Quick Installation Guide Thank you for choosing DIGIEVER Backup Server (the Server). The following quick guide will lead you to complete the installation and configuration of the product. Please read the following description carefully. Safety Notice The following safety precautions will increase the life of the product. Follow all precautions and instructions.
Compatibility of hard disk with the Server 1 slotted screwdriver and 1 Philips screwdriver *For hard disk compatibility, please check our website https://www.digiever.com/resource/Documents/CompatibleList/HDD/hdd_compatible_list.p Remote PC System Requirements The following are minimum system requirements for a personal computer to operate the Server in better performance: ...
Page 5
Graphics Adapter AGP or PCI-Express, minimum 1024× 768, 16bit colors, 1G memory or above Note: It is highly recommended to use a graphics adaptor which provides higher than resolutions 1024x768 in order to experience the full benefits of the software. ...
Package Contents Backup Server Power Cord Power Adapter RJ45 Network Cable Screws for 2.5” HDD Screws for 3.5” HDD Power Code Bracket...
Hardware Description Front View Rear View Power LED indicator System LED indicators HDD LED indicator Network LED indicator USB backup button with LED Indicator 1 x USB 3.2 Gen 2x1 port (Support auto video backup) HDD 1 HDD 2 HDD 3 HDD 4 2 x 2.5 Gigabit LAN ports...
Hard Disk Installation Please follow the steps as illustrated below to install the hard disk: ① Press the button on the lower portion of the hard disk tray to release the latch. ② Using the latch, gently pull the disk tray out of the disk bay. ③...
Page 9
(2) 2.5-inch hard disks and SSD hard disks: Place the hard disk into the area of the disk tray outlined in red (see picture below). Make sure that the mounting holes on the bottom of the hard disk and disk tray are lined up. Secure the drive with four screws. ④...
⑥ Once the latch is secure, you can lock it by using the disk tray lock. Using a flathead screwdriver, turn the lock counterclockwise to lock the latch mechanism. Turning the lock clockwise will unlock it. Un-lock: Lock: Note: Disk tray locks can be found on DFS-4200 series devices. ...
Turn on the Server and there is a beep to indicate the Server is in booting ③ process. Please wait for minutes until the Server beeps another time. The installation of the Server is complete right now. Securing the Power Cord You can use the provided cord bracket to secure the power cord in place, if you are concerned about the power cord becoming detached when the Server is moved.
Page 12
② Attach the bracket to the power cord as shown in the graphic below ③ Remove the fan screw by unscrewing it counter-clockwise ④ Position the bracket over the hole for the removed fan screw. Secure the bracket in place by replacing the fan screw.
Connection to DIGIEVER Backup Server There are 3 methods to connect to the Server: Local display via HDMI connection Connect to the Server through computer in local network environment Web browser Install NVR Search to quickly find the Server in the local network...
Page 14
Connect to the Server through computer in local network environment Web Browser (Microsoft Edge, Chrome, Firefox, Opera, Safari) Step 1. Connect the Server to the local network (router or switch) Step 2. Enter the Server’s IP address in the web browser. Note: There are 2 methods to set network: Obtain an IP address automatically (System Default) ...
Page 15
Step 4. Download and install NVR-Client.exe, a software application, to execute liveview monitoring and video playback. Note: All browsers will be closed when installing the software application. Install NVR Search to quickly find the Server in the local network Step 1. Please download NVR Search from official website (or request from our sales team) and install it to client’s computer.
Page 16
Connect the computer to the Server directly If you need to use a computer to set up the Server in a non-networked environment, you can use the docking method. Step 1. Please connect the Server and computer via LAN cable. Step 2.
Quick Configuration After login, the system will direct you to set Quick Configuration in 5 steps. Follow the instructions of the Overview of wizard to complete the system setup. Once the five steps of Quick Configuration are complete, you can go “Backup >...
Appendix LED Indicators at Front Panel LED Color & Status Indicate Power Off Blue Power On Power UPS power is from AC power mode to battery mode System is off or in sleep mode when UPS battery is too low Green blinking System goes on or goes off System...
LED Indicators at Rear Panel LED Position LED/State Indicate No connection/ 10Mbps connection LAN1 Speed LAN2 (Top LED) Orange 1G /100Mbps connection Green 2.5G connection LAN Link is not established LAN1 Link/Activity Green LAN Link is established LAN2 (Bottom LED) Green LAN activity is occurring blinking...
