Myriad™ Reveal
(tensioned and non-tensioned, with and without SightLine)
USER MANUAL
240215 Rev B
DL16754

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DA-LITE Myriad Reveal and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LEGRAND DA-LITE Myriad Reveal

Summary of Contents for LEGRAND DA-LITE Myriad Reveal

  • Page 1 Myriad™ Reveal (tensioned and non-tensioned, with and without SightLine) USER MANUAL 240215 Rev B DL16754...

  • Page 2: Important Safety Instructions

    4. Failure to provide adequate structural strength for this component can result in serious personal Da-Lite® is a registered trademark of Legrand AV. All injury or damage to equipment! It is the installer’s rights reserved. responsibility to make sure the structure to which this component is attached can support the weight of all equipment.

  • Page 3: Pre-Installation

    PRE-INSTALLATION INSTALLATION 1. Carefully unpack case and remove from 1. Remove the mounting brackets and mount them to the shipping carton. desired location. 2. Recheck measurements of screen location a. On wall: screw into wall from back (Figure 1) before installation. NOTE: For stud wall mounting, use wood stud (2 by 4) Installation and calibration of the unit should only be for wall mount and metal frame of the building...
  • Page 4 INSTALLATION (CONT.) 6. The case is shipped on its side. Lift the case out of its packaging and carry on its side to prevent damage to the rounded doors (Figure 3). arry case On flat siDes tO Prevent Damage On rOunDeD DOOrs Figure 3 7.
  • Page 5 INSTALLATION (CONT.) 8. Rotate the case down to set into the mounting bracket hook (Figure 5). Caution: ensure the case is engaged with all mounting brackets before releasing ntil Ounting racket eetH Otate OWn tO Outing racket autiOn nsure ase is ngageD WitH Ounting rackets...
  • Page 6 WIRING IN END CAPS Remove End Panel Attach End Panel 1. Push up on the bottom of the panel and lightly 1. Align the tab on the end panel with the slot on the end push the tab down (Figure 7). cap (Figure 9).
  • Page 7 WIRING IN END CAPS (CONT.) 2. Remove the chosen knockout location. 3. The power cable is connected to the plate. Run wires out of the knockout to the power connection 4. Plug the Cat5e cable into the RJ-45 connector (Figure 11). 5.
  • Page 8 ALTERNATE WALL SWITCH FOR FOR 230V SCREENS 230V Wiring Diagram with Optional European Style Wall IMPORTANT NOTE: The European style wall switch is for Switch operation only and CANNOT be used to make limit switch adjustments. Therefore, it is advised to locate the limit Use 3-conductor 20–24 gauge wire to connect European adjustment wall switch in an accessible location.

  • Page 9: Operation Of Screen

    OPERATION OF SCREEN “Up” Operation & Limit Adjustment Wall Switch Button 1. Press “DOWN” button on screen switch and screen “Stop” Button will deploy out of case in downward direction. 2. Press “STOP” button on screen switch and screen “Down” Button will stop if in movement.

  • Page 10: Third Party Control

    THIRD PARTY CONTROL Control Panel A control panel may be connected to the wall switch by using the dry contact Up, Down and Common connections. The control panel must provide a momentary, dry contact closure of at least 1/2 Front of Back of second.

  • Page 11: Screen Adjustment

    SCREEN ADJUSTMENT If general adjustment is needed, please follow the steps below and refer to the Wiring Diagram. 1. Locate the wall switch and remove the cover plate from down buttons, the motor will do a small jog in that the wall switch and remove the switch from the junction direction for fine adjustment of the screen.

  • Page 12: Troubleshooting

    TROUBLESHOOTING SYMPTOM CAUSE SOLUTION Verify 115-125V (or 220-240V). If insufficient voltage, Incorrect line voltage. rewire incoming electric line. Blown fuse. Replace fuse. Tripped circuit breaker. Reset circuit breaker. Screen will not operate and motor does not hum. Check above. Tighten all loose wire connections. Correct any improper connections.
  • Page 13 CONDITIONS FOR TRANSPORTATION AND STORAGE • Temperature: Between 40 - 1000F (5 - 400C) • Make sure the entire package is supported when stored • Relative Humidity: 30% to 70%, non-condensing • Do not stack more than six projection screens on top of each other •...
  • Page 14 LIMITED FIVE-YEAR WARRANTY ON DA-LITE PRESENTATION PRODUCTS Legrand AV Inc. warrants certain Da-Lite branded products to the original purchaser only, to be free from defects in materials and workmanship for a period of five (5) years from the date of purchase by the original purchaser; provided they are properly operated according to Da-Lite's instructions and are not damaged due to improper handling or treatment after shipment from the factory.
  • Page 16 EMEA +31 495 580 840 av.emea.sales@legrand.com APAC +852 2145 4099 av.asia.sales@legrand.com ©2024 Legrand AV Inc. 240215 Rev B 06/24 Da-Lite is a registered trademark of Legrand AV Inc. All other brand names or marks are used for identification purposes and are...
