- Page 1 User’s Manual SRP-350V/352V THERMAL RECEIPT PRINTER Ver. 1.01 www.bixolon.co.kr...
-
Page 2: Copyright
It is strictly prohibited to copy, store, and transmit the whole or any part of the manual and any property of the product without the prior written approval of BIXOLON Co., Ltd. The information contained herein is designed only for use with this BIXOLON product. - Page 3 SRP-350V/352V Warning Hazardous moving parts Keep fingers and other body parts away Pull the print head lever can be stop all moving parts. IEC 60417-6057 (2011-05) for other moving parts. Mise en garde Les appareils électroniques, tels que les imprimantes, risquent d'être endommagés par l'électricité...
-
Page 4: Compliance Information
SRP-350V/352V Compliance information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. - Page 5 SRP-350V/352V Waste Electrical and Electric Equipment (WEEE) This marking shown on the product or its literature, indicates that is should not be disposed with other household wastes at the end of its working life, To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
-
Page 6: Warning & Caution
Do not connect multiple products to a Only use authentic products from single or faulty power outlet. Use only BIXOLON. The company will not provide grounded power outlets that meet the post-sale support for damaged or other industry standard. Noncompliance may quality issues that any fake cause electric shock or fire. - Page 7 Do not place heavy product, please contact the original objects, liquids, or metals on the place of purchase or through product. This could cause damage to BIXOLON website’s product repair the product or a fire. page (http://www.bixolon.com). Ver. 1.01 - 7 -...
-
Page 8: Manual Introduction
SRP-350V/352V Manual Introduction This manual provides basic information on printers and provides ways to install, use, and check them. In order to protect the safety of users and prevent property damage, be fully familiar with this manual before using the product. Please use it. Manual Symbol Introduction Precaution It describes death, physical injuries, serious financial losses,... -
Page 9: Printer Introduction
SRP-350V/352V Printer Introduction The SRP-350V is a powerful 3-inch (80 mm) thermal printing solution, providing high- quality receipt and ticket at 180 dpi and 203 dpi at 300 mm/sec. Features built-in a market-proven anti-jam guide, media guide for 2-inch or 3-inch printing media, and cost-saving paper reduction function. -
Page 10: Table Of Contents
SRP-350V/352V Table of Contents Copyright ..........................2 WARNING & CAUTION ......................6 Manual Introduction ......................8 Printer Introduction ......................9 1. Content Confirmation ....................11 2. Product Part Names ..................... 12 2-1 Printer Part Names ......................12 2-2 Interface Part Names ..................... 13 2-2-1 USB (Built-in) ....................... -
Page 11: Content Confirmation
SRP-350V/352V 1. Content Confirmation - If there is any part missing, please contact the place of purchase. - The actual part may look different from the image. SRP-350/352V Standard Components Quick Manual Roll Paper AC/DC Adapter Cable Cover Power Cord USB C Type (A to B) Cable Option Components Serial Cable... -
Page 12: Product Part Names
SRP-350V/352V 2. Product Part Names 2-1 Printer Part Names Printer Cover Controller Tear Bar Cutter Cover Cable Cover Cover-Open Button Power Button Ver. 1.01 - 12 -... -
Page 13: Interface Part Names
SRP-350V/352V 2-2 Interface Part Names • Connect the printer to the host computer using the right interface cable that complies with the specifications of the interface. 2-2-1 USB (Built-in) USB Port Pin No. Signal Name Designation (Color) Function Shell Shield Drain Cable Frame Ground VBUS... -
Page 14: Ifj-El Ethernet Interface Card
SRP-350V/352V 2-2-2 IFJ-EL Ethernet Interface Card 1) Dip Switch : Ethernet interface is only available (USB interface disabled) Ethernet Port Dip Switch 2) Dip Switch : USB interface is only available (Ethernet interface disabled) Ethernet Port Dip Switch Ver. 1.01 - 14 -... - Page 15 - Connect or disconnect the interface cable after the printer powered off. - Change the ethernet interface card dip switch after the printer Powered off. - Refer to the utility and network connection manual for Interface connection information. (www.bixolon.com) Ver. 1.01 - 15 -...
-
Page 16: Serial Interface Card (Rs-232C)
SRP-350V/352V 2-2-3 Serial Interface Card (RS-232C) 2-2-3-1 Serial Single Interface Serial Port Pin No. Signal Name Direction Function Frame Ground Output Transmit Data Input Receive Data Output Ready To Send Input Clear To Send Signal Ground Data Terminal Output Ready Connect or disconnect the communication cable while the printer power is off. - Page 17 SRP-350V/352V 2-2-3-2 Serial Dual Interface Card Serial Port (9pin) Serial Port (RJ45) * Printer Side DSUB 9pin RJ45 Signal Name Direction Function Pin No. Pin No. Output Transmit Data Input Receive Data Signal Ground Data Terminal Output Ready Input Clear To Send Output Ready To Send Connect or disconnect the communication cable while the printer...
-
Page 18: Parallel Interface Card (Ieee1284)
SRP-350V/352V 2-2-4 Parallel Interface Card (IEEE1284) Parallel Port Compatibility Pin No. Source Nibble Mode Mode Host nStrobe HostClk Host/Printer Data 0 (LSB) Host/Printer Data 1 Host/Printer Data 2 Host/Printer Data 3 Host/Printer Data 4 Host/Printer Data 5 Host/Printer Data 6 Host/Printer Data 7 (MSB) Printer... - Page 19 SRP-350V/352V Host nInit nInit Printer nFault nDataAvail/Data0,4 Printer DK_Status Printer Host nSelectIn 1284-Active Connect or disconnect the communication cable while the printer power is off. If power is on, your data may be lost. Ver. 1.01 - 19 -...
-
Page 20: Drawer Kick-Out Port
SRP-350V/352V 2-2-5 Drawer Kick-out Port Connect the Drawer Kick-out connection cable to the drawer kick-out port on the rear side of the printer. Drawer kick-out port Pin No. Signal Name Direction Frame Ground Drawer Kick-out Drive Signal 1 Output Drawer Open/Close Signal Input +24V Drawer Kick-out Drive Signal 2... -
Page 21: Installation & Usage
SRP-350V/352V 3. Installation & Usage 3-1 Printer Installation Placings - Allow sufficient space around the printer for proper ventilation. - Do not place objects close to the back or bottom of the printer, which may hinder the air circulation. - Install the printer on a flat and level surface. - Avoid humid environment. -
Page 22: Power Connection
SRP-350V/352V 3-2 Power Connection • Face the flat side of the power cable to the bottom of the printer and connect the power jack to the power port. Power Port Power Jack Ver. 1.01 - 22 -... - Page 23 SRP-350V/352V - Only use a power supply provided by Bixolon. Bixolon shall bear no responsibility for damage caused by using a third-party power supply. - Check the power supply’s label to check its electronic specs. - When removing the power supply, make sure you have a firm grasp of the plug terminal of the power cable and the printer and pull horizontally.
-
Page 24: Inserting And Changing The Paper Roll
SRP-350V/352V 3-3 Inserting and changing the paper roll Use paper roll that complies with the specifications. If you use a paper roll including paper core attached to paper, the paper may not be properly recognized as paper Empty due to not proper releasing of paper. - Page 25 SRP-350V/352V 2) Replace with a new one as shown in the image. 3) Check the orientation of the roll paper when inserting it into the printer. Ver. 1.01 - 25 -...
- Page 26 SRP-350V/352V 4) Pull out a small amount of paper as shown in the picture, and close the Printer Cover. When closing the Printer Cover, hold down the center of printer cover firmly so that paper roll is loaded correctly. 5) Cut out the paper as indicated. Ver.
-
Page 27: Using Controller
SRP-350V/352V 3-4 Using Controller Explanation Power LED The Power LED light is on whenever the printer is on. Error LED is on when there is an error Error LED such as no paper roll, open cover, etc. Paper LED is on when the paper roll is almost used up or there is no paper roll inside. -
Page 28: Mounting Partition
SRP-350V/352V 3-5 Mounting Partition • When using 58mm roll paper, mount the partition in the direction of the arrow as shown below. When installing the partition, align it with the top and bottom grooves and tighten the screws to secure it. Screw Partition - After using 58mm paper, do not change it to a larger paper. -
Page 29: Printer Setting Change
Select print speed table (*2) Refer to the following 1-5 ~ 1-8 Select print density table (*1) Print speed selection table Remark Print speed SRP-350V SRP-352V Level 9 300mm/s 270mm/s Level 8 270mm/s 250mm/s Level 7 250mm/s 230mm/s Level 6... - Page 30 SRP-350V/352V (*2) Print density selection table Print density Remark Level 12 100% Default Level 11 105% Level 10 110% Level 9 Level 8 Level 7 Level 6 Level 5 Level 4 Level 3 Level 2 Level 1 Ver. 1.01 - 30 -...
- Page 31 SRP-350V/352V 4-2 Serial Interface (Memory Switch 8) Memory Switch Function Default Word length 7bit 8bit Parity Selection Parity Check EVEN Hand Shaking XON/XOFF DTR/DSR Baud rate(bps) 8-5 ~ 8-7 (*3) Refer to following table selection Reserved Fixed to OFF (*3) Baud rate(bps) selection table Baud rate(bps) Remark 9600...
-
Page 32: Self-Test
SRP-350V/352V 5. Self-Test The self-test checks whether the printer has any problems. If the self-diagnostics reveal no error in the printer, please see other device or software. If the printer does not run normally, please contact the place of purchase. - Do not open the top cover while the printer is running. - Page 33 SRP-350V/352V (1) If “Continuous SELF-TEST” is selected ① Press the Feed button for less than one second to print the preset page. ② The Self-Test ends automatically as it prints the following line and cuts the paper *** COMPLETED *** ③...
- Page 34 SRP-350V/352V (2) If “VMSM Selection” is selected ① The following lines will be printed when the VMSM opens. ** VMSM Selection ** 0 : Exit and reboot printer 1 : Print current settings 2 : Set Print Density 3 : Set Print Speed 4 : Set Cutting mode 5 : Buzzer Setting 6 : Set Serial Setting...
-
Page 35: Hexadecimal Dumping
SRP-350V/352V 6. Hexadecimal Dumping This function allows experienced users to see exactly what data is coming to the printer. This can be useful in finding software problems. When you turn on the hexadecimal dump function, the printer prints all commands and data in hexadecimal format along with a guide section to help you find specific commands. -
Page 36: Maintenance
SRP-350V/352V 7. Maintenance 7-1 Paper Jam • If paper is stuck, turn the printer ON/OFF and open the Printer Cover to remove the crumpled paper inside the printer. If the cover will not open, please follow the following instructions. 1) Turn the printer OFF. 2) Lift the paper rollout part of the Cutter Cover to remove it. -
Page 37: Cleaning Printer
SRP-350V/352V 7-2 Cleaning Printer • The presence of dust, foreign matter, adhesive matter, or other pollutants inside the printer’s head and internal capacity may undermine printing quality. It is recommended to clean printer at every paper roll change. 1) Open the printer cover and remove the paper currently in use. 2) Residue or contamination of printer head should be wiped out by alcohol for medical. -
Page 38: Specifications
Printing Width 2 inch: 57.5±0.5mm No. of Characters per Line SRP-350V: 42(Font A), 56(Font B), 56(Font C) (Default Value) SRP-352V: 48(Font A), 64(Font B), 64(Font C) SRP-350V: Max. 300 mm/sec Printing Speed SRP-352V: Max. 270 mm/sec Receiving Buffer Size 4K bytes... -
Page 39: Recommended Papers
- The use of papers other than those recommended above may cause damage to the printer’s TPH or degrade the printing quality. BIXOLON is not responsible for the damage caused by non-recommended papers. - If you have to use other products, we recommend that you use papers with a similar level of quality to the recommended ones. -
Page 40: Revision History
SRP-350V/352V Revision History Rev. Date Description 1.00 14-12-2022 1.01 30-05-2024 Delete Ethernet interface content. Ver. 1.01 - 40 -...
