TECHCON TS5540-MS User Manual page 16

TS5540-MS Micro Spray Valve
User Guide
PART NUMBER
T1000599
TSD1150-34
TSD1120-15
TSD1400-208A
7509-9000
T1000600
TSD1103-16
T1000579
T1000574
TSD1400-495B
T1000583
7509-1760
7509-9010
TSD1003-20
TSD400-85
TSD1120-2
TSD1109-45
TSD1400-006A
TSD1109-3
NEEDLE GUIDES
5540-MS-23
5540-MS-25
5540-MS-27
5540-MS-30
5540-MS-32
TOOLS
7509-1770
7509-0040
DESCRIPTION
End Cap
Compression Ring
Retaining Ring
Buna Ring
Needle/Piston Assembly
Air Cylinder
Fluid Inlet Fitting
Valve Body
Spacer
Viton O-Ring
Lock Nut
Air Cap
Nozzle Assembly
Air Inlet Fitting
Cup Seal
Retaining Ring
Nylon Washer
Buna O-Ring
Nylon Washer
23-Gauge Needle Guide
25-Gauge Needle Guide
27-Gauge Needle Guide
30-Gauge Needle Guide
32-Gauge Needle Guide
Needle Guide Insertion Tool
Seat Insert Tool
