- Page 1 30751172 / 08-2021 INSTRUCTION BOOK FOR (Tensioned) DescenderPro SightLine...
-
Page 2: Important Safety Instructions
Legrand AV and its affiliated corporations and subsidiaries (collectively "Legrand AV"), intend to make this manual accurate and complete. However, Legrand AV makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this subject to change without notice or obligation of any kind. -
Page 3: Case Dimensions
Case dimensions Tensioned DescenderPro DescenderPro Viewing Area Dimensions (mm) Dimensions (mm) 119 x 190 2378 2348 2329 2107 2178 2148 2129 2040 131 x 210 2578 2548 2529 2319 2378 2348 2329 2240 144 x 230 2778 2748 2729 2533 2578 2548 2529... -
Page 4: Tools Required For Installation
Tools Required for Installation 1/2“ Open Wrench #2 Phillips Screwdriver or Socket Driver Pre-Installation 1. Carefully unpack case from shipping carton. 4. Remove any protective foam covering the outside of the case. 2. Set aside the Installation Kit. Items inside will be used during installation. -
Page 5: Case Installation
Case Installation For a clear step by step instruction, instruction video’s are available on YouTube. You can access this video via: https://www.youtube.com/watch?v=_tNuoLX83qw Or scan the QR code on the right Prepare for installation Remove protection tape (A in fig. 1; back side). NOTE: This tape is to protect the fabric on the role. - Page 6 Case Installation Set the correct vertical position Remove closure panel. There are 3 clips at the inside of the closure panel. Move them to the left with your fingers to release the locking mechanism. NOTE: Hinge mechasim is in the middle Take the closure panel out as shown in picture 5 Set the desired vertical position / bottom limit The motor has 2 holes that can be used to mechanically set...
- Page 7 Connecting DescenderPro Connecting electrical projection screens Important! • The connection of the wiring may only be performed by a electrician. • Make sure that the circuits which will be worked on are completely voltage-free before the electrical connections are made. •...
- Page 8 Connecting DescenderPro Electrical projection screens with built-in RF receiver • Connect a plug (not included) and plug it into the socket. Warning! Projection screens with a built-in remote control must be connected to the electric mains using a plug. The plug must be easily accessible to ensure that the projection screens can be made voltage-free if necessary.
- Page 9 Instructions for use General instructions • the use of the projection screen. • The motor has been specially developed for this projection screen and ensures positions may be set on the motor. This has already been done at the factory. Only change these settings slightly when absolutely necessary.
-
Page 10: Troubleshooting
Troubleshooting Symptom Solution Check for main voltage. Check to make sure if the plug is plugged into the socket. Check to see if the batteries are installed properly in the remote control. The projection screen does not unroll or retract (anymore). The thermal overload cut-out of the motor has been activated and has turned off the motor. - Page 11 P 31.495.580.840 E emea.sales@legrand.com Da-Lite is a registered trademarks of Legrand AV. All other brand names or marks are used for identification purposes and are trademarks of their respective owners. All patents are protected under existing designations. Other patents pending.
