WARNING
This furnace is equipped with an ignition control
factory enabled for use with Lennox A2L refrigerant
systems.
Disabling
functionality on A2L system is prohibited by safety
codes. Refer to furnace installation instructions for
non-A2L and non-Lennox refrigerant system setup.
WARNING
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional HVAC installer or
equivalent, service agency, or the gas supplier.
Contents
Unit Dimensions .............................................................2
Parts Arrangement..........................................................3
SLP99UHVK Gas Furnace .............................................4
Shipping and Packing List ..............................................4
Safety Information ..........................................................4
Use of Furnace as Construction Heater .........................5
General ...........................................................................6
Installation - Setting Equipment ......................................6
Filters ............................................................................10
Duct System .................................................................10
Pipe Fittings Specifications...........................................13
Joint Cementing Procedure ..........................................14
Venting Practices ..........................................................15
Vent Pipe Guidelines ....................................................15
Gas Piping ....................................................................30
the
refrigerant
detection
INSTALLATION
INSTRUCTIONS
SLP99UHVK
DAVE LENNOX SIGNATURE
COLLECTION GAS FURNACES
UP/FLOW HORIZONTAL AIR DISCHARGE
508587-01
01/2025
THIS MANUAL MUST BE LEFT WITH THE
HOMEOWNER FOR FUTURE REFERENCE
This is a safety alert symbol and should never be
ignored. When you see this symbol on labels or in man-
uals, be alert to the potential for personal injury or death.
As with any mechanical equipment, contact with sharp
sheet metal edges can result in personal injury. Take
care while handling this equipment and wear gloves and
protective clothing.
A thermostat is not included and must be ordered
separately.
• A communicating thermostat must be used in
communicating applications.
• In non-communicating applications, the Lennox
ComfortSense
7500 thermostat may be used, as well
®
as other non-communicating thermostats.
In all cases, setup is critical to ensure proper system
operation.
Field
wiring
for
communicating applications is illustrated in diagrams,
which begin on Page 35
Electrical .......................................................................33
Ignition Control .............................................................41
Low GWP Application ...................................................46
Blower Data ..................................................................49
Unit Start-Up .................................................................54
Gas Flow ......................................................................55
Operating Pressure Signal Measurement ....................55
Proper Combustion.......................................................57
High Altitude Information ..............................................57
Other Unit Adjustments.................................................57
Heating Sequence of Operation ...................................58
Service..........................................................................60
Repair Parts List ...........................................................62
Configuring Unit Size Codes ........................................63
Unit Set Up Check List .................................................72
Page 1
®
CAUTION
NOTICE
both
communicating
and
