SELF-CONTAINED/MODULAR CUBER

INSTRUCTION MANUAL

(original instructions)

Telford 70, Stafford Park 7, Telford, Shropshire, TF3 3BQ, UK

IM-21CPE

IM-30CPE

IM-30CWPE

IM-45CPE

IM-45PE

IM-45WPE

IM-65PE

IM-65WPE

IM-100PE

IM-130CPE

IM-130PE

IM-130WPE

IM-130APE

IM-240PE

IM-240WPE

IM-240APE

IM-240AWPE

IM-240DPE

IM-240DWPE

IM-240XPE

IM-240XWPE

L1M113201

Rev01 (1224)

Table of Contents

Need help?

Do you have a question about the IM-21CPE and is the answer not in the manual?

Questions and answers

Summary of Contents for Hoshizaki IM-21CPE

Page 1 IM-21CPE SELF-CONTAINED/MODULAR CUBER IM-30CPE IM-30CWPE IM-45CPE IM-45PE IM-45WPE IM-65PE INSTRUCTION MANUAL IM-65WPE IM-100PE (original instructions) IM-130CPE IM-130PE IM-130WPE IM-130APE IM-240PE IM-240WPE IM-240APE IM-240AWPE IM-240DPE IM-240DWPE IM-240XPE IM-240XWPE L1M113201 Rev01 (1224) Telford 70, Stafford Park 7, Telford, Shropshire, TF3 3BQ, UK...
Page 2: Table Of Contents
ENGLISH IMPORTANT SAFETY INFORMATION ................1 INSTALLATION INSTRUCTIONS ................3 CONSTRUCTION ....................3 ACCESSORIES ....................3 UNPACKING ....................... 4 LOCATION ......................5 INSTALLATION ....................7 ELECTRICAL CONNECTIONS ................9 WATER SUPPLY AND DRAIN CONNECTIONS ..........10 OPERATING INSTRUCTIONS ................13 START UP ......................
Page 3: Important Safety Information
ENGLISH IMPORTANT SAFETY INFORMATION Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, or damage to the unit. Indicates a hazardous situation which, if not avoided, could result in death or WARNING serious injury.
Page 4 ENGLISH WARNING This is a commercial icemaker, and should be destined only to be used for the purpose for which it has been expressly designed. Any other use should be considered improper and therefore dangerous. The manufacturer will not be held liable or responsible for any damage caused by improper, incorrect and unreasonable use.
Page 5: Installation Instructions
ENGLISH I. INSTALLATION INSTRUCTIONS 1. CONSTRUCTION [IM-21/30/45/65/100/130/240PE/WPE] [IM-130CPE] [IM-240APE/AWPE] [IM-240DPE/DWPE, IM-240XPE/XWPE] 2. ACCESSORIES Instruction Inlet Hose Outlet Hose Scoop Manual Connector Ice Chute (X type) Ice Chute (A type) Quick Start Hose Cover Guide Clamp Bolt Mounting Bracket ½-¾ Nipple ¾-¾...
Page 6: Unpacking
The presence of UVC and Drain Pump components varies by model; they may be pre- installed or omitted depending on the specific configuration. * Qty.1 Hose clamp included in all drain pump models, IM-21CPE does not include legs. Compatibility kits are sold separately.
Page 7: Location
Modular models: by opening the front panel and removing bin control from drain pan. [Self-Contained Models] [Modular Models] [IM-21/30/45/65/100/130/240PE/WPE/CPE] [IM-130/240APE/AWPE/DPE/DWPE] Note: Modular models need a storage bin, Hoshizaki recommends the following: a. A type (IM-130/240APE/AWPE): B-140SA b. D/X type (IM-240DPE/DWPE/XPE/XWPE): B-340SA 4. LOCATION WARNING This icemaker is not intended for outdoor use.
Page 8 ENGLISH IMPORTANT Normal operating ambient temperature should be within 1°C to 40°C. Water connection is cold water only. Operation of the icemaker, for extended periods, outside of these normal temperature ranges may affect production capacity. Allow the clearance specified below for proper air circulation and ease of maintenance and/or service should they be required.
Page 9: Installation
ENGLISH 5. INSTALLATION CAUTION Incorrect installation can cause harm to people, animals or other items, for which the manufacturer cannot be held responsible. a. Self-Contained Model 1) Place the icemaker in the selected permanent site. 2) Secure the adjustable legs (accessories) into the tapped holes on the underside icemaker, level the unit in both the left-to-right and front-to-rear directions.
Page 10 ENGLISH c. Stacking Modular Model – D / X Type NOTICE Check the icemaker models. A D-type icemaker and an X-type icemaker will be required for stacking two icemakers. A D-type icemaker and two X-type icemakers will be required when stacking three icemakers.
Page 11: Electrical Connections
ENGLISH 6) Attach the upper or middle unit on the lower unit. 7) Secure the two units with the two bolts and the two nuts provided. 8) Place the ice chute (lower or middle unit accessory) and secure it to the bracket with the two screws. 9) Connect the leads (with three-way plug) located in the lower unit wiring channel to the upper unit receptacle, unplugged in the above step 6).
Page 12: Water Supply And Drain Connections
Installation of an external filter or softener is recommended. Contact your local water treatment professional or Hoshizaki service agent. b) Change to the “full drain flush” mode is recommended. Contact your local Hoshizaki service agent. A plumbing permit and services of a licensed plumber may be required in some areas.
Page 13 ENGLISH [Gravity Drain Models] The icemaker drain is gravity flow, so ensure drain hose has an adequate pitch or fall, as shown. To prevent a backflow into the storage bin, the outlet hose must be laid as shown. [Except IM-130CPE] R3/4 1) Hand tighten grey flexible outlet hose (accessory) onto the R3/4 fitting on the rear of the icemaker as indicated, ensuring rubber...
Page 14 [Condensing Water Supply - Water-Cooled Models] Hoshizaki recommends that the water-cooled condenser should be connected to a closed circuit recirculating type cooling system utilizing a tower, water chiller or similar. Water make up should be via a ball valve/break tank arrangement.
Page 15: Operating Instructions
ENGLISH When selecting a cooling tower, refer to the following peak values of heat flow in the condenser: Model: IM-30CW/45W: 295-760W IM-65W 875W IM-100/130W 1165W IM-240W 5235W Select a circulating pump referring to the above values of heat flow. Do not use a cascade pump, or the water regulator will vary the flow and stop it during the defrost cycle. [Icemaker Connections] 1) By means of a suitable spanner or wrench, tighten the 1/2-3/4 nipples (accessory) into the Rc1/2 fittings on the rear of the icemaker as indicated.
Page 16: Start Up
ENGLISH * Close the door after removing ice to prevent entrance of dirt, dust or insects into the storage bin. 1. START UP The installer will normally commission the icemaker to start the automatic ice making process. To ensure continuous operation, make sure that: * The water supply tap is on, and * The icemaker is connected to the power supply.
Page 17 4) Either mix 5 litres of water with 18 ml of 5.25% sodium hypochlorite solution in a suitable container, or the recommended Hoshizaki sanitiser as directed. 5) Soak a clean sponge or cloth with the solution, and wipe the bin liner, bin door and slope.
Page 18: Before Calling For Service
* The air filter is clean (air-cooled model). * The cooling water circuit has a proper flow (water-cooled model). For further assistance or advice, contact your local Hoshizaki service agent. 3. DISPOSAL Comply with local regulations regarding disposal of this appliance and its refrigerant gas. Before you scrap the appliance, take off the door to prevent children becoming trapped.
Page 19: Warranty
“warranty period”. The warranty shall be effective from the date of installation. Hoshizaki’s liability under the terms of the warranty are limited and shall exclude routine servicing, cleaning, essential maintenance and/or repairs occasioned by misuse and installations not in accordance with Hoshizaki guidelines.
