SERVICE MANUAL
CÁMARA DE VIDEO VHS COMPACTO
For disassembling and assembling of MECHANISM ASSEMBLY, refer to the SERVICE MANUAL No.86700(MECHANISM ASSEMBLY).
ESPECIFICACIONES
Formato
Alimentación
Consumo de energía
Sistema de señales
Sistema de registro de video
Luminancia
Color
Cassette
Velocidad de la cinta
Tiempo máximo de
grabación
Temperatura de
funcionamiento
Margen de humedad
para funcionamiento : 35% a 80%
Temperatura de
almacenamiento
Peso
Los especifiaciones indicadas corresponden al modo SP a menos que se especifique lo contrario. Diseño
y especificaciones sujetos a cambio sin previo aviso.
GR-FC1UM,
VU-FC1K
- GR-FC1UM -
: Norma NTSC VHS
: DC 9 V
: 3,4 W
: Tipo NTSC
: Registro por FM
: Registro directo por
subportadora convertida
Según la norma VHS
: Videocassette
: 33,35 mm/s
: 40 minutos
: 10°C a 40°C
: –20°C a 50°C
: Aprox. 590 g
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LTD
US
- VU-FC1KUS -
Dimensiones
: 65 mm x 115 mm x
(An x Al x Pr)
182 mm
(con el visor
completamente inclinado
hacia abajo)
Fonocaptor
: CCD de 1/6"
Objetivo
: F3,5, f = 3.2 mm
Ajuste del balance del
blanco
: Automático
Accesorios opcionales
• VHS (
) Compacto (cassettes VHS-C)
TC-40/30/20
• Bolso CB-V7U
• Adaptador de Cassete C-P7U
Algunos accesorios no se encuentran disponibles
en ciertas áreas. Por favor consulte a su agente
más cercano de JVC antes de comprar los
accesorios opcionales.
GR-FC1UM M3A1
VU-FC1KUS M3ACC
No.86744
2003/05

Advertisement

Table of Contents
loading

Related Manuals for JVC GR-FC1UM

Summary of Contents for JVC GR-FC1UM

  • Page 1 Margen de humedad para funcionamiento : 35% a 80% Algunos accesorios no se encuentran disponibles Temperatura de en ciertas áreas. Por favor consulte a su agente más cercano de JVC antes de comprar los almacenamiento : –20°C a 50°C accesorios opcionales. Peso : Aprox.

  • Page 2: Table Of Contents

    Page Important Safety Precautions 5. PARTS LIST INSTRUCTIONS 5.1 EXPLODED VIEW ..............5-1 GR-FC1UM 5.1.1 PACKING AND ACCESSORY ASSEMBLY <M1> ....5-1 1. DISASSEMBLY 5.1.2 FINAL ASSEMBLY <M2> ............5-2 BEFORE ASSEMBLY AND DISASSEMBLY ......1-1 5.1.3 MECHANISM ASSEMBLY <M3> .......... 5-4 1.1.1 Precautions ................

  • Page 3: Important Safety Precautions

    Important Safety Precautions Prior to shipment from the factory, JVC products are strictly inspected to conform with the recognized product safety and electrical codes of the countries in which they are to be sold. However, in order to maintain such compliance, it is equally important to implement the following precautions when a set is being serviced.
  • Page 4 Safety Check after Servicing Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts and wires have been returned to original positions, Afterwards, perform the following tests and confirm the specified values in order to verify compli- ance with safety standards.

  • Page 5: Disassembly

    SECTION 1 DISASSEMBLY 1.1 BEFORE ASSEMBLY AND DISASSEMBLY 1.1.4 Disconnection of Connectors (Wires) 1.1.1 Precautions Pull both ends of the connector in the arrow direction, remove the lock and disconnect the flat wire. 1. Be sure to disconnect the power supply unit prior to mount- ing and soldering of parts.

  • Page 6: Disassembly Flow Chart

    1.2 ASSEMBLY AND DISASSEMBLY OF CABINET PARTS 1.2.2 Disassembly method 1.2.1 Disassembly flow chart STEP Fig. POINT NOTE PART This flowchart indicates the disassembly step for the cabinet parts and board assembly in order to gain access to item(s) LOWER CASE ASSEMBLY Fig.1-2-1 6(S1) –...
  • Page 7 [6] UPPER CASE (L6) [1] LOWER CASE ASSY 11 (S6) (S1) (S1) (S1) THE SLIDE IS DONE IN THE SAME DIRECTION [7] FRONT COVER SA [8] FRONT FRAME ASSY (S1) AS THE SLIDE SWITCH OF MAIN PWB AND (S1) 12 (S7) LOWER CASE IS INSTALLED .
  • Page 8 ATTACH TERMINALS. TERMINAL 3 FRAME [10] MAIN BOARD ASSY TERMINAL 2 (S10) TERMINALS ARE INSTALLED IN THE 2 (SD10) POSITION OF FIGURE . IT HANGS IT A SIDE VIEW (S10) NOTE THE UNDERMENTIONED CONYENT WHEN SOLDERING. SOLDER ALL SURROUNDINGS IT PUTS THE OF TERMINALS POINT IN THE HOLE .

  • Page 9: Emergency Display

    1.3 EMERGENCY DISPLAY Example (in case of the error number E01): Whenever some abnormal signal is input to the mechacon CPU, an error number (E01, as an example) is displayed in the elec- tronic view finder. In every error status, such the message as UNIT IN REMOVE AND shown below alternately appear over and over.

  • Page 10: Service Note

    1.5 SERVICE NOTE Use the following chart to manage to screws.

  • Page 11: Adjustment

    3.4.1 ELECTRICAL ADJUST- MENT WITH PERSONAL COMPUTER is setup and it ad- justs using a service support system. Please contact to DC POWER JVC Service for detail information. SUPPLY • OP BLOCK • EEP ROM (IC102 of MAIN board) •...

  • Page 12: Tools Required For Adjustment

    1,2. Alignment tape 3.2 TOOLS REQUIRED FOR ADJUSTMENT To be used for check and adjustment of interchangeability of the mechanism. Alignment tape Alignment tape MHP-LC MHP-C (Video: Color bar signal, Audio: Non-signal) 3. Cassette torque meter This is used to cheek the back tension and play torque during mechanism adjustment.

  • Page 13: Mechanism Adjustment

    10.Light box assembly 3.3 MECHANISM ADJUSTMENT To be used for adjustment of the camera system. For the us- 3.3.1 TAPE TRANSPORT ADJUSTMENT age of the Light box assembly, refer to the Service Bulletin No. Mechanism adjustment is needed when DRUM ASSEMBLY or a YA-SB-10035.

  • Page 14: Back Tension

    NOTE: To prevent the tape from damage, turn the guide rollers slowly. (7) By operating the tracking button (both in + and - directions) BACK TENSION 0.97x10 - 1.71x10 in the manual tracking mode, vary the output level of the •...

  • Page 15: A/C Head Height & Azimuth

    3.3.4 A/C head height & azimuth 3.3.5 Phase of control head (X value) Remove the exterior parts attached to the UPPER CASE Note: ASSEMBLY so that the screws around the A/C HEAD Remove the exterior parts attached to the UPPER CASE ASSEMBLY can be tighten or loosen.
  • Page 16 VICTOR COMPANY OF JAPAN, LIMITED AV & MULTIMEDIA COMPANY. 12,3-chome,Moriya-cho,Kanagawa-ku,Yokohama,Kanagawa-prefecture,221-8528,Japan Printed in Japan 0305 VP...
