Technical Support and E-Warranty Certificate www.vevor.com/support
BIKE REPAIR STAND
MODEL:TQXL-03
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VEVOR TQXL-03
Summary of Contents for VEVOR TQXL-03
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support BIKE REPAIR STAND MODEL:TQXL-03 We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
- Page 3 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
-
Page 4: Safety Notices
Safety Notices Risk of injury! • Thoroughly read the assembly and operating instructions prior to assembly and follow the individual steps as described in the assembly instructions. • WARNING! Do not exceed the maximum load capacity of 80 lbs / 36.3kg! Injuries or product damages may result. - Page 5 Maximum Load 80 lbs / 36.3 kg For Bicycle Frame Size 25-40 mm Stretch Range 42.5-74.8 inch / 1079.5-1900 mm Number of Legs 4 pcs Main Material Carbon Steel Item Reference Image QTY. Item Reference Image QTY. - 3 -...
- Page 6 Assembly Fig. 1 Fig. 2 Fig.3 1. Set up the Main Supporting Stand of the bicycle assembly stand by sliding the coupling (1) on the Main Supporting Stand (A) all the way down. 2. Unfold the feet (2) on the tripod legs down and ensure the product is placed on a solid and even surface.
-
Page 7: Care, Storage
5. Mount the bicycle bracket (C) onto the telescopic pole(B). 6. The tool tray (D) can be attached anywhere on the Main Supporting Stand (A). Note The feet on the assembly stand may optionally be screwed into the surface to achieve greater stability. Be sure to use suitable mounting materials. - Page 8 Fig.4 Fig.5 Fig.6 - 6 -...
- Page 9 Fig.7 Fig.8 Adjust the angle of the bicycle bracket (C) to fit the selected frame position of the bicycle (see examples in fig. 4and fig. 5) and tighten the screw (3) (fig. 7). Now place the bicycle in the bicycle bracket and firmly secure frame.
- Page 10 • We recommend performing the next step (height adjustment) with 2 persons. You may then extend the telescopic rod (B) to the desired height. Twisting the telescopic rod allows you to also change the position of the attached bicycle. Once you have reached the desired height and position, firmly tighten the screw (5) (fig.
- Page 12 Technical Support and E-Warranty Certificate www.vevor.com/support...
