- Page 1 EVOCHARGE 50A EV CHARGING STATIONS QUICK INSTALLATION GUIDE EVSE | EVC5O EVC5O LTE ATTENTION: Read and follow all instructions, warnings, dangers, and notifications before installing. Return this guide to the owner after installation.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION Read and follow all instructions, warnings, dangers, and notifications before installing and using EvoCharge EVSE Products. THIS CHARGING STATION MUST BE INSTALLED BY A LICENSED ELECTRICIAN. Failure to follow these guidelines may result in death, injury, or property damage and will void the product warranty. Save these instructions. - Page 3 701077 REVB CAUTION Copper wire must be used and sized to follow NFPA 70 NEC wiring code ■ guidelines. Children should not operate and must be supervised when around the ■ equipment. Do not touch EVSE Connector's end terminals with fingers or sharp metallic ■...
- Page 4 50A Quick Install Guide EVOCHARGE' Prepare the Charger Remove T10 fasteners located on ■ the bottom of the front cover. Pull firmly up on the bottom of the ■ front cover and disengage tabs located mid-panel. Remove the six T25 fasteners ■...
- Page 5 701077 REVB Installation of Mounting Bracket and Cable Holster Charger and holster must be mounted to a solid surface, directly to wood stud or concrete/brick wall. Use the included mounting screws when mounting to a wood stud wall. Screw suggestion: For masonry walls, use%"...
- Page 6 50A Quick Install Guide EVOCHARGE' Mount Charger to Bracket Slide the charger onto the mounting ■ bracket. Fix the charger on the mounting ■ bracket with T10 screw and screw washer. Wiring the Charger WARNING: Failure to disconnect power prior to installation can lead to serious injury or death.
- Page 7 701077 REVB Setting the Amperage of the Charger Verify the power to the unit is off. ■ Adjust the amperage output dial as needed. ■ Using the table below, find the switch ■ setting that corresponds to the desired charger rating {maximum amperage). Using a screwdriver, rotate the arrow on the ■...
- Page 8 50A Quick Install Guide EVOCHARGE'...
- Page 9 701077 REVB Electrical Wiring to the Charger CAUTION: Use copper conductors only. Fix wire on the corresponding terminal block position. The wiring instructions are printed in front of the terminal block {L2/G/L1). Table 1 provides a reference for the minimum conductor size for the circuit from ■...
-
Page 10: Complete Installation
EVOCHARGE' 5 A Quick Install Guide Terminal block wiring position Complete Installation Carefully re-install the sealed enclosure cover and front cover. ■ Powering the charging station: ■ - Turn the breaker on. - After start up sequence of approximately 3 minutes, LED indicator light will illuminate green. - Page 12 ENERGY STAR products are third-party certified by an EPA-recognized Certification Body. Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by EvoCharge, Inc. is under license. Other trademarks and trade names are those of their respective owners.
- Page 13 701077 REVB FCCID:2BEYO-PEVC50 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement WARNING: The radiated output power of the EVSE, EVC50 and EVC50 LTE is below FCC radio frequency exposure limits.
- Page 14 50A Quick Install Guide...
