25 Ton Gas-powered
Hydraulic Log Splitter | GUO096
Operator's Manual
Warning: Please read and thoroughly understand all instructions before operating. Failure to follow
safety rules and other basic safety precautions may result in serious personal injury. Keep these
instructions in a safe and easily accessible place so that they can be referred to when needed. Retain
these instructions to assist in future servicing.
superhandyus.com
© SuperHandy All Rights Reserved | Version 1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Super Handy GUO096
Summary of Contents for Super Handy GUO096
- Page 1 25 Ton Gas-powered Hydraulic Log Splitter | GUO096 Operator’s Manual Warning: Please read and thoroughly understand all instructions before operating. Failure to follow safety rules and other basic safety precautions may result in serious personal injury. Keep these instructions in a safe and easily accessible place so that they can be referred to when needed. Retain these instructions to assist in future servicing.
-
Page 2: Table Of Contents
INDEX TECHNICAL SPECIFICATIONS ---------------------------------------------------------------------------------------------------------- 1 SAFETY DEFINITIONS ---------------------------------------------------------------------------------------------------------------------- 2 SAFETY SYMBOLS ----------------------------------------------------------------------------------------------------------------------- 2~3 SAFETY GUIDELINES ------------------------------------------------------------------------------------------------------------------- 4~5 FUEL SAFETY -------------------------------------------------------------------------------------------------------------------------------- 5 CONTROLS AND FEATURES ----------------------------------------------------------------------------------------------------------- 6 PARTS LIST ----------------------------------------------------------------------------------------------------------------------------------- 6 ASSEMBLY --------------------------------------------------------------------------------------------------------------------------------- 7~8 OPERATION ------------------------------------------------------------------------------------------------------------------------------ 9~10 EXPANDED DRAWINGS ----------------------------------------------------------------------------------------------------------------- 12 MAINTENANCE AND STORAGE ------------------------------------------------------------------------------------------------------ 13 WARRANTY---------------------------------------------------------------------------------------------------------------------------- 13... -
Page 3: Safety Definitions
SAFETY DEFINITIONS The purpose of safety symbols is to bring to your attention possible dangers. The safety symbols, and their explanations, deserve your careful attention and review. The safety warnings do not by themselves eliminate any danger. The instructions or warnings as they give are not substitutes for proper accident prevention measures and care while using the product. - Page 4 SYMBOL MANING Always keep feet away from the wedge and the ram. Moving parts can crush or cut. Hot Surface. To reduce the risk of injury or damage, avoid contact with any hot surface. Open Flame alert. Gas and its vapors are extremely flammable and explosive. Keep gas away from open flames, sparks, pilot lights, heat, and other potential ignition sources.
-
Page 5: Safety Guidelines
DANGER indicates a hazardous situation which, if not avoided,will result in serious injury and possibly death. WARNING indicates a potential hazardous situation which, if not avoided, could result in serious injury or death. CAUTION indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. NOTICE indicates information considered important, but not hazard-related (e.g., messages relating to property damaged). -
Page 6: Gas Safety
Rapid retraction of the starter cord will pull hand and arm towards the engine faster than you can let go. Unintentional startup can result in entanglement, traumatic amputation or laceration. Broken bones, fractures, bruises or sprains could result. When starting engine, pull the starter cord slowly until resistance is felt and then pull rapidly to avoid kickback. Parts of the hydraulic circuit (cylinder, pump, valve-body, hoses) can become very hot during operation. -
Page 7: Controls And Features
CONTROLS AND FEATURES 1. Support Leg — Supports log splitter while operating. 2. Splitting Support Hydraulic tank 3. Splitting Support Beam — Both horizontal and vertical. 4. Side Support Frame 5. Splitting Wedge 6. Wedge Protective Cover 7. Hydraulic Cylinder — Converts hydraulic pressure into linear force. 8. -
Page 8: Assembly
ASSEMBLY Recommended tools Two persons are recommended for assembly STEP #1 Recommended tools: Needle nose pliers STEP #2 Recommended tools: Ratchet Wrench (13mm) M8 Nut Hexagon Flange Bolt M8x40mm Hexagon Flange Bolt M8x65mm Tightening torque:22-30 N.m STEP #3 Recommended tools: Ratchet Wrench (13mm) M8 Nut Hexagon Flange Bolt M8x45mm Tightening torque:22-30 N.m... - Page 9 STEP #5 Recommended tools: Ratchet Wrench（21mm） M14 Nut Hexagon Flange Bolt M14x110mm Tightening torque:22-30 N.m STEP #6 Recommended tools: Ratchet Wrench (13mm) M8 Nut Hexagon Flange Bolt M8x105mm Tightening torque:22-30 N.m STEP #7 Recommended tools: Flat head screwdriver STEP #8 Recommended tools: Allen Wrench（22mm）...
-
Page 10: Operation
OPERATION 1. Read the Operator’s Manual completely before attempting to use this log splitter. 2. Do not allow anyone to operate your log splitter who has not read the Operator’s Manual or has not been instructed on the safe use of the log splitter. - Page 11 8. Shut-off engine (see Stopping the Engine in the Operation section). 9. Hydraulic oil can be added appropriately when the cylinder thrust is insufficient. For safety reasons, hydraulic oil, oil and fuel are not included in the package. CHANGING BEAM FROM HORIZONTAL TO VERTICAL ORIENTATION When logs are too heavy to lift, log splitter beam can be moved from horizontal to vertical orientation.
- Page 12 SPLITTER TRANSFER INSTRUCTIONS RECOMMENDED 1. Press down on the handle. 2. Turn the handle outward and secure it in the handle slot. STEP #1 PUSH PUSH STEP #2 3. Lift the handle with one hand (Location 1) and hold the top of the main beam with the other (Location 2), then push the splitter forward. Location 2 PUSH PUSH...
-
Page 13: Expanded Drawings
EXPLODED DRAWINGS 2 20 21 22 Part No. Description Q’ty Part No. Description Q’ty Oil Hose Hexagon Socket Screw M10x35mm Flange Nut M8 Spring Washer 10 Engine Mounting Plate Wedge Protective Cover Elastic Ring Flange Nut M12 Filter Half Round Head Square Neck Bolt M12x50mm 10"... -
Page 14: Maintenance And Storage
MAINTENANCE AND STORAGE 1. Always shut off the power source while repairing or adjusting the splitter except as recommended by the manufacturer. 2. Clean debris from the engine cylinder, cylinder head fins, recoil starter cover, and muffler areas. If the engine is equipped with a spark arrestor muffler, clean and inspect it regularly (follow manufacturer’s service instructions). - Page 16 Thank you for your most recent purchase. Great Circle USA Follow us on social media @SuperHandy Support Line: 1-866-493-0524 help@greatcircleus.com www.superhandyus.com Size: 210x285mm 157克双铜 REV 01/15/24 6.02.00013...
