TS5540-MS Micro Spray Valve
User Guide
SPRAY AREA COVERAGE BY 1/4" LONG NEEDLE*
Needle
Part Number
TE723025
TE725025
TE727025
TE730025
TE732025
SPRAY AREA COVERAGE BY 1/2" LONG NEEDLE*
Needle
Part Number
TE723050
TE725050
TE727050
TE730050
*Spray area coverage shown in the charts above is for reference only. Actual
coverage area depends on fluid viscosity and other characteristics.
Needle
0.5"
Size
Spray Area Coverage (Diameter)
.260"
23G x 1/4"
(6.60 mm)
.240"
25G x 1/4"
(6.10 mm)
.200"
27G x 1/4"
(5.08 mm)
.190"
30G x 1/4"
(4.83 mm)
.180"
32g x 1/4"
(4.57 mm)
Needle
0.5"
Size
.280"
23G x 1/2"
(7.11 mm)
.240"
25G x 1/2"
(6.10 mm)
.220"
27G x 1/2"
(5.59 mm)
.200"
30G x 1/2"
(5.08 mm)
Spray Distance
1"
.320"
(8.13 mm)
.280"
(7.11 mm)
.270"
(6.86 mm)
.240"
(6.10 mm)
.220"
(5.59 mm)
Spray Distance
1"
Spray Area Coverage (Diameter)
.430"
(10.92 mm)
.330"
(8.38 mm)
.300"
(7.62 mm)
.280"
(7.11 mm)
9
1.5"
.375"
(9.53 mm)
.350"
(8.89 mm)
.300"
(7.62 mm)
.275"
(6.99 mm)
.260"
(6.60 mm)
1.5"
.600"
(15.24 mm)
.400"
(10.16 mm)
.375"
(9.53 mm)
.350"
(8.89 mm)
