- Page 1 Portable Printer B-FP3D-GH52-WM-R Owner's Manual...
- Page 2 CAUTION! 1. Only use Toshiba Tec battery packs designed and manufactured for use with the specific printer model. The battery used in this device may present a risk of fire or chemical burn if mistreated. Do no disassemble, heat above +50degC, or incinerate.
- Page 3 Precautions for Handling of Wireless Communication Devices Bluetooth® Module: BT800 Wireless LAN Module: RS9113 Trade Mark Bluetooth is a registered trademark owned by Bluetooth SIG, Inc. and used by Toshiba Tec Corporation under license. Cautions General For all countries and areas This product is a wireless communication device, and the use of this product is restricted to the following countries or areas.
- Page 4 (8) Be sure to use a shielded interface cable. CAUTION! 1. This manual may not be copied in whole or in part without the prior written permission of Toshiba Tec. 2. The contents of this manual may be changed without notification.
- Page 5 Use the specified battery only. Failure to do this may cause fire or electric shock. • Danger of explosion if the battery is incorrectly replaced. Replace the battery only with a Toshiba Tec Corporation, Battery Pack Model B-FP803-BTH-QM-R. Discard used batteries according to the manufacturer's instruction.
-
Page 6: Part Names
Part Names Media sensor Platen Top cover Print head Tear bar Peel-off unit Top cover open button DCIN connector Operation panel Battery lever Strap slot Battery cover USB port Belt clip Print head cleaner M-3x8 screws... -
Page 7: Operation Panel Functions
Operation Panel Functions (11) (12) (10) POWER FEED PAUSE STATUS CHARGE NOTE: Do not touch the operation panel with a sharp object, as its surface is easily damaged. Name/Icon Function/Usage Icons indicating the printer statuses, such as the radio intensity, Liquid Crystal Display battery level, etc. - Page 8 Displayed when an error occurs on the printer. Error Battery level Indicates the battery level in 5 levels. Lights or blinks in green, red, or orange to indicate the printer status. Lights up in green: Normal state Lights up in orange: Low-battery warning state (Operable) ...
- Page 9 Loading a Battery Pack WARNING! 1. If the battery pack leaks liquid or gives out smoke or bad smell, immediately stop using it and keep it away from fire. Failure to do this may cause an explosion or a fire. 2.
-
Page 10: Removing A Battery Pack
Removing a Battery Pack Push the battery lever down in the direction of the arrow, and remove the battery pack from the printer by pulling on the tab. Battery lever Open Battery pack... -
Page 11: Loading The Media
Paper guide Paper lever guide NOTE: Use Toshiba Tec approved media only. Toshiba Tec is not responsible for any print result caused by use of other media When you order media, contact the nearest Toshiba Tec representative. NOTE: Use caution when working with the tear bar. - Page 12 Before using a Peel-off Unit When issuing labels in the peel-off mode, pull out How to put away the peel-off roller the peel-off roller before loading a label roll. 1. Gently press the peel-off unit down, and push it 1.
- Page 13 How to Attach the Accessories CAUTION! 1. Care should be taken not to drop the printer when securing it to your waist or slinging it over your shoulder. 2. For fixing the printer to your belt, the belt width should be 40 mm or less. Use of the other belts may cause the printer to fall off .
-
Page 14: Data Transmission
4. Send data from the host to the printer. NOTE: For details of the interface cable, please consult the nearest Toshiba Tec representative. When disconnecting the USB cable, please follow the instructions of the host system. Wireless Bluetooth 2.1... -
Page 15: Daily Maintenance
Daily Maintenance To help retain the high quality and performance of your printer, it should be cleaned regularly cleaned. CAUTION! DO NOT USE a sharp object to clean the print head or various rollers, as this may cause a print failure or breakdown of the printer. - Page 16 Media sensor window and media path Media sensor window Remove dust or dirt from the media sensor window with a commercially available soft dry brush. Clean the media path with a soft dry cloth. When linerless labels are used, wipe off dirt of residual glues from the media guides after the use of one or two media rolls.
-
Page 17: Troubleshooting
If you cannot solve a problem by means of the following, do not attempt to repair it by yourself. Turn off the printer, remove the battery pack, then contact a Toshiba Tec service representative for assistance. When an error message is displayed When an error message is displayed, follow the respective instruction then press the [PAUSE] button. - Page 18 The flash memory has insufficient area FLASH MEMORY FULL again. If the problem reoccurs, turn off for storing data. the power and contact your Toshiba Tec service representative. Turn off the printer and replace the LOW BATTERY The remaining battery capacity is low.
- Page 19 Load the media properly. The printout is light. Damaged media is used. Load a new media roll. The media is not a Toshiba Tec Use a Toshiba Tec approved media. approved one The [STATUS] lamp is lit or blinking. Clear the error The printer received print data but does not print.
-
Page 20: Printer Specification
Printer Specification Model B-FP3D-GH52-WM-R Media types Label / Tag / Receipt Print method Direct Thermal Resolution 203dpi (8dots/mm) Max 6 inch/s (152 mm/s) Print speed (It depends on the operating environment, print conditions, battery condition, etc.) Effective print width 72mm (2.9") -
Page 21: Media Specification
Media Specification <Labels> Print surface Feed direction Roll method: Labels facing outside <Tag> Black mark (Reverse Side） Print surface Roll method: Receipts facing outside Feed direction... - Page 22 (Unit: mm) Media type Label Receipt With black Without black Mode Batch Strip Item marks marks Min. 10.0 13.0 10.0 – Label pitch Max. 999.9 67.0 999.9 – Min. 10.0 – Label length Max. 997.0 60.0 997.0 – Min. 26.0 –...
-
Page 23: Battery Warning
Care and Handling of the Media CAUTION! Be sure to read carefully and understand the Supply Manual. Use only media that meets the specified requirements. Use of non-specified media may shorten the head life and result in problems with bar code readability or print quality. - Page 24 Do not attempt to effect repairs or modifications to this equipment. If a fault occurs that cannot be rectified using the procedures described in this manual, turn off the power, unplug the machine, and then contact your authorized Toshiba Tec Corporation representative for assistance. Meanings of Each Symbol...
- Page 25 Connect a properly grounded. Extension modify the machine by yourself. grounding wire. disassembling. cables should also be Contact your authorised Toshiba grounded. Fire or electric Tec Corporation representative for shock could occur on assistance. You may be injured by improperly grounded high voltage, very hot parts or equipment.
- Page 26 Since this product uses extremely low power compared with mobile phones, it cannot possibly interfere the pacemakers and defibrillators. However, if the use of this product should be likely to have affected the pacemaker or defibrillator, immediately stop using the product and contact your Toshiba Tec sales agent. ...
- Page 27 Notes This manual may not be copied in whole or in part without the prior written permission of Toshiba Tec Corporation. The contents of this manual may be changed without notification.
