  • Page 2: Contact Information

    Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp ASRock Incorporation e-mail: info@asrock.com.tw...

  • Page 3: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Motherboard Layout I/O Panel Block Diagram Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM) Connecting the Front Panel Header Installing the I/O Panel Shield Installing the Motherboard Installing SATA Drives Installing a Graphics Card Connecting Peripheral Devices...

  • Page 4: Chapter 1 Introduction

    ASRock’s website without further notice. If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 5: Specifications

    • Supports DDR5 non-ECC, un-buffered memory up to 6400* • Supports Clocked Unbuffered DIMM (CUDIMM) • Max. capacity of system memory: 128GB • Supports Intel® Extreme Memory Profile (XMP) 3.0x * Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/) CPU: Expansion Slot • 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*...
  • Page 6 H810M-H Audio • 7.1 CH HD Audio (Realtek ALC897 Audio Codec) • Gigabit LAN 10/100/1000 Mb/s • Realtek RTL8111H Chipset: • 4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front) • 6 x USB 2.0 (4 Rear, 2 Front)
  • Page 7 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 8: Motherboard Layout

    H810M-H 1.3 Motherboard Layout...
  • Page 9 No. Description ATX 12V Power Connector (ATX12V1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1) CPU Fan Connector (CPU_FAN1) Addressable LED Header (ADDR_LED1) Addressable LED Header (ADDR_LED2) ATX Power Connector (ATXPWR1) USB 3.2 Gen1 Header (USB3_3_4) SPI TPM Header (SPI_TPM_J1) SATA3 Connectors (SATA3_2)(Upper), (SATA3_3)(Lower) USB 2.0 Header (USB_5_6) System Panel Header (PANEL1)

  • Page 10: I/O Panel

    H810M-H 1.4 I/O Panel No. Description No. Description USB 2.0 Ports (USB_1_2) USB 3.2 Gen1 Type-A Ports (USB3_1_2) LAN RJ-45 Port* USB 2.0 Ports (USB_3_4) Line In (Light Blue)** PS/2 Mouse/Keyboard Port Front Speaker (Lime)** HDMI Port Microphone (Pink)** * There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.

  • Page 11: Block Diagram

    1.5 Block Diagram...

  • Page 12: Chapter 2 Installation

    H810M-H Chapter 2 Installation This is a Micro ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 13: Installing The Cpu

    2.1 Installing the CPU 1. Before you insert the 1851-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found. Otherwise, the CPU will be seriously damaged.
  • Page 14 H810M-H Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 15: Installing The Cpu Fan And Heatsink

    2.2 Installing the CPU Fan and Heatsink...

  • Page 16: Installing Memory Modules (Dimm)

    H810M-H 2.3 Installing Memory Modules (DIMM) This motherboard provides two 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs.

  • Page 18: Connecting The Front Panel Header

    H810M-H 2.4 Connecting the Front Panel Header Front Panel Wires System Panel Header Power SW (-) RESET SW (+) Power SW (+) RESET SW (-) Power LED (-) HDD LED (-) Power LED (+) HDD LED (+) PANEL1...

  • Page 19: Installing The I/O Panel Shield

    2.5 Installing the I/O Panel Shield...

  • Page 20: Installing The Motherboard

    H810M-H 2.6 Installing the Motherboard...

  • Page 21: Installing Sata Drives

    2.7 Installing SATA Drives Optical Drive SATA Drive SATA Data Cable...
  • Page 22 H810M-H SATA Power Connector SATA Data Connector...

  • Page 23: Installing A Graphics Card

    2.8 Installing a Graphics Card CLICK!
  • Page 24 H810M-H Expansion Slots (PCIe Slots) There are 2 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 25: Connecting Peripheral Devices

    2.9 Connecting Peripheral Devices...

  • Page 26: Connecting The Power Connectors

    H810M-H 2.10 Connecting the Power Connectors...

  • Page 27: Power On

    2.11 Power On...

  • Page 28: Jumpers Setup

    H810M-H 2.12 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper (CLRMOS1) (see p.5, No.

  • Page 29: Onboard Headers And Connectors

    2.13 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header (9-pin PANEL1) (see p.5, No.
  • Page 30 H810M-H Power LED and Speaker Header (7-pin SPK_PLED1) (see p.5, No. 15) Please connect the chassis power LED and the chassis speaker to this header. SPK_PLED1 SPEAKER DUMMY DUMMY PLED+ PLED+ PLED- Serial ATA3 Connectors Vertical: (SATA3_0) (see p.5, No. 13) (SATA3_1) (see p.5, No.
  • Page 31 USB 2.0 Header (9-pin USB_5_6) (see p.5, No. 10) There is one header on this motherboard. This USB 2.0 header can support two ports. USB_5_6 USB_PWR DUMMY USB_PWR USB 3.2 Gen1 Header (19-pin USB3_3_4) (see p.5, No. 7) There is one header on this motherboard. This USB 3.2 Gen1 header can support two ports.
  • Page 32 H810M-H Front Panel Audio Header (9-pin HD_AUDIO1) (see p.5, No. 17) This header is for connecting audio devices to the front audio panel. HD_AUDIO1 PRESENCE# MIC_RET OUT_RET OUT2_L J_SENSE OUT2_R MIC2_R MIC2_L High Definition Audio supports Jack Sensing, but the panel wire on the chassis must support HDA to function correctly.
  • Page 33 Chassis Fan Connector (4-pin CHA_FAN1) (see p.5, No. 18) This header allows you to connect Case or Radiator fan. If you plan to connect a 3-pin fan, please connect it to Pin 1-3. CHA_FAN1 FAN_SPEED_CONTROL CHA_FAN_SPEED FAN_VOLTAGE CPU Fan Connector (4-pin CPU_FAN1) (see p.5, No.
  • Page 34 H810M-H ATX Power Connector (24-pin ATXPWR1) (see p.5, No. 6) This motherboard provides a 24-pin ATX power connector. To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13. ATXPWR1 ATX 12V Power Connector (8-pin ATX12V1) (see p.5, No. 1) This motherboard provides a 8-pin ATX 12V power connector.
  • Page 35 SPI TPM Header (13-pin SPI_TPM_J1) (see p.5, No. 9) This connector supports SPI Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity.
  • Page 36 H810M-H RGB LED Header (4-pin RGB_LED1) (see p.5, No. 16) This RGB header is used to connect RGB LED extension cable which allow users to choose from various LED lighting effects. Caution: Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged.
  • Page 37 Addressable LED Headers (3-pin ADDR_LED1) (see p.5, No. 4) (3-pin ADDR_LED2) (see p.5, No. 5) These headers are used to connect Addressable LED extension cables which allow users to choose from various LED lighting effects. Caution: Never install the Addressable LED cable in the wrong orientation; otherwise, the cable may be damaged.
  • Page 38 H810M-H 1. Never install the Addressable LED cable in the wrong orientation; otherwise, the cable may be damaged. 2. Before installing or removing your Addressable LED cable, please power off your system and unplug the power cord from the power supply. Failure to do so may cause damages to motherboard components.

  • Page 39: Wifi/Bt Pcie Wifi Module Installation Guide

    2.14 M.2 WiFi/BT PCIe WiFi Module Installation Guide The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket (Key E) supports type 2230 WiFi/BT PCIe WiFi module. * The M.2 socket does not support SATA M.2 SSDs. Installing the WiFi/BT module Step 1 Prepare a type 2230 WiFi/BT PCIe...
  • Page 40 H810M-H Step 3 Gently insert the WiFi/BT PCIe WiFi module into the M.2 slot. Please be aware that the module only fits in one orientation. Step 4 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw...

  • Page 41: Ssd Installation Guide (M2_1)

    2.15 M.2 SSD Installation Guide (M2_1) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_1, Key M) supports type 2280 PCIe Gen4x4 (64 Gb/s) mode. Installing the M.2 SSD Step 1 Prepare a M.2 SSD.
  • Page 42 H810M-H Step 3 Align and gently insert the M.2 SSD into the M.2 slot. Please be aware that the M.2 SSD only fits in one orientation. Step 4 Ensure that the notch at the end of the M.2 SSD aligns with the nut.

  • Page 43: Copyright Notice

    (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in...
  • Page 44 INTEL END USER SOFTWARE LICENSE AGREEMENT IMPORTANT - READ BEFORE COPYING, INSTALLING OR USING. LICENSE. Licensee has a license under Intel’s copyrights to reproduce Intel’s Software only in its unmodified and binary form, (with the accompanying documentation, the “Software”) for Licensee’s personal use only, and not commercial use, in connection with Intel-based products for which the Software has been provided, subject to the following conditions: (a) Licensee may not disclose, distribute or transfer any part of the Software, and You...
  • Page 45 U.S. GOVERNMENT RESTRICTED RIGHTS. The Software is a commercial item (as defined in 48 C.F.R. 2.101) consisting of commercial computer software and commercial computer software documentation (as those terms are used in 48 C.F.R. 12.212), consistent with 48 C.F.R. 12.212 and 48 C.F.R 227.7202-1 through 227.7202-4. You will not provide the Software to the U.S.

  • Page 46: Fcc Compliance Statement

    FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 47 ASRock follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock product is in line with global environmental regulations. In addition, ASRock disclose the relevant information based on regulation requirements.
  • Page 48 If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply)
  • Page 49 BSMI 限用物質及元素清單 限用物質及其化學符號 單元 鉛 (Pb) 鎘 (Cd) 汞 (Hg) 六價鉻 (Cr 多溴聯苯 (PBB) 多溴聯苯醚 (PBDE) 電路板 電子元件 線材 配件 備考 1.〝超出 0.1 wt %〞及〝超出 0.01 wt %〞係指限用物質之百分比含量超出百分比含量 基準值。 備考 2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。 備考 3.〝－〞係指該項限用物質為排除項目。...
  • Page 50 China RoHS 电子信息产品污染控制标示 依据中国发布的「电子信息产品污染控制管理办法」及 SJ/T 11364-2006「电子信息产 品污染控制标示要求」，电子信息产品应进行标示，藉以向消费者揭露产品中含有的 有毒有害物质或元素不致发生外泄或突变从而对环境造成污染或对人身、财产造成严 重损害的期限。依上述规定，您可于本产品之印刷电路板上看见图一之标示。图一中 之数字为产品之环保使用期限。由此可知此主板之环保使用期限为 10 年。 图一 有毒有害物质或元素的名称及含量说明 若您欲了解此产品的有毒有害物质或元素的名称及含量说明，请参照以下表格及说明。 有害物质或元素 部件名称 铅 (Pb) 镉 (Cd) 汞 (Hg) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 印刷电路板 及电子组件 外部信号连 接头及线材 以上表格依据 SJ/T 11364-2014 的规定编制。 O: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。 X: 表示该有害物质至少在该部件的某一均质材料中的含量超出...
