Summary of Contents for ASROCK H810M-X

  • Page 2: Contact Information

    Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp ASRock Incorporation e-mail: info@asrock.com.tw...

  • Page 3: Table Of Contents

    Chapter 1 Introduction Package Contents Specifications Motherboard Layout I/O Panel Block Diagram 802.11ac Wi-Fi Module and ASRock WiFi 2.4/5 GHz Antennas (H810M-X WiFi) Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM) Connecting the Front Panel Header...
  • Page 4 2.14 M.2 WiFi/BT PCIe WiFi Module Installation Guide (H810M-X) 39 2.15 M.2 SSD Installation Guide (M2_1)

  • Page 5: Chapter 1 Introduction

    ASRock’s website without further notice. If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 6: Specifications

    • Supports DDR5 non-ECC, un-buffered memory up to 6400* • Supports Clocked Unbuffered DIMM (CUDIMM) • Max. capacity of system memory: 128GB • Supports Intel® Extreme Memory Profile (XMP) 3.0x * Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/) CPU: Expansion Slot • 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*...
  • Page 7 • 4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front) • 6 x USB 2.0 (4 Rear, 2 Front) * All USB ports support ESD Protection • 2 x Antenna Ports (H810M-X WiFi) Rear Panel • 2 x Antenna Mounting Points (H810M-X) • 1 x PS/2 Mouse/Keyboard Port...
  • Page 8 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 9: Motherboard Layout

    H810M-X WiFi H810M-X 1.3 Motherboard Layout...
  • Page 10 No. Description ATX 12V Power Connector (ATX12V1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1) CPU Fan Connector (CPU_FAN1) Addressable LED Header (ADDR_LED1) Addressable LED Header (ADDR_LED2) ATX Power Connector (ATXPWR1) USB 3.2 Gen1 Header (USB3_3_4) Front Panel Type C USB 3.2 Gen1 Header (USB3_TC1) SPI TPM Header (SPI_TPM_J1) SATA3 Connectors (SATA3_2)(Upper), (SATA3_3)(Lower) USB 2.0 Header (USB_5_6)

  • Page 11: I/O Panel

    H810M-X WiFi H810M-X 1.4 I/O Panel H810M-X WiFi: No. Description No. Description DisplayPort 1.4 USB 3.2 Gen1 Type-A Ports (USB3_1_2) USB 2.0 Ports (USB_1_2) USB 2.0 Ports (USB_3_4) 2.5G LAN RJ-45 Port* PS/2 Mouse/Keyboard Port Line In (Light Blue)** D-Sub Port...
  • Page 12 No. Description No. Description DisplayPort 1.4 USB 3.2 Gen1 Type-A Ports (USB3_1_2) USB 2.0 Ports (USB_1_2) USB 2.0 Ports (USB_3_4) 2.5G LAN RJ-45 Port* PS/2 Mouse/Keyboard Port Line In (Light Blue)** D-Sub Port Front Speaker (Lime)** HDMI Port Microphone (Pink)** * There are two LEDs on each LAN port.

  • Page 13: Block Diagram

    H810M-X WiFi H810M-X 1.5 Block Diagram...

  • Page 14: 802.11Ac Wi-Fi Module And Asrock Wifi 2.4/5 Ghz Antennas (H810M-X Wifi)

    1.6 802.11ac Wi-Fi Module and ASRock WiFi 2.4/5 GHz Antennas (H810M-X WiFi) 802.11ac Wi-Fi + BT Module This motherboard comes with an exclusive 802.11 a/b/g/n/ac Wi-Fi + BT v5.0 module that offers support for 802.11 a/b/g/n/ac Wi-Fi connectivity standards and Bluetooth v5.0.
  • Page 15 H810M-X WiFi H810M-X WiFi Antennas Installation Guide Step 1 Prepare the WiFi 2.4/5 GHz Antennas that come with the package. Step 2 Connect the two WiFi 2.4/5 GHz Antennas to the antenna connectors. Turn the antenna clockwise until it is securely connected.

  • Page 16: Chapter 2 Installation

    Chapter 2 Installation This is a Micro ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 17: Installing The Cpu

    H810M-X WiFi H810M-X 2.1 Installing the CPU 1. Before you insert the 1851-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket.
  • Page 18 Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 19: Installing The Cpu Fan And Heatsink

    H810M-X WiFi H810M-X 2.2 Installing the CPU Fan and Heatsink...

  • Page 20: Installing Memory Modules (Dimm)

    2.3 Installing Memory Modules (DIMM) This motherboard provides two 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs. 2.
  • Page 21 H810M-X WiFi H810M-X...

  • Page 22: Connecting The Front Panel Header

    2.4 Connecting the Front Panel Header Front Panel Wires System Panel Header Power SW (-) RESET SW (+) Power SW (+) RESET SW (-) Power LED (-) HDD LED (-) Power LED (+) HDD LED (+) PANEL1...

  • Page 23: Installing The I/O Panel Shield

    H810M-X WiFi H810M-X 2.5 Installing the I/O Panel Shield...

  • Page 24: Installing The Motherboard

    2.6 Installing the Motherboard...

  • Page 25: Installing Sata Drives

    H810M-X WiFi H810M-X 2.7 Installing SATA Drives Optical Drive SATA Drive SATA Data Cable...
  • Page 26 SATA Power Connector SATA Data Connector...

  • Page 27: Installing A Graphics Card

    H810M-X WiFi H810M-X 2.8 Installing a Graphics Card CLICK!
  • Page 28 Expansion Slots (PCIe Slots) There are 2 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 29: Connecting Peripheral Devices

    H810M-X WiFi H810M-X 2.9 Connecting Peripheral Devices...

  • Page 30: Connecting The Power Connectors

    2.10 Connecting the Power Connectors...

  • Page 31: Power On

    H810M-X WiFi H810M-X 2.11 Power On...

  • Page 32: Jumpers Setup

    2.12 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper (CLRMOS1) (see p.5, No. 15) CLRMOS1 allows you to clear the data in CMOS.

  • Page 33: Onboard Headers And Connectors

    H810M-X WiFi H810M-X 2.13 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard.
  • Page 34 Power LED and Speaker Header (7-pin SPK_PLED1) (see p.5, No. 16) Please connect the chassis power LED and the chassis speaker to this header. SPK_PLED1 SPEAKER DUMMY DUMMY PLED+ PLED+ PLED- Serial ATA3 Connectors Vertical: (SATA3_0) (see p.5, No. 14) (SATA3_1) (see p.5, No.
  • Page 35 H810M-X WiFi H810M-X USB 2.0 Header (9-pin USB_5_6) (see p.5, No. 11) There is one header on this motherboard. This USB 2.0 header can support two ports. USB_5_6 USB_PWR DUMMY USB_PWR USB 3.2 Gen1 Header (19-pin USB3_3_4) (see p.5, No. 7) There is one header on this motherboard.
  • Page 36 Front Panel Type C USB 3.2 Gen1 Header (20-pin USB3_TC1) (see p.5, No. 8) There is one Front Panel Type C USB 3.2 Gen1 Header on this motherboard. This header is used for connecting a USB 3.2 Gen1 module for additional USB 3.2 Gen1 ports.
  • Page 37 H810M-X WiFi H810M-X Chassis Fan Connector (4-pin CHA_FAN1) (see p.5, No. 19) This header allows you to connect Case or Radiator fan. If you plan to connect a 3-pin fan, please connect it to Pin 1-3. CHA_FAN1 FAN_SPEED_CONTROL CHA_FAN_SPEED FAN_VOLTAGE CPU Fan Connector (4-pin CPU_FAN1) (see p.5, No.
  • Page 38 ATX Power Connector (24-pin ATXPWR1) (see p.5, No. 6) This motherboard provides a 24-pin ATX power connector. To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13. ATXPWR1 ATX 12V Power Connector (8-pin ATX12V1) (see p.5, No. 1) This motherboard provides a 8-pin ATX 12V power connector.
  • Page 39 H810M-X WiFi H810M-X SPI TPM Header (13-pin SPI_TPM_J1) (see p.5, No. 9) This connector supports SPI Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity.
  • Page 40 RGB LED Header (4-pin RGB_LED1) (see p.5, No. 17) This RGB header is used to connect RGB LED extension cable which allow users to choose from various LED lighting effects. Caution: Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged.
  • Page 41 H810M-X WiFi H810M-X Addressable LED Headers (3-pin ADDR_LED1) (see p.5, No. 4) (3-pin ADDR_LED2) (see p.5, No. 5) These headers are used to connect Addressable LED extension cables which allow users to choose from various LED lighting effects. Caution: Never install the Addressable LED cable in the wrong orientation; otherwise, the cable may be damaged.
  • Page 42 1. Never install the Addressable LED cable in the wrong orientation; otherwise, the cable may be damaged. 2. Before installing or removing your Addressable LED cable, please power off your system and unplug the power cord from the power supply. Failure to do so may cause damages to motherboard components.
  • Page 43 H810M-X WiFi H810M-X 2.14 M.2 WiFi/BT PCIe WiFi Module Installation Guide (H810M- The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket (Key E) supports type 2230 WiFi/BT PCIe WiFi module.
  • Page 44 Step 3 Gently insert the WiFi/BT PCIe WiFi module into the M.2 slot. Please be aware that the module only fits in one orientation. Step 4 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw as this might damage the module.
  • Page 45 H810M-X WiFi H810M-X 2.15 M.2 SSD Installation Guide (M2_1) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_1, Key M) supports type 2280 PCIe Gen4x4 (64 Gb/s) mode.
  • Page 46 Step 3 Before installing a M.2 SSD, please loosen the screws to remove the M.2 heatsink. *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD. Step 4 Align and gently insert the M.2 SSD into the M.2 slot.
  • Page 47 H810M-X WiFi H810M-X Step 6 Tighten the screws with a screwdriver to secure the M.2 SSD and M.2 heatsink into place in the order shown. Tighten screw opposite the M.2 connector first (2), and then tighten the one next to the M.2 connector (3).

  • Page 48: Copyright Notice

    (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in...
  • Page 49 INTEL END USER SOFTWARE LICENSE AGREEMENT IMPORTANT - READ BEFORE COPYING, INSTALLING OR USING. LICENSE. Licensee has a license under Intel’s copyrights to reproduce Intel’s Software only in its unmodified and binary form, (with the accompanying documentation, the “Software”) for Licensee’s personal use only, and not commercial use, in connection with Intel-based products for which the Software has been provided, subject to the following conditions: (a) Licensee may not disclose, distribute or transfer any part of the Software, and You...
  • Page 50 U.S. GOVERNMENT RESTRICTED RIGHTS. The Software is a commercial item (as defined in 48 C.F.R. 2.101) consisting of commercial computer software and commercial computer software documentation (as those terms are used in 48 C.F.R. 12.212), consistent with 48 C.F.R. 12.212 and 48 C.F.R 227.7202-1 through 227.7202-4. You will not provide the Software to the U.S.

  • Page 51: Fcc Compliance Statement

    FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 52 ASRock follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock product is in line with global environmental regulations. In addition, ASRock disclose the relevant information based on regulation requirements.
  • Page 53 If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply)
  • Page 54 European Community Radio Equipment Directive Compliance Statement This device complies with directive 2014/53/EU issued by the Commision of the European Community. This equipment complies with EU radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator &...
