TS5540-MS Micro Spray Valve
User Guide
8.

SPARE PARTS AND ACCESSORIES

TSD1109-3 (NYLON WASHER)
TSD1400-006A (BUNA O-RING)
TSD1109-45 (NYLON WASHER)
TSD1120-2 (RETAINING RING)
TSD400-85 (CUP SEAL)
TSD1003-20 (AIR INLET FITTING)
7509-9010 (NOZZLE ASSY)
7509-1760 (AIR CAP)
T1000583 (LOCKING NUT)
Figure 7.0
15
T1000599 (END CAP)
TSD1150-34 (COMPRESSION SPRING)
TSD1120-15 (RETAINING RING)
TSD1400-208A (BUNA O-RING)
7509-9000 (NEEDLE/PISTON ASSEMBLY)
T1000600 (AIR CYLINDER)
TSD1103-16 (FLUID INLET FITTING)
T1000579 (VALVE BODY)
T1000574 (SPACER)
TSD1400-495B (VITON O-RING)
