PerfecTron SCH4X2-AC User Manual

Smart energy 13/12th pprocessor fanless computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Version 1.1
SCH4X2-AC
SCH4X2-RAC
SMART ENERGY 13/12th PPROCESSOR
FANLESS COMPUTER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCH4X2-AC and is the answer not in the manual?

Questions and answers

Related Manuals for PerfecTron SCH4X2-AC

Summary of Contents for PerfecTron SCH4X2-AC

  • Page 1 Version 1.1 SCH4X2-AC SCH4X2-RAC SMART ENERGY 13/12th PPROCESSOR FANLESS COMPUTER...

  • Page 2: Safety Information

    SCH4X2-AC/RAC Manual V1.1 Safety Information Electrical safety  To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.  When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.

  • Page 3: Revision History

    V1.1 2024/05/24 Change 2.5G to 1G for IEC-61850- Packing list Item Description Q’ty SCH4X2-AC/RAC Smart Energy Intel 13/12th CPU Fanless Computer Driver CD SSD Tray Key (Option)Accessories Kit for SCH3X2/SCH4X2 Single Machine Rackmount 1 set Bracket (Option) Accessories Kit for SCH3X2/SCH4X2 Dual Machine Rackmount...

  • Page 4: Rohs Compliance

    Equipment) directive 2011/65/EU, to be your trusted green partner and to protect our environment. In order to meet the RoHS compliant directives, Perfectron has established an engineering and manufacturing task force to implement the introduction of green products. The task force will ensure that we follow the standard Perfectron...

  • Page 5: Table Of Contents

    SCH4X2-AC/RAC Manual V1.1 Table of Contents Safety Information ..........................1 Electrical safety ..........................1 Operation safety ..........................1 Statement ............................1 Revision History ..........................2 Packing list ............................2 Ordering information ........................... 2 Chapter 1 : Product Introduction ....................... 6 1.1 Specifications ..........................
  • Page 6 SCH4X2-AC/RAC Manual V1.1 4.4.11 NVMe Configuration ......................31 4.5 Security Page ..........................32 4.5.1 HDD Security configuation ....................33 4.5.2 Secure Boot........................... 34 4.5.3 Key Management ........................35 4.5.4 BIOS Update ......................... 37 4.6 Boot Page ..........................38 4.6.1 (List Boot Device Type) Drive BBS Priorities ................. 39 4.7 Save &...

  • Page 7: Chapter 1 : Product Introduction

    SCH4X2-AC/RAC Manual V1.1 Chapter 1 : Product Introduction 1.1 Specifications System 13th/12th Gen Intel® Raptor Lake-S/Alder Lake-S LGA1700 Socket Processor / Core i9/i7/i5/i3 Processor up to TDP 65W Memory Capacity DDR4 SO-DIMM 3200 MHz up to 64G Chipset Q670E Display Intel®...

  • Page 8: Os Support List

    SCH4X2-AC/RAC Manual V1.1 OS support list Windows Windows® 11 64bit, / Windows® 10 IoT LTSC 64bit (LTSC 2021) / Ubuntu 22.04 / Linux (support by request) Mechanical and Environmental Dimension 220 x 315 x167 mm ( W x D x H ) Operating Temp.

  • Page 9: Sch34X2-A9 Rear Panel I/O Placement

    SCH4X2-AC/RAC Manual V1.1 1.3 SCH34X2-A9 Rear Panel I/O Placement 1.4 SCH4X2-RA9 Front Panel I/O Placement www.perfectron.com...

  • Page 10: Sch4X2-Ra9 Rear Panel I/O Placement

    SCH4X2-AC/RAC Manual V1.1 1.5 SCH4X2-RA9 Rear Panel I/O Placement 1.6 SCH4X2-A9 Mechanical Dimensions Single System : www.perfectron.com...
  • Page 11 SCH4X2-AC/RAC Manual V1.1 Dual System : 1.7 SCH3X2-RD7 Mechanical Dimensions Single System : www.perfectron.com...
  • Page 12 SCH4X2-AC/RAC Manual V1.1 Dual System : www.perfectron.com...

  • Page 13: Chapter 2 : Rear I/O Port

    SCH4X2-AC/RAC Manual V1.1 Chapter 2 : Rear I/O Port 2.1 LAN port LED Indications 1G LAN : www.perfectron.com...

  • Page 14: Chapter 3: System Setup

    SCH4X2-AC/RAC Manual V1.1 Chapter 3: System Setup This chapter provides more detailed information and let you know how to install components into the SCH4X2-A9/RA9 series embedded system. Prior to removing the chassis cover, make sure the unit’s power is off and disconnected from the power sources to prevent electric shock or system damage.
  • Page 15 SCH4X2-AC/RAC Manual V1.1 • Remove the BKT-1 screw of the cover • Remove the BKT-2 screws of the cover www.perfectron.com...
  • Page 16 SCH4X2-AC/RAC Manual V1.1 • 2*PCIex8 Slot www.perfectron.com...
  • Page 17 SCH4X2-AC/RAC Manual V1.1 • Install PCIe Card • Lock BKT-2 screw www.perfectron.com...
  • Page 18 SCH4X2-AC/RAC Manual V1.1 • Lock BKT-1 screw • Lock back cover screws www.perfectron.com...

  • Page 19: Chapter 4: Ami Bios Utility

    SCH4X2-AC/RAC Manual V1.1 Chapter 4: AMI BIOS UTILITY This chapter provides users with detailed descriptions on how to set up a basic system configuration through the AMI BIOS setup utility. 4.1 Starting To enter the setup screens, perform the following steps: ...

  • Page 20: Main Page

    SCH4X2-AC/RAC Manual V1.1 The <F1> key displays the General Help screen. The <F10> key saves any changes made and exits the BIOS setup utility. The <Esc> key discards any changes made and exits the BIOS setup utility. The <Enter> key displays a sub-screen or changes a selected or Enter highlighted option in each menu.

  • Page 21: Advance Page

    SCH4X2-AC/RAC Manual V1.1 Set the Date. Use Tab to switch between Date elements. Default Ranges: Year: 1998-9999 Months: 1-12 Days: dependent on month. Range of Years may vary. System Time Set the Time. Use Tab to switch between Time elements.
  • Page 22 SCH4X2-AC/RAC Manual V1.1 HW Monitor Monitor hardware status S5 RTC Wake Settings Enable system to wake from S5 using RTC alarm. Network Stack Configuration Network Stack Settings. NVMe Configuration NVMe Device Options Settings 4.4.1 Onboard Device Turbo Mode Enable/Disable processor Turbo Mode (requires Intel Speed Step or Intel Speed Shift to be available and enabled.

  • Page 23: Chassis Intrusion

    SCH4X2-AC/RAC Manual V1.1 48M / 52M / 56M /60M / 64M DVMT Total Gfx Mem Select DVMT5.0 Total Graphic Memory size used by the Internal Graphics Device. 128M / 256M / MAX Wake on LAN Enable Enable/Disable integrated LAN to wake the system. Disabled /...
  • Page 24 SCH4X2-AC/RAC Manual V1.1 L3 Cache Size SMX/TXT SMX/TXT Supported or Not 4.4.3 VMD setup menu Enable VMD controller Enable/Disable to VMD controller. Disabled / Enabled www.perfectron.com...

  • Page 25: Trusted Computing

    SCH4X2-AC/RAC Manual V1.1 4.4.4 Trusted Computing Security Device Support Enables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Disabled / Enabled Pending operation Schedule an Operation for the ecurity Device. NOTE: Your Computer will reboot during restart in order to change State of Security Device.

  • Page 26: Serial Port 1 Configuration

    SCH4X2-AC/RAC Manual V1.1 4.4.5 NCT6126D Super IO Configuration Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA) Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB) www.perfectron.com...

  • Page 27: Serial Port 1 Configuration

    SCH4X2-AC/RAC Manual V1.1 4.4.6 Serial Port 1 Configuration Serial Port Enable or Disable Serial Port (COM). Disabled / Enabled Device Settings Device Super IO COM1 Address and IRQ.Read only Change Settings Select an optimal setting for Super IO Device. Auto / IO=3E8h; IRQ=7;...

  • Page 28: Serial Port 2 Configuration

    SCH4X2-AC/RAC Manual V1.1 4.4.7 Serial Port 2 Configuration Serial Port Enable or Disable Serial Port (COM). Disabled / Enabled Device Settings Device Super IO COM2 Address and IRQ.Read only Change Settings Select an optimal setting for Super IO Device. Auto / IO=3E8h; IRQ=7;...

  • Page 29: Hardware Monitor

    SCH4X2-AC/RAC Manual V1.1 4.4.8 Hardware Monitor Hardware Monitor Alert Enable [Disabled If Enabled, POST monitors voltage, temperature, and fan status. If these values are out of range, BIOS display warning message and turn on beep sound. Disabled / Enabled] System Fan Enable (Suppressed if Hardware Monitor Alert is Disabled) If Enabled, POST monitors system fan status.

  • Page 30: S5 Rtc Wake Settings

    SCH4X2-AC/RAC Manual V1.1 4.4.9 S5 RTC Wake Settings Wake system from S5 Enable or disable System wake on alarm event. Select Fixed Time, system will wake on the hr:min:sec specified. Disabled / Fixed Time Wake up hour(Show when Wake system from S5 set to Fixed Time) Select 0-23.

  • Page 31: Network Stack Configuration

    SCH4X2-AC/RAC Manual V1.1 4.4.10 Network Stack Configuration Network stack Enable/Disable UEFI Network Stack. Disabled / Enabled Ipv4 PXE Support (Available when Network stack Enabled) Enable/Disable Ipv4 PXE Boot Support. If disabled IPV4 PXE boot option will not be created. Disabled / Enabled Ipv6 PXE Support (Available when Network stack Enabled) Enable/Disable Ipv6 PXE Boot Support.

  • Page 32: Nvme Configuration

    SCH4X2-AC/RAC Manual V1.1 4.4.11 NVMe Configuration (Device) Here shows the Device Name you installed. A sample screenshot shows below.  www.perfectron.com...

  • Page 33: Security Page

    SCH4X2-AC/RAC Manual V1.1 4.5 Security Page Administrator Password Set Administrator Password User Password Set User Password. HDD Security drive HDD Security Configuration for selected drive Press Enter when selected to go into the associated Sub-Menu. Secure Boot Set User Password.

  • Page 34: Hdd Security Configuation

    SCH4X2-AC/RAC Manual V1.1 4.5.1 HDD Security configuation (Device) Read only www.perfectron.com...

  • Page 35: Secure Boot

    SCH4X2-AC/RAC Manual V1.1 4.5.2 Secure Boot Secure Boot Secure Boot feature is Active if Secure Boot is Enabled. Platform Key (PK) is enrolled and the System is in User mode. The mode change requires platform reset. Disabled / Enabled Secure Boot Mode Secure Boot mode options: Standard or Custom.
  • Page 36 SCH4X2-AC/RAC Manual V1.1 4.5.3 Key Management Factory Key Provision Install factory default Secure Boot keys after the platform reset and while the System is in Setup mode. Disabled / Enabled Restore Factory Keys Force System to User Mode. Install factory default Secure Boot key...
  • Page 37 SCH4X2-AC/RAC Manual V1.1 b)EFI_CERT_X509 (DER) c)EFI_CERT_RSA2048 (bin) d)EFI_CERT_SHAXXX 2.Authenticated UEFI Variable 3.EFI PE/COFF Image(SHA256) Key Source: Factory,External,Mixed Authorized Signatures Enroll Factory Defaults or load certificates from a file: 1.Public Key Certificate: a)EFI_SIGNATURE_LIST b)EFI_CERT_X509 (DER) c)EFI_CERT_RSA2048 (bin) d)EFI_CERT_SHAXXX 2.Authenticated UEFI Variable 3.EFI PE/COFF Image(SHA256)

  • Page 38: Bios Update

    SCH4X2-AC/RAC Manual V1.1 2.Authenticated UEFI Variable 3.EFI PE/COFF Image(SHA256) Key Source: Factory,External,Mixed Export Secure Boot variables Copy NVRAM content of Secure Boot variables to files in a root folder on a file system device Enroll Efi Image Allow the image to run in Secure Boot mode. Enroll SHA256 Hash certificate of a PE image into Authorized Signature Database (db) 4.5.4 BIOS Update...

  • Page 39: Boot Page

    SCH4X2-AC/RAC Manual V1.1 4.6 Boot Page Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535 (0xFFFF) means indefinite waiting. Bootup NumLock State Select the keyboard NumLock state. On / Off Boot Option #1 ~ Boot Option #8 [Sets the system boot order.

  • Page 40: List Boot Device Type) Drive Bbs Priorities

    SCH4X2-AC/RAC Manual V1.1 4.6.1 (List Boot Device Type) Drive BBS Priorities Boot Option #1 Sets the system boot order. Boot Device Name #1 of this type / Disabled www.perfectron.com...

  • Page 41: Save & Exit Page

    SCH4X2-AC/RAC Manual V1.1 4.7 Save & Exit Page Discard Changes and Exit Exit system setup without saving any changes. Save Changes and Reset Reset the system after saving the changes. Restore Defaults Restore/Load Default values for all the setup options.

  • Page 42: Event Logs

    SCH4X2-AC/RAC Manual V1.1 4.8 Event Logs Change Smbios Event Log Settings Press <Enter> to change the Smbios Event Log configuration. View Smbios Event Log Press <Enter> to change the Smbios Event Log records. www.perfectron.com...
  • Page 43 SCH4X2-AC/RAC Manual V1.1 4.8.1 Change Smbios Event Log Setting Smbios Event Log Change this to enable or disable all feature of Smbios Event Logging during boot. Disabled / Enabled Erase Event Log Choose options for erasing Smbios Event Log. Erasing is done prior to any logging activation during reset.
  • Page 44 SCH4X2-AC/RAC Manual V1.1 4.8.2 ViewSmbios Event Log DATE / TIME / ERROR CODE / SEVERITY / COUNT Description: Log Area Reset and Count is applicable only for Multi- Events. By Events. MM/DD/YY HH:MM:SS Smbios 0x16 N/A N/A www.perfectron.com...
