Dreame Roboticmower A2
User Manual
1
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Roboticmower A2 and is the answer not in the manual?

Questions and answers

Related Manuals for Dreame Roboticmower A2

Summary of Contents for Dreame Roboticmower A2

  • Page 1 Dreame Roboticmower A2 User Manual...
  • Page 2 .................P05~P39 .................P40~P75 ...............P76~P113 ..............P114~P148 ..............P149~P183 ..............P184~P218...

  • Page 3: Declaration Of Conformity

    Dreame Trading (Tianjin) Co., Ltd. No. 1-1-2112, Financial and Trade Center South Zone, 6975 Asia Road, Tianjin Pilot Free Trade Zone (Dongjiang Bonded Port Zone)，Tianjin 300461, P .R. China On behalf of Dreame declare that the product Description Robotic Lawnmower Type MLLA7210...

  • Page 4: Table Of Contents

    Original Instructions Table of Contents 1 Safety Instructions ..................P06 2 Product Introduction ................... P10 3 Installation ....................P14 4 Preparation for First Use ................P16 5 Map Your Garden ..................P22 6 Operation ....................P27 7 Dreamehome App ..................P30 8 Maintenance ....................

  • Page 5: Safety Instructions

    • When connecting the main cable to the power outlet, use a residual-current device (RCD) with a maximum tripping current of 30 mA. • Only use original batteries recommended by Dreame. The safety of the product cannot be guaranteed with non-original batteries. Do not use non-rechargeable batteries.

  • Page 6: Safety Instructions For Operation

    1.3 Safety Instructions for Operation • Keep your hands and feet away from the rotating blades. Do not place your hands or feet near or below the product when it is turned on. • Do not lift or move the product when it is turned on. •...
  • Page 7 1.7 Symbols and Decals WARNING – Read user instructions before operating the machine. WARNING – Keep a safe distance from the machine when operating. WARNING – Operate the disabling device before working on or lifting the machine. WARNING – Do not ride on the machine. WARNING –...
  • Page 8 It is impossible for digging, sweeping or snow cleaning. Hereby, Kutting Technology (Suzhou) Co., Ltd. declares that the radio equipment model Dreame MXXA8210 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://global.dreametech.com/pages/declaration-of-conformity.

  • Page 9: Product Introduction

    Verbinden Sie das Netzteil mit dem Verlängerungskabel und schließen Sie es an eine Steckdose an. N'hésitez pas à nous contacter si vous avez d'autres questions. Raccorder l'alimentation à la rallonge et la brancher sur la prise d'alimentation. Email：aftersales@dreame.tech Website: https://global.dreametech.com You can also download Dreamehome app from App Store or Google Play Sie können die Dreamehome App auch im App Store oder bei Google Play herunterladen.

  • Page 10: Product Overview

    2.2 Product Overview Stop button LiDAR Knob Light Display Charging contacts Handle Battery compartment EdgeMaster ™ Link module blade disc Front wheel Drive wheel Front camera [1] Equipped with hub motors. 2.3 OmniSense ™ 2.0: 3D Ultra-Sensing System with AI Camera Elevate lawn care to the next level with OmniSense ™...
  • Page 11 Dreame after-sales service team via dreamesupport@dreame.tech to help you restore the service. Important: If you do not contact Dreame after-sales service to renew the Link Service within one year after its expiration, your Link Module will be locked. To reactivate the service, you must bring the Link Module to a Dreame after-sales service center.
  • Page 12 Place the robot on a soft surface and turn it upside down. Loosen 4 screws to remove the cover using a screwdriver. Take out the battery, and disconnect the battery connector. Disconnect the module connector and carefully remove the Link Module from its slot. 2.5 Sensors Name Description...

  • Page 13: Installation

    3 Installation 3.1 Select a Suitable Location • Place the charging station on a level surface near the edge of the lawn and a power outlet. Place it in an area with a strong Wi-Fi signal. Note: Use your mobile device to help check the Wi-Fi signal strength of the location. A good Wi-Fi signal strength ensures a stable connection between the robot and the app.
  • Page 14 Insert the charging tower into the baseplate until you hear a click. Insert the cleaning brush into the charging tower by aligning the tab with the slot. Connect the power supply to the extension cable and then connect to a power outlet. Please keep the power supply at least 30 cm above the ground.

  • Page 15: Preparation For First Use

    Note: The indicator light will blink green when the robot is charging successfully in the charging station. Note: If you're looking to add a garage for extra protection, please use the matching Dreame Garage available at local stores or online. Using a non-Dreame garage may cause issues during recharging.
  • Page 16 Display Icon Status Battery level (Shows the current battery level.) Charging (The robot successfully docks in the charging station.) Bluetooth (The robot is connected to the app via Bluetooth.) Wi-Fi (The robot is connected to the app via a Wi-Fi network.) Link service (Link service is activated.) Schedule (A task is scheduled for today and has not started yet.) Controls...

  • Page 17: Menu Structure Overview

    Menu Structure Overview All-Area Mowing Modes Edge Mowing View Schedule Schedule Turn on/off Schedule Mowing Efficiency Mowing Height Obstacle Avoidance Height Do Not Disturb Mode Rain Protection Main Page Frost Protection Lift Alarm Settings Off-Map Alarm Change PIN Code Volume Language Reset the Robot About...

  • Page 18: Initial Settings

    4.2 Initial Settings Before turning the robot on for the first time, there are some basic settings to do before the robot is ready to start working. Press the Stop button to open the top cover. Press and hold the button on the control panel for 2 seconds to turn on the robot.
  • Page 19 2. Enter the PIN code again to complete setting the PIN code. Note: If two passwords do not match, please set the new password again. Connect the Robot to the Internet Please scan the QR code to download the Dreamehome app on your mobile device. After the installation, please create an account and log in.
  • Page 20 3. Follow the in-app instructions to complete the Wi-Fi network connection. Important: Please use a single-band network of 2.4 GHz frequency or dual-band network of 2.4/5 GHz frequency. Important: Make sure your Wi-Fi network doesn't have a firewall and isn't encrypted. Otherwise, the network setup may fail.

  • Page 21: Map Your Garden

    5 Map Your Garden Before mapping, please check the following: • The battery level of the robot is more than 50%. • The protective cover of the LiDAR is removed. • The top cover is closed. • The robot correctly docks in the charging station. 5.1 Create the Virtual Boundary 5.1.1 Automatic Mapping The robot utilises OmniSense ™...
  • Page 22 We recommend following the robot during the mapping process. If the robot fails to accurately detect the boundaries, you can exit automatic mapping mode and switch to manual control at any time. 5.1.2 Mapping via Remote Control If you prefer not to use the Auto Mapping feature, you can switch to remote control to map out the boundaries. Tap Remote Control to enter remote control mode.
  • Page 23 • The robot can navigate slopes with an incline up to 50% (27° ). However, for better mowing results, it is recommended to keep the slopes of work areas below 25% (14° ). • For areas narrower than 80 cm, please set them as paths to allow the robot to pass through (see section 5.4: Set Path).
  • Page 24 When the robot returns to within 1 m of the starting point, you can tap Close Boundary and the boundary will automatically be completed. 5.2 Set No-Go Zone Though the robot can automatically avoid obstacles, it is still necessary to set areas with a risk of falling, such as swimming pools and sandpits, as no-go zones.
  • Page 25 • To Separate and Combine Zones To divide a zone into smaller ones or to merge zones that were divided using the app into a larger one, go to > Map Editing > Zone settings and tap Separate or Combine in the app. 5.4 Set Path For isolated zones, please create a path to connect them.

  • Page 26: Operation

    5.5 Finish Map Tap Finish Map when work areas, paths and no-go zones are completed. 5.6 Add a Second Map If there is no path between your front and back gardens, you can create a second map. After completing the first map, tap Add Map to continue creating the second one. Alternatively, you can navigate to >...
  • Page 27 • Start via the control panel 1. Press Stop button to open the cover and enter the PIN code. 2. Select "Modes" on the display and press the knob. 3. Turn the knob to select the mowing mode.
  • Page 28 button, then close the top cover in 5 seconds. The robot will leave the charging station and 4. Press the start all-area mowing. You can also tap Start in the app to start mowing. 6.2 Pause To pause the current mowing task, you can press the Stop button on the robot or tap Pause in the app. Note: The robot cannot be started directly through the app after the Stop button is pressed.

  • Page 29: Dreamehome App

    6.4 Return to the Charging Station To send the robot back to its charging station, press the on the control panel. Confirm to pause or cancel the current task, then close the top cover within 5 seconds. The robot will automatically return to the charging station to recharge.

  • Page 30: Child Lock

    7.4 Schedule After the first map is completed, the robot automatically creates two weekly mowing schedules according to the lawn size, which are "Spr/Sum Schedule" and "Aut/Win Schedule". You can tap in the app to do detailed schedule settings. With the schedule function, you can completely leave the daily mowing work to the robot.
  • Page 31 7.8 Security Features The robot comes with multiple anti-theft features, powered by the built-in GPS in the Link module for added security. Besides, the front camera uses OmniSense ™ 2.0 technology to detect human presence, making the robot a helpful garden guardian. 7.8.1 Lift Alarm With this function enabled, an alarm will go off immediately when the robot is lifted, and the robot will be locked.

  • Page 32: Maintenance

    Level for Resuming Tasks to set the battery levels at which the robot will automatically return to the charging station or resume unfinished mowing tasks. Note: Dreame development team will continuously conduct OTA (Over-the-Air) updates and maintenance on the firmware and app. Please check for update notifications or enable the Auto-update function to keep the firmware and app up-to-date and enjoy more features.
  • Page 33 • The housing, chassis and blade disc: 1. Turn the robot off. 2. Cover the LiDAR with its protective cover. 3. Turn the robot upside down. 4. Clean the housing, blade disc and chassis with a hose. Warning: Do not touch the blades when cleaning the chassis. Please wear gloves when cleaning. Caution: Please do not use a high-pressure washer for cleaning.

  • Page 34: Replacing The Components

    To keep the blades sharp, please replace the blades regularly. It is recommended to replace the blades every 6–8 weeks or sooner. Please only use the Dreame genuine blades. Warning： Please turn off the robot. Wear protective gloves before replacing the blades.
  • Page 35 3. Put the robot on a soft surface and turn it 4. Remove the holder by pressing the button upside down. under the blade disc. 5. Remove the blade by aligning the hole of the 6. Remove 3 blades and holders. blade with the shaft.

  • Page 36: Battery

    9 Battery For long-term storage, charge the robot every 6 months to protect the battery. Battery damage caused by over-discharge is not covered by the limited warranty. Do not charge the battery at an ambient temperature above 45° C or below 6° C. The long-term storage temperature for the battery should be between -10 and 35°...

  • Page 37: Troubleshooting

    12 Troubleshooting Issue Cause Solution 1. The robot is not within 1. Check if the robot has completed the process Wi-Fi signal coverage or of turning on. The robot is not Bluetooth range. 2. Check if the router is working properly. connected to the app.
  • Page 38 Issue Cause Solution 1. Clean the cutting system and remove any debris or foreign objects. The blade disc cannot The blade disc cannot move 2. If you continue to encounter this error, you can move to the side. to the side. disable the EdgeMaster ™...
  • Page 39 Issue Cause Solution 1. The robot will automatically try to return to the charging station to cool down. 2. Ensure the robot operates at an ambient temperature below 40 ℃ . 3. Place the robot in a shaded, cool, and well- LiDAR temperature is LiDAR temperature is ≥...
  • Page 40 Issue Cause Solution The robot cannot find the 1. Check if there are obstacles blocking the robot. Failed to return to the charging station when Remove the obstacles and retry. charging station. returning to the charging 2. Remote control the robot back to the charging station.

  • Page 41: Specifications

    13 Specifications Product name Dreame Roboticmower A2 Brand Dreame Basic information Model MXXA8210 Dimensions 643 × 436.5 × 261 mm Weight (battery included) 16.3 kg Recommended working capacity 3,000 m² Standard: 1,000 m²/day Mowing efficiency Efficient: 2,000 m²/day Mowing Mowing height 30–70 mm...
  • Page 42 Driving speed under remote control 0.45 m/s–0.8 m/s Standard: 0.35 m/s Driving motor Driving speed when mowing Efficient: 0.6 m/s Motor type Hub motor Cutting motor Speed 2200/min Battery model MBPA10 Battery type Lithium-ion battery Battery (robot) Rated capacity 5000 mAh Rated voltage 18 V DC Charger model...
