Summary of Contents for Husqvarna K1 PACE

  • Page 1 K1 PACE, K1 PACE Rescue, K1 PACE Rail Operator's manual 2-44 Bedienungsanweisung 45-90 Manuel d'utilisation 91-134 Gebruiksaanwijzing 135-178...

  • Page 2: Table Of Contents

    K1 PACE is used to cut hard materials such as concrete, masonry, stone and steel. K1 PACE Rescue is used in rescue operations. K1 PACE Rail with RA 11 is specially made to cut railroad tracks. Do not use the product for other tasks.
  • Page 3 Product overview K1 PACE 1. Power trigger lockout 2. Power trigger 3. Water nozzle 4. Flange for diamond blade, spindle, arbor bushing 5. Cutting blade 6. Blade guard 7. Adjustment handle for blade guard 8. Spindle direction of rotation 9. Front handle 10.
  • Page 4 Product overview K1 PACE Rescue 1. Rear handle 28. Flanges for bonded abrasive blade 2. Water connection with filter 29. Combination wrench ® 3. Shoulder strap 30. Water connector, GARDENA 4. Belt guard 31. Operator's manual 5. Supplementary arbor bushing 20 mm/0.8 in.

  • Page 5: Symbols On The Product

    Product overview K1 PACE Rail Symbols on the product 1. Power trigger lockout 2. Power trigger WARNING: This product can be 3. Adjustment handle for blade guard dangerous and cause serious injury or 4. Blade guard death to the operator or others. Be careful 5.

  • Page 6: Safety

    For more information about the cloud This product complies with applicable EU ™ asset management solution Husqvarna Fleet Services Directives. download the iOS or Android app Husqvarna Fleet Services at https://apps.apple.com/se/app/husqvarna- fleet-services/id1334672726 or https://play.google.com/ Environmental mark. The product or store/apps/details?id=com.husqvarna.hfsmobile&hl=en.

  • Page 7: General Power Tool Safety Warnings

    protected supply. Use of a RCD reduces the risk of CAUTION: Used if there is a risk of electric shock damage to the product, other materials or the adjacent area if the instructions in the WARNING: Do not pressure wash the manual are not obeyed.
  • Page 8 Power tool use and care • Use power tools only with specifically designated battery packs. Use of any other battery packs may • Do not force the power tool. Use the correct power create a risk of injury and fire. tool for your application.

  • Page 9: Kickback And Related Warnings

    intended for peripheral grinding, side forces applied could snag your clothing, pulling the accessory into to these wheels may cause them to shatter. your body. • Always use undamaged wheel flanges that are of • Regularly clean the power tool’s air vents. The correct diameter for your selected wheel.

  • Page 10: General Safety Instructions

    The protruding agent. wheel may cut gas or water pipes, electrical wiring or objects that can cause kickback. • Only use the Husqvarna PACE batteries that we General safety instructions recommend for your product. The batteries are software encrypted. WARNING: •...

  • Page 11: Battery Charger Safety

    Do not use the product in unknown Battery charger safety situations. • Turn to your servicing dealer or HUSQVARNA if you WARNING: Read all safety warnings have questions about the operation of the product. We can give you information about how to operate and all instructions.

  • Page 12: Personal Protective Equipment

    Cutting generates sparks that can ignite clothing. HUSQVARNA recommends that you wear flame- • Do not use a product in a situation where you can retardant cotton or heavy denim. Do not wear not get for support if an accident occurs.
  • Page 13 X-Halt 3. Rail fixture indicator, engaged or disengaged. Only Troubleshooting of the for K1 PACE Rail. Refer to The X-Halt function is an electronic brake system that is product on page 35 . engaged if a kickback occurs. The function can not fully ®...

  • Page 14: Safety Instructions For Maintenance

    1. Make sure that the cutting blade is attached correctly • Numbness, loss of feeling, tingling, pricking, and does not show signs of damage. pain, burning, throbbing, stiffness, clumsiness, loss of strength, changes in skin color or 2. Make sure that the blade guard has no cracks or is condition.

  • Page 15: Cutting Blades

    The rated speed Applicable cutting blades value of those cutting blades is too low for this product. CAUTION: Use HUSQVARNA WARNING: Do not use cutting recommended cutting blades for K1 blades with thickness exceeding maximum PACE and the material to be cut.
  • Page 16 • Cutting blades applicable to this product are Blade type Material available in two basic models; bonded abrasive blades and diamond blades. Stone Con- Concrete, asphalt, stone masonry, crete blade cast iron, aluminum, copper, brass, cables, rubber and plastic. Steel blade Steel, alloy steel and other hard met- Rail blade Railway rail.
  • Page 17 • Diamond blades are used for masonry, reinforced concrete and stone. • Make sure that the diamond blade rotates in the direction of the arrows shown on the diamond blade. • Always use a sharp diamond blade. • Diamond blades can become blunt if you use an incorrect feeding pressure or when you cut materials WARNING: such as hard reinforced concrete.
  • Page 18 (fire departments), Husqvarna is aware that they may use this power cutter with carbide tipped blades in certain emergency situations due to the ability of carbide tipped blades to 2.

  • Page 19: Operation

    1. Examine the flange washers and the spindle shaft. To examine the spindle shaft and the flange Refer to Strap eyelet (K1 PACE Rescue) washers on page 18 . 2. Put the cutting blade on the arbor bushing (A) The product has 2 strap eyelets. The eyelets are used to between the inner flange washer (B) and the flange attach the shoulder strap.
  • Page 20 Kickback zone Never use the kickback zone of the blade for cutting. If the blade is pinched or stalled in the kickback zone, the reactive force will push the power cutter up and back towards the user in a rotating motion causing serious or even fatal injury.
  • Page 21 5 steps. • Set the blade guard to pipe cutting mode. Refer to To set the pipe cutting mode (Only K1 PACE and K1 PACE Rescue) on page 25 . 1598 - 008 - 27.05.2024...
  • Page 22 Be careful when you put 10. Charge the battery and make sure that it is correctly the blade in an existing cut. attached to the product. Only use Husqvarna PACE approved batteries for the product. WARNING: 11. Make sure that the power cutter stops when you Make sure that the release the power trigger.

  • Page 23: Bluetooth Wireless Technology

    To examine the direction of rotation of the ™ 2. Go to Husqvarna Fleet Services website https:// fleetservices.husqvarna.com for more information. cutting blade To connect the battery charger 1. Find the arrow on the blade guard that shows the direction of rotation of the spindle shaft.

  • Page 24: Basic Working Techniques

    • The product is made for high speed diamond blades, abrasive blades and recommended blades for the product. Use HUSQVARNA recommended cutting blades for the product. • The product is made to cut into tiles, light concrete and stone. Use only for this type of operation.
  • Page 25 • Do not cut with the kickback zone of the blade, see Kickback zone on page 20 . To set the pipe cutting mode (Only K1 PACE and K1 PACE Rescue) WARNING: The adjustment handle for blade guard can be very hot, use gloves when you adjust the blade guard.

  • Page 26: Wet Cutting

    To connect the coolant water 3. Put back the stop bolt to the standard cutting mode after the pipe cutting operation. The arrow (A) shows 1. Connect the water hose to the water supply (A). the standard cutting mode. 2. Turn the water valve (B) to start or stop the water flow.

  • Page 27: To Stop The Product

    2. Put the battery in the battery holder. 4. Push and hold the On/Off button until the battery status indicator comes on. 5. Push the power trigger and power trigger lockout to start the motor. 3. Push the battery until you hear a click sound. If the battery does not move into the battery holder easily, it is not attached correctly into the battery holder.
  • Page 28 Installation points and rail fixture indicator K1 PACE Rail has 2 installation points for the rail fixture, on the left side and on the right side of the product. The rail fixture indicator shows if the rail fixture is attached or not attached to the product.
  • Page 29 To install the rail fixture RA 10, RA 10S 1. Attach the rail fixture to the rail. Tighten the handle fully. CAUTION: Install the rail fixture to the rail before you install the product to the rail fixture. There is a risk that the rail fixture is not installed at a correct angle if the product is installed first.
  • Page 30 To stop the product on The cutting guide helps the operator to put the cutting a) Stop the product. Refer to page 27 . blade in correct position for the cut. b) Remove the product from the rail fixture. 1. Fold out the cutting guide. c) Install the product with its left side to the rail 2.
  • Page 31 3. Move the product rearward and forward to decrease e) Adjust the position of the cutting blade, if it is the contact surface between the cutting blade and necessery. Loosen the 2 crews (A) and adjust the rail. More contact surface increases the risk of (B) the position of the cutting blade.

  • Page 32: Maintenance

    • For the best result and a straight cut, install the power cutter with its right side to the rail fixture. Maintenance Introduction cycle and increase the risk of accidents. All servicing and/or repair work must also be done by a professional. Turn to your WARNING: Read and understand the servicing dealer for more information.
  • Page 33 To do a check of the power trigger lockout 4. Push and hold the On/Off button to start the product To start the product on and apply full power. Refer to 1. Make sure that the power trigger and power trigger page 26 .

  • Page 34: To Clean The Cooling System

    To remove the drive belt Product overview 1. Remove the belt guard. Refer to K1 PACE on page 3 . 2. Put the belt tool on top of the front pulley. Use a 4. Attach the belt guard. Refer to Product overview K1 wrench to pull the drive belt off the pulley.

  • Page 35: Troubleshooting Of The Product

    Servicing is necessary. Speak to an approved Husqvarna service center. No reaction from the motor Servicing is necessary. Speak to an approved when you push the power Husqvarna service center.

  • Page 36: Transportation, Storage And Disposal

    Transportation and storage • Disconnect the battery from the product. • When you put the K1 PACE Rail in its transportation CAUTION: box, make sure that the rail fixture and the product Do not install the rail fixture do not touch.
  • Page 37 Note: The symbol shows on the product or package of the product. 1598 - 008 - 27.05.2024...

  • Page 38: Technical Data

    Technical data HUSQVARNA K1 PACE, K1 PACE Rescue and K1 PACE Rail Voltage d.c. maxi- 109.2/93.6 mum/nominal, V K1 PACE 12 in. 7.2/15.8 K1 PACE 14 in. 7.4/16.3 K1 PACE Rescue 12 in. 7.7/17 Weight, kg/lbs K1 PACE Rescue 14 in.

  • Page 39: Noise And Vibration Declaration Statement

    Noise emissions K1 PACE Rail LpA, dB(A) K1 PACE Rail LwA, dB(A) ™ Husqvarna Fleet Services Installed arbor bush- K1 PACE 12in., K1 PACE 14in.,K1 PACE Rescue, K1 PACE Rail 25.4/1 ing diameter, mm/in. K1 PACE 12in. UK 20/0.8 IP class...

  • Page 40: Accessories

    Frequency, Hz 50-60 50-60 Power, W 1800 Vacuum attachment ( K1 PACE, K1 Wheel kit PACE Rescue) The wheel kit is attached at the bottom of the product. Use the vacuum attachment to connect a dust extractor to the product.

  • Page 41: Service

    Service Approved service center To find your nearest Husqvarna approved service center, go to the web site www.husqvarnaconstruction.com. 1598 - 008 - 27.05.2024...

  • Page 42: Declaration Of Conformity

    +46-36-146500, declare on our sole responsibility that the product: Description Portable cut-off machine Brand HUSQVARNA Type/Model K1 PACE, K1 PACE Rescue, K1 PACE Rail Identification Serial numbers dating from 2023 and onwards complies fully with the following EU directives and regulations: Directive/Regulation Description 2006/42/EC "relating to machinery"...
  • Page 43 Description Portable cut-off machine Brand HUSQVARNA Type/Model K1 PACE, K1 PACE Rescue, K1 PACE Rail Identification Serial numbers dating from 2023 and onwards complies fully with the following EU directives and regulations: Description The Supply of Machinery (Safety) Regulations 2008...

  • Page 44: Registered Trademarks

    Registered trademarks ® Bluetooth word mark and logos are registered Bluetooth SIG, inc. and any use trademarks owned by of such marks by HUSQVARNA is under license. 1598 - 008 - 27.05.2024...
