- Page 1 WET GRINDER HS200A ASSEMBLY AND OPERATING INSTRUCTIONS Due to continuing improvements, actual product may differ slightly from the product described herein. TO PREVENT SERIOUS INJURY, READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS BEFORE USE.
- Page 2 PRODUCT SPECIFICATIONS Item Description Electrical Requirements 230 VAC / 50 Hz / 120W / 50-180 RPM SAVE THIS MANUAL You will need this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures, parts list and assembly diagram. Keep your invoice with this manual.
- Page 3 grounded in accordance with all codes and ordinances. Never remove the grounding prong or modify the plug in any way. Do not use any adapter plugs. Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. If the tools should electrically malfunction or break down, grounding provides a low resistance path to carry electricity away from the user.
- Page 4 footing and balance enables better control of this product in unexpected situations. Use safety equipment. Wear eye protection when assembling and using this product. TOOL USE AND CARE Disconnect the Power Cord Plug from the power source before making any adjustments, changing accessories, or storing the Wet Grinder.
- Page 5 Maintain a safe environment. Keep the area well lit. Make sure there is adequate surrounding space. Always keep the area free of obstructions, grease, oil, trash, and other debris. Do not use an electrically powered product in areas near flammable chemicals, dusts, and vapors. Never leave the Wet Grinder unattended when it is plugged into an electrical outlet.
- Page 6 and other construction activities, contain chemicals known (to the State of California) to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: lead from lead-based paints, crystalline silica from bricks and cement or other masonry products, arsenic and chromium from chemically treated lumber.
- Page 7 EXTENSION CORDS Grounded tools require a three wire extension cord. Double Insulated tools can use either a two or three wire extension cord. As the distance from the supply outlet increases, you must use a heavier gauge extension cord. Using extension cords with inadequately sized wire causes a serious drop in voltage, resulting in loss of power and possible tool damage.
- Page 8 SYMBOLOGY UNPACKING When unpacking, check to make sure all the parts shown on the Parts List on page 18 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible. OPERATING INSTRUCTIONS NOTE: For additional information regarding the parts listed in the...
- Page 9 into the two mounting holes located at the top of the Wet Grinder. Adjust the Tool Support to the desired height. Then tighten the two Knobs (21) to secure the Tool Support in place. (See Figure E, next page.) To attach the Tool Support for horizontal grinding/honing, insert the Tool Support into the two mounting holes located on the rear side of the Wet Grinder.
- Page 10 TOOL SUPPORT (23) KNOB (21) WATER TANK CHANGE-OVER SPEED CONTROL (41) SWITCH KONB POWER SWITCH (34) KNOB (21) TOOL SUPPORT (23) WATER TANK (41) TOOL SUPPORT HONING WHEEL (23) (27) KNOB TOOL BLADE (15) (NOT INCLUDED) KNOB SUPPORT PLATE (15) (16) ABRASION PASTE (43)
- Page 11 blade (sharp end downward) in the Support Plate. Then firmly tighten the two Knobs to secure the tool blade in place. (See Figure J, previous page.) Adjust the Tool Support (23) so that the Support Plate (16) is no more than 1/16” from the Grinding Stone (19) or Honing Wheel (27).
- Page 12 When necessary, remove the Holder (6) from the Tool Support and readjust (downward) the Tool Support (23) so that the knife blade again lightly touches the Grinding Stone (19) or Honing Wheel (27). (See Figure K, previous page.) When finished grinding/honing the knife blade, remove the Holder (6) from the Tool Support (23).
- Page 13 Grinding Tips: After you have set the angle, turn on the Wet Grinder and begin the grinding process. Press the tool evenly onto the Grinding Stone (19) near the cutting edge, and move the tool crosswise across the Stone. Make sure that at least half the width of the cutting edge comes into contact with the Grinding Stone at any time to avoid damage to the Stone.
- Page 14 INSPECTION, MAINTENANCE, AND CLEANING WARNING! Make sure the Wet Grinder is disconnected from its electrical outlet prior to performing any inspection, maintenance, or cleaning procedures. Before each use: Inspect the general condition of the Wet Grinder. Check for cracked or broken parts, damaged electrical wiring, damaged Grinding Stone or Honing Wheel, and any other condition that may affect safe operation.
- Page 15 To clean: Use a mild detergent or mild solvent to clean the exterior of the Wet Grinder. Do not immerse the machine in liquid. When storing, make sure to store the Wet Grinder in a clean, dry, safe location out of reach of children and other unauthorized people. CAUTION! All maintenance, service, or repairs not mentioned in this manual must only be performed by a qualified service technician.
- Page 16 ASSEMBLY DIAGRAM NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. PAGE 17...
