- Page 1 Owner’s Manual Manual del Propietario Manuel d’utilisatio Benutzerhandbuch select language MSC Coaxials Altavoz Coax MSC seleccione el idioma Haut-parleurs choisir la Coaxiaux MSC langue sprache MSC Koax-System auswählen...
-
Page 2: Table Of Contents
Contents Overview ......3 Specifications ......4 Installation ......5 Wiring Configuration ....5 LED Wiring Configuration .... 6 Mounting ........7 Grille Installation ......10 Warranty ......13 Garantía | Garantie ....English 51MSC-b... -
Page 3: Overview
VENTILATION. SUBWOOFERS SHOULD BE MOUNTED WITH AT LEAST 1 INCH (2.5CM) CLEARANCE BETWEEN THE FRONT OF THE SPEAKER AND ANY SURFACE. KICKER PRODUCTS ARE CAPABLE OF PRODUCING SOUND LEVELS THAT CAN PERMANENTLY DAMAGE YOUR HEARING! TURNING UP A SYSTEM TO A LEVEL THAT HAS AUDIBLE DISTORTION IS MORE DAMAGING TO YOUR EARS THAN LISTENING TO AN UNDISTORTED SYSTEM AT THE SAME VOLUME LEVEL. -
Page 4: Specifications
Note: All specifications and performance figures are subject to change. Please visit www.kicker.com for the most current information. To get the best performance from your new KICKER speakers, we recommend using genuine KICKER accessories and wiring. Please allow two weeks of break-in time for the speakers to reach optimum performance. -
Page 5: Installation
CLEAR BLUE WIRE - POSITIVE (+) b. CLEAR BLACK WIRE - NEGATIVE (-) 2. Connect the MSC audio & LED plugs to the MSC. Pro Tip: You’re a KICKER KXM amplifier a few cables... -
Page 6: Led Wiring Configuration
LED Wiring Configuration When wiring the LED lighting, the black lead is +12V and the blue, red, green and white leads are ground. 1. Connect the black LED wire to the positive terminal of the battery. a. Place a 2-amp fuse (not included) no further than 7”... -
Page 7: Mounting
MSC product page KICKER.com. If necessary, pre-drill the mounting screw holes using a 7/64” (2.5mm) bit following the template. Use masking tape to help prevent damage to the paint in the locations to be cut or drilled. - Page 8 Make sure the mounting screws and speed nuts will not puncture the fuel cell, wiring, or interfere with any mechanical parts on the underside of the mounting surface. If the supplied hardware is not applicable to your installation, some other means of securely attaching the speakers to the boat must be used.
- Page 9 Secure speaker to desired location. Possible locations for MSC Speaker Mounting Mounted Stern Mid-Ship Mounted Mounted in the Bow English...
-
Page 10: Grille Installation
The MSC Speaker Grille is a snap-lock configuration that must be correctly oriented to be installed properly. To do this, make sure the KICKER badge logo at the top of the grille is in the same orientation as the KICKER “K” logo located on the tweeter bridge, directly above the tweeter. -
Page 11: Warranty
Should service be necessary under this warranty for any reason due to manufacturing defect or malfunction during the warranty period, KICKER will repair or replace (at its discretion) the defective merchandise with equivalent merchandise. Warranty replacements may have cosmetic scratches and blemishes. - Page 12 Service performed by anyone other than KICKER HOW LONG WILL IT TAKE? KICKER strives to maintain a goal of one-week service for all acoustics (subwoofers, midrange drivers, tweeters, crossovers, etc) returns. Delays may be incurred if lack of replacement inventory or parts is encountered.
-
Page 13: Garantía | Garantie
(“a todo volumen”) en todo sentido. La línea de altavoces y amplificadores KICKER es la mejor del mercado de audio de automóviles y por lo tanto representa el “combustible” para vivir a todo volumen en el área de “estéreos de automóvil” de la vida de nuestros clientes.
