1
ITEM #5105949
20 PC MODULAR
WALL
ORGANIZER
MODEL #54006
Español p. xx
Lowes.com
Advertisement
Table of Contents
Related Manuals for Kobalt 54006
Summary of Contents for Kobalt 54006
- Page 1 20 PC MODULAR WALL ORGANIZER MODEL #54006 Español p. xx KOBALT , K-RAIL and logo design are trademarks or registered trademarks of LF, LLC. All rights reserved. ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 888-3KOBALT (888-356-2258), 8 a.m - 8 p.m., EST,...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents ...........................3 Hardware Contents ..........................4 Preparation ............................4 Safety Information ..........................5 Assembly Instructions ........................6 Operating Instructions ..........................9 Care and Maintenance ........................9 Troubleshooting ..........................9 Warranty ............................10 Replacement Parts List ........................10 Lowes.com... -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Post Shelf Left Bracket Right Bracket K Steel Rail 6 in. Post Hook 4 in. K Rail Hook 6 in. Double-head K Rail Hook 6 in. Single-head K Rail Hook Lowes.com... -
Page 4: Hardware Contents
HARDWARE CONTENTS M6x10mm Φ14x1.0mm Bolt Washer Qty.16 Qty.16 ST5x40mm Screw Qty.20 PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time:15 Minutes Tools Required for Assembly (not included): Ladder,Hammer, Tape measure, Stud finder,... -
Page 5: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any questions regarding the product, please call customer service at 888-3KOBALT (888-356-2258), 8 a.m - 8 p.m., EST, Monday - Sunday. You could also contact us at partsplus@lowes.com. -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. Locate the desired position for the first vertical Post (A) on the exposed wall joist. Mark the location and drill a small pilot hole (1/8 in). Using the top-hole position of the Post (A), use screw (AA) and screw it in place to the wall joist. - Page 7 ASSEMBLY INSTRUCTIONS 4. Place Left Brackets (C) onto the Post (A) as the installation procedure by the picture showing. Using the Hammer hit the Brackets (C) down, ensure the hook touching tighten to the Post (A) as shown, same to the Right Brackets (D).
- Page 8 ASSEMBLY INSTRUCTIONS 7. Place K Steel Rail (E) onto the Post (A) using the Hammer hit the K Steel Rail (E) down, ensure the Rail touching tighten to the Post (A) as shown. NOTE: You can adjust the Rail distance as needed.
-
Page 9: Operating Instructions
Re-locate post distance mounting post distance to be 32-in as required. Follow extreme caution when loading and unloading items from the KOBALT 20 PC Modular Wall Organizer. Weight load capacity is up to 150-lb per shelf evenly distributed; 150-lb per feet for K Steel Rail;... -
Page 10: Warranty
WARRANTY You should never have a problem with your Kobalt Tools. However, if you do, return the item to the place of purchase for a free replacement. No questions asked. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state. The warranty excludes the screws.
