Summary of Contents for Wurkkos TS23

  • Page 1 User manual Model TS23...
  • Page 2: Specifications

    Wurkkos TS23 is a high lumen led flashlight with electric tail switch design, max 5000 Lumen regulated output, beam distance up to 482 meters. ANSI/NEMA FL1 Chart Mode Turbo High Medium Moon Luminous 5000Lm 1800Lm 800Lm 300Lm 50Lm 10Lm Flux Runtime 2.5h...
  • Page 3 Operation Instructions The TS23 led flashlight with two group mode(Stepped&Tactical), control by one electric tail switch, easy to use by one hand.
  • Page 4: Power Indicator

    Red = battery power is 25%-50% Flashing Red = critical power(<25%), will stay flashlight red when it is on. Low Voltage Protection: If the battery’s voltage is lower than 2.8V, TS23 turns off automatically to avoid battery damage by over discharge.
  • Page 5 TS23 Benutzeranleitung Wurkkos TS23 ist eine hohe Lumen LED-Taschenlampe mit elektrischem Endschalter Design, max 5000 Lumen regulierte Leistung, Strahl Entfernung bis zu 482 Metern. ANSI/NEMA FL1-Tabelle Modus Turbo Hoch Mittel Niedrig Mond Lichtstrom 5000Lm 1800Lm 800Lm 300Lm 50Lm 10Lm Laufzeit 2.5h...
  • Page 6 Betriebsanleitung Die TS23 führte Taschenlampe mit zwei Gruppen-Modus (Stepped & taktische), Steuerung durch eine elektrische Schwanzschalter, einfach zu bedienen mit einer Hand.
  • Page 7 Energie-Anzeige Die LED-Anzeige im Seitenschalter zeigt nach dem Einschalten des TS23 für 5 Sekunden den Stromstatus an. Grün = Batterieleistung 75%-100% Gelb= Batterieleistung 50%-75% Rot = Batterieleistung 25%-50% Rot blinkend = kritische Leistung (<25%), die Taschenlampe bleibt rot, wenn sie eingeschaltet ist.
  • Page 8 TS23 Manuel de l'utilisateur La Wurkkos TS23 est une lampe de poche à LED à haute luminosité avec interrupteur électrique à l'arrière, avec une sortie régulée de 5000 lumens maximum et une distance de rayonnement de 482 mètres. ANSI/NEMA FL1 Tableau...
  • Page 9: Spécifications

    60°C afin d'éviter la surchauffe.  Avertissement de basse tension Instructions d'utilisation La lampe de poche TS23 est dotée de deux modes de groupe (progressif et tactique), contrôlés par un seul interrupteur électrique, facile à utiliser d'une seule main.
  • Page 11 Rouge clignotant = puissance critique (<25%), la lumière reste rouge lorsqu'elle est allumée. Recharge Le TS23 est doté d'un port USB-C pour une recharge pratique. Veuillez le connecter avec le câble USB-C fourni pour le charger - les câbles de type A-C et de type C-C fonctionnent tous les deux.
