KOBALT and logo design are trademarks or registered trademarks of LF, LLC.
All rights reserved.
ATTACH YOUR RECEIPT HERE
Serial Number
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 888-3KOBALT (888-356-2258), 8 a.m - 8 p.m., EST,
Monday - Sunday. You could also contact us at ascs@lowes.com.
SS23419
Purchase Date
1
ITEM #6309481
2-Drawer
Adjustable Height
Workbench Table
MODEL #410-096-0131
Español p. 11
Advertisement
Related Manuals for Kobalt 6309481
Summary of Contents for Kobalt 6309481
- Page 1 2-Drawer Adjustable Height Workbench Table MODEL #410-096-0131 Español p. 11 KOBALT and logo design are trademarks or registered trademarks of LF, LLC. All rights reserved. ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 888-3KOBALT (888-356-2258), 8 a.m - 8 p.m., EST,...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information ..........................2 Package Contents ..........................3 Hardware Contents ..........................4 Assembly Instructions .........................5 Operation Instructions .........................8 Care and Maintenance ........................9 Replacement Parts List ........................10 SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble or operate this product. -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Wood Top Stability Bar Leg (Right) Caster Crank Handle Drawer Slide (Pair) Leveling Feet Drawer Leg (Left) Drawer Side Panel Top Rail Back Panel Rotating Rod Front Panel... -
Page 4: Hardware Contents
HARDWARE CONTENTS OOLS REQUIRED Safety Phillips goggles screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. PART DESCRIPTION QUANTITY Screw M6 x 15L Bolt M8 x 25L Washer M8 10-14mm Wrench PRODUCT SPECIFICATIONS COMPONENTS SPECIFICATIONS Maximum Capacity (Drawer) 35 lbs. Maximum Capacity 300 lbs. -
Page 5: Assembly Instructions
2. Determine the front and back of the top before starting. The front of the wood top (A) has the Kobalt badge on the edge. 3. Attach the right leg (B) to the wood top (A) as shown using four M6 x15L screws (AA). -
Page 6: Caster Installation
ASSEMBLY INSTRUCTIONS 7b. Option 2: Attach the stability bar (H) to the bottom of the leg (B) and leg (E) using four M8 x 25L bolts (BB) Leveling feet installation and four M8 washers (CC). Finger tighten only. BB CC 10. - Page 7 ASSEMBLY INSTRUCTIONS 12. Attach the front panel (N) to the drawer side 14. Remove the drawers using the steps below panels (L) by using one screw (AA) ▪ Fully extend and empty the drawer. for each side. ▪ Depending on the slide, either lift or lower the release lever on both sides so the slides can ride over the stops.
-
Page 8: Operation Instructions
OPERATION INSTRUCTIONS 1. Leveling Foot Adjustment Important: Ensure there is no weight on top of the workbench when leveling. ▪ Adjust each leveling foot (D) to the desired elevation with a wrench(DD) as shown. ▪ Turn the lock nut counterclockwise to elevate and clockwise to lower the leveling foot. -
Page 9: Care And Maintenance
CARE AND MAINTENANCE • Keep the product in good repair by adopting a regular maintenance program. • Grease the casters annually using high quality bearing grease. • Lubricate the slides semi-annually with general purpose grease or equivalent. • Periodically clean the drawer fronts, drawer trim, and other surfaces with a mild detergent and water. -
Page 10: Replacement Parts List
REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 888-3KOBALT (888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also contact us at ascs@lowes.com. PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Wood Top Stability Bar Leg (Right) Caster Crank Handle...
