Summary of Contents for Bosch MIC-7504

  • Page 1 MIC IP ultra 7100i │ MIC IP starlight 7100i MIC‑7504│MIC‑7522 User Manual...
  • Page 3: Table Of Contents

    5.17 Pixel Counter Recording Introduction to recording Storage Management 6.2.1 Device manager 6.2.2 Recording media 6.2.3 Activating and configuring storage media 6.2.4 Formatting storage media 6.2.5 Deactivating storage media Recording Profiles Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 4 Saving snapshots 10.1.8 Recording live video 10.1.9 Full-screen display 10.1.10 Audio communication 10.1.11 Storage, CPU and network status 10.1.12 Status icons 10.1.13 Date and Time 10.1.14 Video Security App 10.2 Playback 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 5 11.2 Uploading a User Logo 11.3 Two-line and Three-line Camera Titles 11.4 Azimuth, Elevation, and Compass Directions Troubleshooting 12.1 Rebooting the unit 12.2 Physical reset button 12.3 Customer Service and Support Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 6: Introduction

    If you cannot connect, the unit may have reached its maximum number of connections. Depending on the device and network configuration, each unit can have up to 50 web browser connections, or up to 100 connections via Bosch Video Client or Bosch Video Management System.
  • Page 7: Password Protection In Camera

    (“service”) and the service-level password every time that they access the device. Fill in the fields User name and Password. Click OK. If the password is correct, the desired page appears. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 8: System Overview

    Configuration To configure the unit, click this icon. Links To navigate to the Bosch download store, click this icon. To get context sensitive help for a particular page, click this icon. Note: None of the pages are accessible until after you set a service-level password.
  • Page 9: General

    A check mark in this check box indicates that at least one certificate is loaded onto the camera. If no certificates are loaded, then “No certificate installed” appears to the right of the text. The Escrypt certificate is a root certificate for Bosch Security Systems that proves that the device meets the following criteria: –...
  • Page 10: Date/Time

    The unit already contains the data for DST switch-overs for many years in advance. If the date, time and zone have been set up correctly, a DST table is automatically created. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 11: Display Stamping

    128x128 pixels and 256 colors to the camera. Its position on the image can then be selected. Logo position Select the position for the logo on the OSD: To the left of the name, To the right of the name, or Logo only. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 12 The fields Position (XY) and (0...255) appear. In the field Position (XY), specify the exact position. (The default is 10.) In the field (0...255), enter the position range. (The default is 176). 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 13: T 28181

    Enter a value (in milliseconds) for the registration timeout. The default is 3600. Heartbeat timeout Enter the value (in seconds) for the heartbeat timeout. The default is 15. Server ID Enter the ID of the server. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 14 Enter the ID of the device. Device port Enter the number of the device port. The default is 5060. Password Enter the appropriate password. Alarm device ID Enter the ID of the alarm device. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 15: Web Interface

    Select this check box to show overlay icons on the live video image. Show VCA items Shows alarm fields, lines and routes configured for the video analytics in the following colors: Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 16: Live Functions

    Here you can specify whether the Live page displays the section Show 'AUX Control'. Show ‘Special Functions’ Video file format Select a file format for the live page display. The MP4 format does not include metadata. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 17: Camera

    Allow several seconds for the camera to optimize the picture after a reset. Note: Clicking this button also clears the service-level password. Operators must reset the password before doing anything else. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 18: Positioning

    Select the Global check box to use the global, overall calibration for all AUTODOME and MIC cameras. Alternatively, clear the Global check box to obtain a local calibration and overwrite the global calibration for the selected profile. To do this, select the VCA profile before. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 19 The angle on ground represents an angle lying on the horizontal ground plane, such as the corner of a carpet or parking bay markings. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 20 The orientation of the camera in a counter-clockwise angle starting with 0° in the east (WGS 84) or on the X-axis (Cartesian). If the camera is directed towards the north (WGS 84) or the Y-axis (Cartesian), the azimuth is 90°. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 21: Scene Mode

    In this case, the name of the user mode changes to “Custom.” Mode ID The name of the selected mode is displayed. Copy mode to Select the mode from the drop-down menu to which you wish to copy the active mode. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 22: Picture Settings

    Use the slide to select the desired number for fixed gain. The default is 2. Maximum Gain Level Controls the maximum value the gain can have during AGC operation. To set the maximum gain level, choose from: – Normal – Medium – High (default) 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 23: Enhance

    Values are ¼, 1/8, 1/15, and 1/30; the default is 1/15. 5.2.2 Enhance High dynamic range Select On to activate wide dynamic range, which improves image reproduction in extreme high-contract scenes. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 24: Scene Mode Scheduler

    Select the mode you wish to use during the day from Marked range drop-down box. Select the mode you wish to use during the night from Unmarked range drop-down box. Use the two slider buttons to set the Time ranges. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 25: Encoder Profile

    For an SD image, the video bit rate and frame Optimized quality are adjusted to ensure that the bit rate is the priority. Profile 7 DSL Optimized Ideal for encoding on a DSL uplink where bit rate limitations are critical. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 26 Note: The value in this field adjusts the resolution for SD streams only. Expert settings If necessary, use the expert settings to adapt the I-frame quality and the P-frame quality to specific requirements. The setting is based on the H.264 quantization parameter (QP). 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 27: Encoder Streams

    Click Default to return the profile to the factory default values. Encoder Streams Note: If you access this menu while the camera is recording, the following message appears at the top of the page: Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 28 Profile 4 SD Image Optimized For an SD image, the video bit rate and frame quality are adjusted to ensure that the picture quality is the priority. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 29: Encoder Statistics

    (shape) in the preview of the video image. – Drag the center, corner points, or sides of the shaded area (shape). – Double-click a side to add additional points to the area (shape). Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 30: Privacy Masks

    Draw the mask 10% larger than the object to ensure that the mask completely covers the object as the camera zooms in and out. Pattern Select the color of the mask as it will appear in live video: Black, White, or Gray. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 31: Lens Settings

    Manual: camera must be manually adjusted to compensate for varying light conditions. Auto iris level Increases or decreases brightness according to the amount of light. Type a value between 1 and 15. Maximum zoom speed Controls the zoom speed. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 32: Ptz Settings

    Note: If you would like to pan/tilt manually, or to use recording Tour A / Tour B, while using the “IVA while moving” feature, then you must set the value in this field to <5. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 33 Use the View Control dialog box to make the necessary camera movements. Click the Stop Recording button to save all actions. Note: Tour B is now intended for use with the 'IVA while moving' functions. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 34: Pre-Positions And Tours

    SW, W, NW) heading in which the camera is pointing. Notice! The compass feature is not compatible with Bosch’s Intelligent Tracking feature. If Intelligent Tracking is activated, the camera automatically disables the display of the compass heading. Once Intelligent Tracking is deactivated, the camera returns the compass heading to the display.
  • Page 35: Pre-Position Settings

    Select the degree of intensity of the White light. 5.12 Pre-position mapping Pre-position mapping allows you to map a function to a pre-position action. This feature works for Bosch protocols and for non-Bosch protocols. Action Select the appropriate action: Show or Set. Pre-position Enter the number of the pre-position to map.
  • Page 36: Sectors

    The default intensity for illumination (both IR and White light) is 33%. IR mode Select the appropriate IR mode to control the IR illuminators: – Off - This mode turns off the illuminators. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 37: Audio

    You can set the gain of the audio signals to suit your specific requirements. The live video image is shown in the window to help you check the audio source. Your changes are effective immediately. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 38: Pixel Counter

    To change the shape of a zone, place the cursor over the edge of the zone, hold down the mouse button and drag the edge of the zone to the required position. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 39: Recording

    A iSCSI target storage device can only be associated with one user. If a target is being used by another user, ensure that the current user no longer needs the target before decoupling that user. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 40: Formatting Storage Media

    You can specify whether, in addition to video data and metadata (for example alarms, VCA data and serial data) should also be recorded. Including metadata could make subsequent searches of recordings easier but it requires additional memory capacity. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 41: Maximum Retention Time

    The recording scheduler allows you to link the created recording profiles with the days and times at which the camera's images are to be recorded in the event of an alarm. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 42 Click the Stop button to deactivate the recording scheduler. Running recordings are interrupted and the configuration can be changed. Recording status The graphic indicates the recording activity of the camera. You will see an animated graphic while recording is taking place. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 43: Recording Status

    Select the type of image to be sent. Target Select the target account for best face posting. Timeout Fill in the timeout in seconds. Leave at 0 for no timeout. Maximum image width [px] Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 44: Sd Card Status

    SD Card Status This section identifies the following details about the SD card installed in the camera: – Manufacturer – Product – Size – Lifespan Check – Lifespan – Lifespan alarm 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 45: Alarm

    Multicast operation is not possible. To enable Multicast operation, select the UDP option for the Video transmission parameter here and on Network Access. Stream Select the number of the stream from the drop-down list. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 46 The following field may or may not appear, depending on your camera: Audio Select On to activate audio alarms. The following field may or may not appear, depending on your camera: 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 47: Video Content Analysis (Vca)

    Sensitivity and Trigger delay [s] can only be changed if Reference check is selected. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 48: Audio Alarm

    Notice! First set up normal audio transmission before you configure the audio alarm here (see Audio). 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 49: Alarm E-Mail

    Select the appropriate image size: Small, Medium, Large, 720p, 1080p, Best possible. Attach JPEG from camera Click the checkbox to specify that JPEG images are sent from the camera. An enabled video input is indicated by a check mark. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 50: Alarm Task Editor

    AUX on: defines a standard or custom keyboard ON command. – AUX off: defines a standard or custom keyboard OFF command. – Pre-position: defines a pre-position from shot 1-256. (Note: This option is not available for the input Time range.) 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 51 17 is set to [camera name] - IO“ (for a camera connected to MIC-ALM-WAS-24) Click the checkbox Enabled to activate the alarm. Click Set to save. The camera’s system activates the alarm rules. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 52: Network

    If you want the unit to establish a connection to a remote location in a different subnet, enter the IP address of the gateway here. Otherwise leave the box blank (0.0.0.0). 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 53 This deactivates all unsecured connections. Connections will then only be possible via the HTTPS port. You can activate and configure encryption of the media data (video and metadata) on the Encryption page (see Encryption). Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 54: Dyndns

    Notice! Information about the service, registration process and available host names can be found at DynDNS.org. Provider The value in this field defaults to dyndns.org. Select another option as necessary. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 55: Advanced

    This field identifies any cloud-based services with which the camera communicates. – If you have registered the device on a cloud-based service such as Bosch Remote Portal, then this field identifies this fact (“Registered on Bosch Remote Portal”). Note: The button (Connect to Bosch Remote Portal) to connect to the device with that service is active.
  • Page 56: Network Management

    To use the UPnP function on a computer, both the Universal Plug and Play Device Host and SSDP Discovery Service must be active in Windows XP and Windows 7. This function should not be used in large installations because of the variety of potential registration notifications. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 57: Multicast

    This value must be greater than one if multicast is to be run via a router. IGMP version You can define the multicast IGMP version to comply with the device. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 58: Accounts

    IP Address 1 / 2 Enter the IPv4 address that you want to allow or block Mask 1 / 2 Enter the subnet mask for the appropriate IPv4 address. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 59: Service

    Cancel to stop the upload. Click Download to save the camera settings to a file to upload to the same camera or to a similar camera in the future. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 60: Licenses

    Logs This section updates automatically with the history of the camera and maintains a log of all events such as those listed below. Click the REFRESH button to reload log data. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 61: System Overview

    This window is for information only and cannot be modified. Keep this information at hand when seeking technical support. Select the text on this page with a mouse and copy it so that it can be pasted into an e-mail if required. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 62: Operation Via The Browser

    Note: If the pre-position is already stored, a dialog box displays the message, “Overwrite current pre-position?” Click OK to overwrite, or click Cancel to cancel the operation. Click to display the selected pre-position in the video image. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 63: Aux Control

    Individual images from the displayed live video stream can be saved locally in JPEG format on the computer's hard drive. The storage location depends on the configuration of the camera. – Click the photo camera icon to save a single image. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 64: Recording Live Video

    – if the CPU load is too big, change the VCA settings, – if the network load is too big, change the encoder profile to reduce bitrate. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 65: Status Icons

    Start Video Security app To start the Video Security app, click 10.2 Playback 10.2.1 Selecting the recording stream On the left side of the browser, expand the Connection group if necessary. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 66: Searching For Recorded Video

    The buttons have the following functions: – Start/Pause playback – Select the playback (forward or backward) speed using the speed regulator – Step forward or backward frame-by-frame when paused (small arrows) 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 67: Using Your Mic Camera

    Note: Tour B is now intended for use with the 'IVA while moving' functions. Preset Tours For scenarios that require the camera to be in continuous motion for most of the day, Bosch recommends that you set the camera in Preset Tour mode, moving between a desired set of presets.
  • Page 68: Uploading A User Logo

    Change the Camera Title Click General. Select Identification. Delete all of the text in the field Camera name. Rename the camera if desired. Click Set to save. 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 69: Two-Line And Three-Line Camera Titles

    LOOKING will always appear in English and will be at a fixed location on the OSD. – The X or XX designates the compass direction that updates automatically as the camera pans. A identifies “North,” “South,” “East,” or West.” AA identifies “Northeast,” “Northwest,” “Southeast,” or “Southwest.” Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 70 LOOKING will always appear in English and will be at a fixed location on the OSD. – The X or XX designates the compass direction that updates automatically as the camera pans. A identifies “North,” “South,” “East,” or West.” AA identifies “Northeast,” “Northwest,” “Southeast,” or “Southwest.” 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 71: Azimuth, Elevation, And Compass Directions

    Azimuth Zero point. Notice! Bosch recommends that only the installer calibrate the Azimuth Zero point. A recalibration to the Azimuth Zero point may cause inaccurate compass headings. Set the Azimuth Zero point: Determine the North compass heading, then move the camera to that position.
  • Page 72: Troubleshooting

    Your camera has an improper network connection. intermittently Test your camera with another power supply. Check the Bosch website for a software update that might address the issue. Nothing appears on the screen. Are the power cord and line connection between the camera and monitor made properly? The image on the screen is dim.
  • Page 73 (especially on the yoke arms). – If there is obvious and severe damage, stop using the camera and contact your Bosch Service Center for assistance. – If no damage is evident, complete one of the following steps: a) Cycle the power on the camera.
  • Page 74: Rebooting The Unit

    If you cannot control the unit after the firmware upgrade, then cycle the power to the unit. If a power reset does not solve the problem, or if Configuration or video management software identifies the unit as “Videojet Generic,” then contact your Bosch Service Center for an RMA for the unit.
  • Page 75: Physical Reset Button

    Let the camera complete a self-check. When the self-check completes, the red LED will go off. Find the IP address again. Access the camera using the web browser. Set the initial service-level password for the camera. Bosch Security Systems User Manual 2019-07-09 | 0.5 |...
  • Page 76 | Troubleshooting MIC IP ultra 7100i │ MIC IP starlight 7100i 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 77: Customer Service And Support

    MIC IP ultra 7100i │ MIC IP starlight 7100i Troubleshooting | en 12.3 Customer Service and Support If this unit needs service, contact the nearest Bosch Security Systems Service Center for authorization to return and shipping instructions. Telephone: 800-366-2283 Fax: 800-366-1329 Email: cctv.repair@us.bosch.com...
  • Page 78 | Troubleshooting MIC IP ultra 7100i │ MIC IP starlight 7100i 2019-07-09 | 0.5 | User Manual Bosch Security Systems...
  • Page 80 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2019...
