- Page 1 Failover Server Quick Installation Guide DFS-8200-RM Series 2.2.0.10 Information in this document is subject to change without notice. © Copyright 2025, DIGIEVER Corporation. All rights reserved.
-
Page 2: Table Of Contents
Hardware Description ................5 Hard Disk Installation ................6 Connection to DIGIEVER Failover Server ........... 7 Quick Configuration ................11 Appendix ....................12 LED Indicators on Front Panel ..............12 LED Indicators at Rear Panel ..............13... -
Page 3: Safety Notice
Quick Installation Guide Thank you for choosing DIGIEVER Failover Server (the Server). The following quick guide will lead you to complete the installation and configuration of the product. Please read the following description carefully. Safety Notice The following safety precautions will increase the life of the product. Follow all precautions and instructions. -
Page 4: Pre-Installation Notice
1 slotted screwdriver and 1 Philips screwdriver *For hard disk compatibility, please check our website https://www.digiever.com/resource/Documents/CompatibleList/HDD/hdd_compatible_list.p Remote PC System Requirements The following are minimum system requirements for a personal computer to operate the Server in better performance: ... -
Page 5: Package Contents
AGP or PCI-Express, minimum 1024× 768, 16bit colors, 1G memory or above Note: It is highly recommended to use a graphics adaptor which provides higher than resolutions 1024x768 in order to experience the full benefits of the software. Make sure the display DPI setting is set to default at 96DPI ... -
Page 6: Hardware Description
Hardware Description Front View Rear View HDD LED indicator Network LED indicator: LAN 1, LAN 2 Power LED indicator One-touch backup button with LED indicator 2 x USB3.2 Gen 1x1 port (Front) HDD 1 HDD 2 HDD 3 HDD 4 HDD 5 HDD 6 HDD 7... -
Page 7: Hard Disk Installation
Hard Disk Installation Please follow the steps as illustrated below to install the hardware: Take out the disk tray from the Connect the Ethernet cable to Server. the port of 2.5 Gigabit LAN. Connect the power cord to ... -
Page 8: Connection To Digiever Failover Server
Connection to DIGIEVER Failover Server There are 3 methods to connect to the Server: Local display via HDMI connection Connect to the Server through computer in local network environment Web browser Install NVR Search to quickly find the Server in the local network... - Page 9 Connect to the Server through computer in local network environment Web Browser (Microsoft Edge, Chrome, Firefox, Opera, Safari) Step 1. Connect the Server to the local network (router or switch) Step 2. Enter the Server’s IP address in the web browser. Note: There are 2 methods to set network: Obtain an IP address automatically (System Default) ...
- Page 10 Step 4. Download and install NVR-Client.exe, a software application, to execute liveview monitoring and video playback. Note: All browsers will be closed when installing the software application. Install NVR Search to quickly find the Server in the local network Step 1. Please download NVR Search from official website (or request from our sales team) and install it to client’s computer.
- Page 11 Connect the computer to the Server directly If you need to use a computer to set up the Server in a non-networked environment, you can use the docking method. Step 1. Please connect the Server and computer via LAN cable. Step 2.
-
Page 12: Quick Configuration
Quick Configuration After users log in the Server, the system will direct you to set Quick Configuration in 5 steps. Follow the instructions of the Overview of wizard to complete the system setup. Once 5-step Quick Configuration are completed, you can go to Management >... -
Page 13: Appendix
Appendix LED Indicators on Front Panel LED Color & Status Indicate LAN Link is not established Orange LAN Link is established Orange blinking LAN is being accessed Hard disk drive device is not established 1. Hard disk drive is ready to be accessed HDD1 2. -
Page 14: Led Indicators At Rear Panel
LED Indicators at Rear Panel LED Position LED/State Indicate LAN Link is not established LAN1 Link/Activity Yellow LAN Link is established LAN2 (Right LED) Yellow LAN activity is occurring Blinking 10Mbps connection or no connection LAN1 Speed 100Mbps connection LAN2 (Left LED) Green 1000Mbps connection...
