S e r v i c e L i t e r a t u r e
SLP99UHV series units are high-efficiency upflow, hori-
zontal right and left) gas furnaces equipped with variable
capacity gas valve, variable speed combustion air inducer
and variable speed indoor blower motor. All models are
designed only for direct vent (dual pipe) venting system.
SLP99UHV units are available in heating capacities from
66,000 to 132,000 Btuh (19.3 to 38.6 kW) and cooling ap-
plications from 2 to 5 tons (7.0 kW to 17.5 kW). Refer to
Engineering Handbook for proper sizing.
Units are factory-equipped for use with natural gas. Kits
are available for conversion to LPG operation. SLP99UHV
models include a SureLight
control that can be used with a Lennox communicating
thermostat as part of a communicating comfort system.
All SLP99UHV units meet the California Nitrogen Oxides
(NOx) Standards and California Seasonal Efficiency re-
quirements.
All specifications in this manual are subject to change.
Procedures outlined in this manual are presented as rec-
ommendations only and do not supersede or replace local
or state codes. In the absence of local or state codes, the
guidelines and procedures outlined in this manual (except
where noted) are recommendations only and do not con-
stitute code.
