SERVICE MANUAL
COMPACT VHS CAMCORDER
GR-SXM340U,SXM740U
SPECIFICATIONS
(The specifications shown pertain specifically to the model GR-SXM745)
Camcorder
General
Format
: S-VHS/VHS NTSC standard
Power source
: DC 11 V
(Using AC Adapter)
DC 6 V
(Using battery pack)
Power consumption
Viewfinder on
: 4.0 W
LCD monitor on
: 4.5 W
Video light
: 3.0 W
Signal system
: NTSC-type
Video recording system
Luminance
: FM recording
Color
: Converted sub-carrier direct recording
Conforms to VHS standard
Cassette
:
/
cassette
Tape speed
SP
: 33.35 mm/sec. (1-5/16 ips)
EP
: 11.12 mm/sec. (7/16 ips)
Recording time (max.)
SP
: 40 minutes
EP
: 120 minutes
(with TC-40 cassette)
Operating
temperature
: 0°C to 40°C (32°F to 104°F)
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C (–4°F to 122°F)
Weight
: Approx. 930 g (2.1 lbs)
Dimensions
: 200 mm x 112 mm x 118 mm
(W x H x D)
(7-7/8" x 4-7/16" x 4-11/16")
(with the LCD monitor closed and with the viewfinder
fully tilted downward)
Pickup
: 1/4" format CCD
Lens
: F1.6, f = 3.9 mm to 62.4 mm,
16:1 power zoom lens with auto iris and macro control,
filter diameter 40.5 mm
Viewfinder
: Electronic viewfinder with 0.5" black/white CRT
White balance
adjustment
: Auto/Manual adjustment
This service manual is printed on 100% recycled paper.
COPYRIGHT © 2001 VICTOR COMPANY OF JAPAN, LTD.
LCD monitor
: 3.5" diagonally measured, LCD panel/TFT active
matrix system
Speaker
: Monaural
Connectors
: 1 V (p-p), 75 Ω unbalanced, analog output (via
Video
Video output connector)
Audio
: 300 mV (rms), 1 kΩ analog output
(via Audio output connector)
Digital
: ø3.5 mm, 4-pole, mini-head jack
: Y : 1 V (p-p), 75 Ω, analog output
S-Video
C : 0.29 V (p-p), 75 Ω, analog output
AC Adapter
Power requirement
U.S.A. and Canada : AC 120 V`, 60 Hz
Other countries
: AC 110 V to 240 V`,
50 Hz/60 Hz
Output
: DC 11 V
, 1 A
Optional Accessories
• Battery Packs BN-V12U, BN-V20U, BN-V400U
• A/V (Audio/Video) Cable
• Compact S-VHS (
) Cassettes ST-C-40/30/20
• Compact VHS (
) Cassettes TC-40/30/20
• Active Carrying Bag CB-V7U
Some accessories are not available in some areas. Please consult your
nearest JVC dealer for details on accessories and their availability.
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design
and specifications subject to change without notice.
No. 86656
December 2001
