- Page 1 Model: T5B-110.1 T5B-220.1 USER MANUAL CENTR INSPIRE SERIES T5 & IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY Record Serial Number Here MADE IN CHINA 80364-EN-V2025-01-17...
-
Page 3: Product Warranty
WELCOME Welcome to Centr and thanks for your purchase. We're happy to have you. Please inspect your product and contact us right away if anything is missing or damaged. Your equipment also comes with access to Centr's digital membership, unlocking tools that will fuel your active lifestyle and well-being. -
Page 5: Table Of Contents
TABLE OF CONTENTS PRODUCT WARRANTY..................3 IMPORTANT SAFETY INSTRUCTIONS............6 WARNING AND SERIAL NUMBER LABELS..........8 USE OF SAFETY KEY..................10 GROUNDING INSTRUCTIONS (FOR 110V MACHINES) ......11 GROUNDING INSTRUCTIONS (FOR 220V MACHINES)......12 HARDWARE PACK.....................13 ASSEMBLY......................14 FEATURES OVERVIEW..................20 BEFORE YOU BEGIN..................21 FOLDING AND MOVING INSTRUCTIONS..........23 MAINTENANCE AND CARE................25 ADJUSTING THE RUNNING BELT...............26 LUBRICATING THE RUNNING BELT............27... -
Page 6: Important Safety Instructions
Never operate the treadmill if it has a damaged power cord or electrical plug, if it is not working properly, if it has been dropped or damaged, or partially immersed in water. Contact Centr properly, if it has been dropped or damaged, or partially immersed in water. Contact Centr customer service. - Page 7 ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE- EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. Centr, LLC. DOES NOT ASSUME ANY RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
-
Page 8: Warning And Serial Number Labels
80313-V2024-12-02 Manufacture according to MFG-001 specification, supplied by CENTR Engineering. WARNING AND SERIAL NUMBER LABELS WARNING / AVERTISSEMENT / ADVERTENCIA / WARNUNG 80340-V2024-11-27 HEART RATE MONITOR MAY BE INACCURATE. STOP IMMEDIATELY IF YOU FEEL FAINT. Manufacture according to MFG-001 specification, LE MONITEUR DE FRÉQUENCE CARDIAQUE PEUT ÊTRE IMPRÉCIS. - Page 9 80392-V2024-12-10 Manufacture according to MFG-001 specification, supplied by CENTR Engineering. HOME USE TREADMILL. For Consumer Use Only. Manufacturer / Fabricant / HEALTH IN MOTION LLC Fabricante / Hersteller TAPIS ROULANT À USAGE DOMESTIQUE. Pour usage grand public uniquement. CINTA DE CORRER PARA USO DOMÉSTICO. Solo para uso del consumidor.
-
Page 10: Space Requirements
SPACE REQUIREMENTS This treadmill requires a minimum amount of floor space to safely operate. Keep a minimum open area of 2 m (78 in) behind the treadmill, and 0.6 m (24 in) on both sides. A space of 0.3 m (12 in) in the front is recommended for access to the power cord and switch. -
Page 11: Grounding Instructions (For 110V Machines)
GROUNDING INSTRUCTIONS (FOR 110V MACHINES) This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This treadmill is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 12: Grounding Instructions (For 220V Machines)
GROUNDING INSTRUCTIONS (FOR 220V MACHINES) This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This treadmill is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 13: Hardware Pack
HARDWARE PACK (NOT TO SCALE) HARDWARE STEP 3 STEP 2 6X Bolt, M8X25 (1) 2X Bolt, M8X25 (1) STEP 5 STEP A 3X Bolt, M6X10 (2) 4X Bolt, M8X15 (17) 1X #5 & #6 Allen Wrench 80351-EN-V2024-09-20 187 mm 80364-EN-V2025-01-17 Pg. -
Page 14: Assembly
ASSEMBLY WARNING Do not remove the Packing Strap until instructed. Do not lift the treadmill without the Packing Strap securing the Running Deck to the Base Frame Assembly. Failure to do so may result in injury or damage to property. NOTE: It is recommended to have at least 2 people for unboxing and assembling the treadmill. - Page 15 STEP 2 - Lift the Left and Right Uprights until the holes at the bottom are aligned on the Base Frame Assembly, and install the hardware. DO NOT FULLY TIGHTEN THE HARDWARE UNTIL INSTRUCTED. WARNING The Console Base Assembly is loose and can pivot down onto the Uprights. Keep fingers away from both ends of the Upright tubes.
- Page 16 STEP 3 - Pivot the Console Base until the holes align, and install the hardware to secure it. WARNING Keep fingers away from the ends of the Upright tubes when pivoting the Console Base Assembly. A second person to safely hold the Console Base Assembly during this step is recommended. Console Base Assembly Left Upright Right Upright...
- Page 17 STEP 4 - TIGHTEN ALL HARDWARE FROM PREVIOUS STEPS. The Left and Right Upright Covers have two tabs that secure them to the Uprights. Slide the tabs of the appropriate Upright Cover onto the Upright, and then push into place. Tabs Right Upright Left Upright...
- Page 18 STEP 5 - Route the Cable up into the Console Mast while sliding it down onto the Console Base Assembly. Only pull the Cable out enough to route it into the Console Mast. Be sure not to crimp or cut any Cables.
- Page 19 Console Assembly. If needed, the Console User Manual can be found by scanning the appropriate QR Code. 80322-EN 80323-EN FOR T5S FOR T5 CENTR INSPIRE SERIES CENTR INSPIRE SERIES 15.6” TOUCHSCREEN 15” TOUCH KEY LED DISPLAY 80364-EN-V2025-01-17 Pg. 19...
-
Page 20: Features Overview
FEATURE OVERVIEW CHARGING TRAY WATER BOTTLE HOLDER CONSOLE KEYPAD STORAGE POCKET INCLINE CONTROLS AND DISPLAY SIDE HANDRAILS SPEED CONTROLS AND DISPLAY SAFETY KEY RUNNING BELT RUNNING DECK TRANSPORT WHEEL SIDE PLATFORM BELT ADJUSTMENT BOLTS Pg. 20 80364-EN-V2025-01-17... -
Page 21: Before You Begin
5. Play the desired audio on the device and adjust the volume with the console. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc., and any use of such marks by Centr, ® LLC, is under license. Other trademarks and trade names are those of their respective owners. - Page 22 Paired Devices screen. 4. The app will search for available devices, and will provide an available list. 5. Tap on “Centr-T5-XXXXXX” to select it. 6. The app will show that it is connected to the treadmill. 7. Tap OK.
-
Page 23: Folding And Moving Instructions
FOLDING AND MOVING INSTRUCTIONS FOLDING This treadmill is designed to be folded when not in use, to save floor space and allow for easy transport. Before folding the treadmill, be sure that the Incline is set to 0, the Power switch is in Off position, and the power cord is removed from the outlet and machine. - Page 24 MOVING Before moving the treadmill, be sure that the deck is securely folded, and the power cord is removed from the outlet and machine. WARNING The treadmill may be moved by one or more people depending on their physical abilities. Be sure that you and others are all physically fit and able to safely move the machine.
-
Page 25: Maintenance And Care
MAINTENANCE AND CARE WARNING The safe operation of the machine can only be maintained when the equipment is regularly examined for damage and wear. It is the sole responsibility of the user/owner to ensure that regular maintenance and inspections for damage and wear are performed. Special attention should be given to components which are most susceptible to wear. -
Page 26: Adjusting The Running Belt
ADJUSTING THE RUNNING BELT The running belt is properly adjusted at the factory but may loosen or change over time. It is important to properly adjust the running belt so it has the right tension and is centered on the deck, without drifting to one side. -
Page 27: Lubricating The Running Belt
LUBRICATING THE RUNNING BELT The pre-lubricated running belt on this treadmill should run approximately 5592 miles IMPORTANT NOTE: (9000 km) before the belt and deck need to be inspected for lubrication. After the initial break in period, lubricating the running deck and belt is essential as the friction between the two affects the life span and function of the treadmill. -
Page 28: Troubleshooting
TROUBLESHOOTING When the treadmill electronics detect a problem or a potential problem, the HR window in the center of the console keypad will display one of the Error Codes in the following table. WARNING Always unplug the treadmill from the electrical outlet before cleaning, lubricating or repairing the unit. ERROR CODE POSSIBLE SOLUTION(S) E00 - No Error... - Page 29 TROUBLESHOOTING WARNING Always unplug the treadmill from the electrical outlet before cleaning, lubricating or repairing the unit. ERROR CODE POSSIBLE SOLUTION(S) E17 - Lift Motor Calibration Error 1. Check that the incline adjustment motor cable is properly connected. 2. Re-calibrate the incline motor. E21 - Motor Control Board Save Turn off the power using the On/Off switch.
- Page 30 Pg. 30 80364-EN-V2025-01-17...
- Page 31 80364-EN-V2025-01-17 Pg. 31...
- Page 32 centr.com...
