Before using your phone, please read the legal, safety and regulatory information provided with your product.
Tip: you can keep your phone secure with your face, a pattern, a password or a PIN. Swipe up from the Home screen and tap Settings > Security > face unlock or screen lock to apply security to the lock screen.
Get answers, updates and info:
Water repellent. Your phone is not waterproof. For more about your phone's water-repellent design and care, swipe up and tap Settings > Help.
Battery safety. To prevent possible burning and injury, the battery in your phone should only be removed by a Motorola-approved service centre or similar skilled personnel.
If your phone becomes unresponsive, press and hold the power button until the screen goes dark and your phone restarts. Charge your phone using a compatible Motorola charger (may be sold separately). Use of other chargers is not recommended and may impair the charging performance. Don't charge your phone in temperatures below -20°C or above 45°C. Chargers that do not comply with applicable national standards may be unsafe, with risk of death or injury, and may cause slow charging or product damage.
Warning about high volume usage. To prevent possible hearing damage, do not listen at high volume levels for long periods. When your headset volume reaches the high volume threshold, a warning will be shown. Tap OK to dismiss it, or wait one to five seconds, then press the Volume up button to dismiss the alert and enable the volume to continue to be adjusted.
Extreme heat or cold. Don't use your phone in temperatures below -20°C or above 45°C. Don't store/transport your phone in temperatures below -20°C or above 60°C.
Supported frequencies and power (Model XT2345-3, XT2345-5).
This phone is capable of operation on the following frequencies, subject to location and network availability.
Operating mode | Frequency range MHz / Band | Maximum nominal transmit power dBm |
Bluetooth | 2400 – 2483.5 | 20 dBm EIRP |
Wi-Fi | 2400 – 2483.5 | 20 dBm EIRP |
Wi-Fi | 5150 – 5250 | 23 dBm EIRP |
Wi-Fi | 5250 – 5350 | 20 dBm EIRP |
Wi-Fi | 5470 – 5725 | 20 dBm EIRP |
Wi-Fi | 5725 – 5850 | 14 dBm EIRP |
GNSS | 1559 – 1610 | N/A |
NFC (XT2345-5 only) | 13.56 | -21.48 dBuA/m @ 10 m |
FM | 87.5 – 108 | N/A |
GSM | 3/5/8 | 33/30 |
UMTS | 1/5/8 | 24 |
LTE | 1/3/5/7/8/20/28/38/40/41 | 23 |
Here you can download full pdf version of manual, it may contain additional safety instructions, warranty information, FCC rules, etc.
