G Manual

Let's get started

Before using your phone, please read the legal, safety and regulatory information provided with your product.
Overview
* Note: only model XT2343-6 has an ultra-wide camera.

Put the cards in and power on

  1. Insert the SIM tool into the hole next to the tray to pop out the tray.
    Put the cards - Step 1 - Nano SIM
    Note: make sure that you use the correct size of SIM card and don't cut the SIM card.
  2. Insert the SIM card(s) with the gold contacts down, then gently push the tray into the slot.
    Add a microSD card (optional, sold separately) for additional storage.
    eSIM option (only for models with one physical SIM): your phone may have an eSIM (embedded SIM card) in addition to the physical SIM card. Contact your service provider for details if you want to activate and use it.
    Put the cards - Step 2
  3. Press and hold the power button to turn on your phone, then follow the prompts to get started.
    Power On
    Note: to turn off your phone, press the power and volume up buttons at the same time.

Help and more

Get answers, updates and info:

  • Help is here: from the Home screen, swipe up and tap Settings > Help to learn how to use your phone and get support.
  • Get more: get software, user guides and more at www.motorola.com/mymotog.
  • Get apps: tap Play Store to browse and download apps.

play.google.com

  • Connect with 5G: 5G service plan and 5G network coverage required; available only in selected areas; device not compatible with all 5G networks. Contact your service provider for details.

Legal information. This guide provides important legal, safety and regulatory information that you should read before using your product. For the complete legal information, from the Home screen swipe up and tap Settings > , then type Legal information, or visit www.motorola.com/device-legal.
Water repellent. Your phone is not waterproof. For more about your phone's water-repellent design and care, swipe up and tap Settings > Help.
Charging and battery safety. To prevent possible burning and injury, the battery in your phone should only be removed by a Motorola approved service centre or similar skilled personnel.
If your phone becomes unresponsive, press and hold the power button until the screen goes dark and your phone restarts. Charge your phone using a compatible Motorola charger (may be sold separately). Use of other chargers is not recommended and may impair the charging performance. Don't charge your phone in temperatures below -20°C or above 45°C. Chargers that do not comply with applicable national standards may be unsafe, with risk of death or injury, and may cause slow charging or product damage. To view applicable standards and to learn more, see the "Legal information" section of this guide or visit www.motorola.com/device-legal.

Warning about high volume usage. To prevent possible hearing damage, do not listen at high volume levels for long periods. When your headset volume reaches the high volume threshold, a warning will be shown. Tap OK to dismiss it, or wait one to five seconds, then press the volume up button to dismiss the alert and enable the volume to continue to be adjusted.
Extreme heat or cold. Don't use your phone in temperatures below -20°C or above 45°C. Don't store/transport your phone in temperatures below -20°C or above 60°C.
Supported frequencies and power (Model XT2343-2, XT2343-6). This phone is capable of operation on the following frequencies, subject to location and network availability.

Operating mode Frequency range MHz/band Maximum nominal transmit power dBm
Bluetooth 2400 – 2483.5 20 dBm EIRP
Wi-Fi 2400 – 2483.5 20 dBm EIRP
Wi-Fi 5150 – 5250 23 dBm EIRP
Wi-Fi 5250 – 5350 20 dBm EIRP
Wi-Fi 5470 – 5725 20 dBm EIRP
Wi-Fi 5725 – 5850 14 dBm EIRP
GNSS 1559 – 1610/1164 – 1300 N/A
NFC 13.56 -21.09 dBuA/m @ 10m
FM receive 87.5 – 108 N/A
GSM 2/3/5/8 33/30
UMTS 1/2/5/8 24
LTE B1/2/3/5/7/8/20/26/28/ 32/38/40/41*/42 23/(26*)
5G n1/3/5/7/8/20/26/28/ 38/40/41/77*/78* 23(26*)
