Summary of Contents for Monster MT-MS22111
- Page 1 2.0 CHANNEL SOUNDBAR MODEL: MT-MS22111 User Manual...
-
Page 2: Welcome
Welcome Premium connectivity that fuels modern lifestyle and empowers innovation. A better everyday experience through amazing products. The user manual will provide everything you need to know about using your new product. All our products are produced and tested to stringent standards of performance and safety, and are pleased to provide a 2 Year Warranty with your purchase. -
Page 3: Table Of Contents
Contents Welcome Product Overview Controls and Connections Remote Control Operation Bluetooth ® Troubleshooting Specifications Compliance and Responsible Disposal... -
Page 4: Product Overview
Product Overview What’s in the box: A. 2.0 Channel Soundbar B. Remote Control C. AAA Batteries (2) D. 3.5mm to RCA Cable E. Optical Cable F. AC Power Adaptor G. Wall Mount Kit H. HDMI Adaptor I. Warranty Card J. General Safety Warnings K. -
Page 5: Important Tips
Wall Mount Installation Kit The illustration below shows the contents of the wall mount installation kit. These are the parts you will need when wall mounting the soundbar. Some parts are not shown at the same scale. 1. Plastic anchor (2) 2. -
Page 6: Installation
Installation This soundbar can sit free-standing on a surface, or it can be mounted to a wall. Place on a secure, flat surface. Make sure the soundbar is standing on its rubber pads (on the left and right sides on the bottom of the soundbar) and no other area of the bottom of soundbar is touching the surface. -
Page 7: Wall Mounted
Wall mounting instructions are on the following pages. • Wall-mounted installation must be carried out by qualified personnel only. Incorrect assembly can result in severe personal injury and property damage! If you intend to install this product yourself, you must check for installations such as electrical wiring and plumbing, which may be hidden inside or behind the wall. -
Page 8: Wall Mounting Instructions
Wall Mounting Instructions Use a pencil to make drill hole marks on the wall for the plastic anchors. Make sure the marks are level before drilling. Use a 6mm bit and power drill (not supplied) to drill holes on the marks. 860mm Note: For a wood stud wall, use an electronic stud detector to locate the centre of the framing... -
Page 9: Connect To Power
Connect to Power Make sure the soundbar is switched off at the power outlet until you have finished connecting your cables. Don't forget to plug in the soundbar to the power outlet. Leave the power switched off until installation is finished. PRODUCT OVERVIEW | 9... -
Page 10: Controls And Connections
Controls and Connections Get to Know your Soundbar LED display sound mode (please see page 17 for Front more details) LED display Buttons on the Soundbar button : Press to switch between input sources. : press to play/pause current song. Press and hold for 2 seconds to unpair Bluetooth device. - Page 11 Rear ports on the soundbar The ARC (Audio Return Channel) function allows you to send audio input from an ARC-compliant TV to an HDMI (ARC) SOUND ARC-compliant audio device (e.g. soundbar) without the need for an additional audio cable connection. Connect an Optical cable (included) to the OPTICAL OPTICAL SOUND...
- Page 12 HDMI (ARC) To use the ARC function, make sure the soundbar's TO TV When you use ARC or Optical connection (ARC) socket is connected via HDMI cable (not included) to the to your TV or DVD, the audio output in the TV or DVD settings menu must be set to HDMI (ARC) socket of your ARC compliant TV.
-
Page 13: Remote Control
Remote Control Setup Insert two AAA size batteries according to the polarity AAA size markings (+ / -) inside the compartment. Make sure the batteries included batteries are correctly aligned and properly pushed into place. Precautions When Using Batteries • Do not use old and new batteries together. •... -
Page 14: Using The Remote Control
Using the Remote Control To use the remote, point it towards the remote sensor at the front of the soundbar. The remote will not operate if its path is blocked. The remote has a range of up to about 6 metres from the soundbar at an angle of up to 30 degrees to either side of the sensor, as illustrated below. -
Page 15: Remote Overview
Remote Overview (POWER): Switch the : Switch between the soundbar on or standby input sources : Play the previous/next : Play/pause song song : Enter Bluetooth mode : Turn the 3D sound effect on/off : Turn Bass enhanced audio on/off : Increase the volume level : Decrease the volume level REMOTE CONTROL | 15... -
Page 16: Operation
Operation Input Modes General Operation Input Display HDMI ARC Function Action Bluetooth ® Press and hold the button on the top of the soundbar, Optical Turn the soundbar ON or press the button on the remote control to switch the Coaxial soundbar on. - Page 17 Using the HDMI (ARC) Input • You will need an audio source with a HDMI (ARC) audio output and a HDMI (ARC) audio cable (not included). • Connect the HDMI (ARC) audio cable to the HDMI (ARC) on the audio source and the HDMI ARC input on the soundbar.
-
Page 18: Bluetooth
Select the speaker name: MT-MS22111' from the list of found devices. Note: Only one playback device can be connected to If a mobile phone on which you are playing the speaker. -
Page 19: Bluetooth ® Playback
Bluetooth Playback ® Function Action Press and hold the button on the soundbar or press the Increase the Volume button on the remote control Press and hold the button on the soundbar or press the Decrease the Volume button on the remote control Play/Pause Press on the remote or soundbar. -
Page 20: Troubleshooting
Troubleshooting If you have problems with the soundbar, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 886 649. Problem Solution • Ensure that the power adaptor is properly connected. • Ensure that there is power at the AC outlet. No power •... - Page 21 Problem Solution • Make sure the input source is set to HDMI ARC; the LED will display 'hd'. • Make sure your TV or external device supports ARC function and connect the HDMI cable to the ARC port of the TV or external device. •...
-
Page 22: Specifications
Bluetooth pairing operation range – Up to 10 metres For Technical and Warranty Support distance Bluetooth pairing name MT-MS22111 1300 886 649 monster@tempo.org Bluetooth pairing 0000 monsterproducts.com.au password Distributed by Tempo (Aust) Pty Ltd, Bluetooth version... -
Page 23: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging Compliance The packaging of your product has been This product complies with the Australian selected from environmentally friendly Safety Standard AS/NZS 62368.1 to ensure materials and can usually be recycled. Please the safety of the product. ensure these are disposed of correctly.
