Panasonic DVD-S325EE Service Manual

Specifications
Power supply:
Power consumption:
Power consumption in standby mode:
Dimensions:
Mass:
Signal system:
Operating temperature range:
Operating humidity range:
Discs played [8 cm (3" ) or 12 cm (5" )]:
(1) DVD (DVD-Video, DivX
(2) DVD-R (DVD-Video, MP3
*5,6
DivX )
(3) DVD-R DL (DVD-Video)
(4) DVD-RW (DVD-Video, MP3
*5,6
DivX )
(5) +R/+RW (Video)
(6) +R DL (Video)
(7) CD, CD-R/RW (CD-DA, Video CD, SVCD , MP3
*3,6 *4,6
JPEG , MPEG4
*1 Conforming to IEC62107
AC230 V, 50 Hz
(DVD-S325EE)
AC110-240 V, 50/60 Hz
(DVD-S325GC/GCA/GCS/GCU)
9 W
(DVD-S325EE)
8 W
(DVD-S325GC/GCA/GCS/GCU)
approx. 1 W
430 (W) × 251 (D) × 43 (H) mm
2.2 kg (approx.)
PAL 625/50, PAL 525/60, NTSC
+ 5 to + 35 °C
5 to 90 % RH (no condensation)
*5,6
)
*2,6 *3,6
, JPEG , MPEG4/ASF
*2,6 *3,6
, JPEG , MPEG4/ASF
*1 *2,6
*5,6
, DivX )
DVD-S325EE
DVD-S325GC
DVD-S325GCA
DVD-S325GCS
DVD-S325GCU
DL4.5 Mechanism Series
Color
(S).......................Silver Type
*2 MPEG-1 Layer 3, MPEG-2 Layer 3
*3 Exif Ver2.1 JPEG Baseline files
Picture resolution: between 320 × 240 and 6144 × 4096
pixels (Sub sampling is 4:2:2 or 4:2:0)
*4 MPEG4 data recorded with the Panasonic SD multi cameras
or DVD video recorders
Conforming to SD VIDEO specifications (ASF
standard)/MPEG4 (Simple Profile) video system/G.726 audio
system
*5 DivX 3.11, 4.x, 5.x
GMC (Global Motion Compensation) not supported.
*6 The total combined maximum number of recognizable audio,
picture and video contents and groups: 1000 audio, picture
and video contents and 256 groups.
Video output:
Output level:
Output terminal:
*4,6
,
*4,6
S video output:
,
Y output level:
C output level:
,
Output terminal:
ORDER NO.CHM0608042CE
1 Vp-p (75 Ω )
Pin jack (1 system)/AV
(DVD-S325EE)
Pin jack (1 system)
(DVD-S325GC/GCA/GCS/GCU)
1 Vp-p (75 Ω )
NTSC: 0.286 Vp-p (75 Ω )
PAL: 0.300 Vp-p (75 Ω )
AV
(DVD-S325EE)
© 2006 Matsushita Electric Industrial CO., Ltd. All
rights reserved. Unauthorized
distribution is a violation of law.
DVD Player
copying and
