Page 1: Repair Parts
COOKTOP Repair Parts List MODEL NUMBER MGC5536BDQ When requesting service or ordering parts, always provide the following information: - Product Type - Part Number - Model Number - Part Description ©2005 Maytag Services... - Page 2 Section: TOP ASSEMBLY Model: MGC5536BDQ C15-583...
-
Page 3: Top Assembly
Section: TOP ASSEMBLY Part No. Description Series Qty 74007356 BUMPER, GRATE BOTTOM 74007791 GRATE (TAUPE) 74007810 GRATE (TAUPE-CTR) 74007356 BUMPER, GRATE BOTTOM 74007419 CAP, BURNER (SMR-TAUPE) 74007751 CAP, BURNER (MED-TAUPE) Note: CAP, BURNER (LRG-TAUPE) 74011277 KNOB, BURNER (BSQ) 74007793 KNOB, BURNER (BSQ) 74007705 GROMMET 74007803... - Page 4 Section: BODY Model: MGC5536BDQ C14-790...
- Page 5 Section: BODY Part No. Description Series Qty 74007797 BOTTOM, BURNER BOX 74007811 BRACKET, ORIFICE HOLDER (CTR) 74009250 BRACKET, ORIFICE HOLDER 74007787 BRACKET, ORIFICE HOLDER 74009253 SCREW, HEX HEAD 74009253 SCREW, HEX HEAD 74007787 BRACKET, ORIFICE HOLDER 74009250 BRACKET, ORIFICE HOLDER 74001380 SEAL, MANIFOLD PIPE 74007798...
-
Page 6: Supplemental Information
Section: SUPPLEMENTAL INFORMATION Part No. Description Series Qty 74007565 MANUAL, USE & CARE 8111P475-60 MANUAL, USE & CARE 74007697 HARNESS, SPARK LEAD Note: HARNESS, SPARK (FRT MODULE) 74007812 HARNESS, SPARK Note: HARNESS, SPARK (REAR MODULE) 74007788 KIT, LP CONVERSION *Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available... - Page 7 Section: WIRING INFORMATION Model: MGC5536BDQ 15003190...
