CONTENTS SAFETY INFORMATION……………………………………………………..4-5 IMPORTANT REFERENCE INFORMATION………………….……….6 SPECIFICATIONS……………………………………………………….……….7 FEATURES……………………………………………………………….…..……8 INSTALL PLANNING AND SERVICE WIRING……………………….9 INSTALLATION………………………………………………………………….10-17 OPERATION……………………………………………………………………..18-19...
• Do not attempt to open, disassemble, repair, tamper with, or modify the EVoReel product. The EVoReel product is not user serviceable. Contact EVoCharge for any repairs. • Do not use the EVoReel product when either you, the vehicle, or the EVoReel product is exposed to severe rain, snow, electrical storm or other severe weather.
Page 5
SAVE THESE SAFETY INSTRUCTIONS This document contains important instructions and warnings that must be followed when installing and maintaining the EVoReel product Caution • Incorrect installation and testing of the EVoReel product could potentially damage either the vehicle’s Battery and/or the EVoReel product itself.
EVoReel product. The EVoReel products are not user serviceable. Contact EVoCharge for any repairs • Periodic cleaning may be required, depending on local conditions. To avoid damaging the finish of the EVoReel products, only use an automotive grade soft cleaning cloth and a mild soap and water mixture to remove accumulation of dirt and dust.
SPECIFICATIONS Product Description EVoReel Retractable Cable Reel for use with SAE J1772 EVSEs EVSE Compatibility SAE J1772, AC Level 2 and AC Level 1 Max Continuous Current Rating Voltage Rating 120VAC / 208-240VAC Max Power Rating 7.20 kW Vehicle Connector SAE J1772 Frequency 50/60 Hz...
FEATURES Retractable Reel All EVoReel retractable reel products provide improved convenience and safety for the user by utilizing a retractable reel for charge cable management. The retractable reel includes a vehicle charge cable up to 30 feet in length. Indoor/Outdoor Rated Enclosures (NEMA 4) The EVoReel products are rated for both indoor and outdoor installation and comply with NEMA 4.
INSTALL PLANNING AND SERVICE WIRING • Prior to mounting, determine location of an acceptable mounting support. The Wall or Ceiling mount unit must be anchored into a mounting support such as a 2” x 4” stud or a solid concrete wall, using mounting hardware that is appropriate for the surface on which you are mounting.
INSTALLATION STEP 1 – Verify Received Content Mounting Interconnect Support Clamp Bracket Quantity: (4) Retractable Reel Charge Cable 3/8” Lag Screws Quantity: (3) (For use when mounting reel to Vehicle wall/ceiling wooden wall stud) Connector Interconnect – Connector & Terminal Kit Cable Connection to EVSE Quantity: (1) Kit Consisting of (4) pcs.
Page 11
INSTALLATION STEP 2 – Adjust Retractable Reel Roller Guide Arm Position 1. Prior to mounting retractable reel, determine the preferred position of the roller guide arm. The roller guide arm can be adjusted into (12) different locations based on your installation method.
Page 12
INSTALLATION STEP 3 – Install Retractable Reel 1. Determine preferred height and orientation of retractable reel. It is recommended to install retractable reel at the maximum height based on interconnect cable length. The retractable Mounting Option “A” reel can be mounted using mounting option “A”...
Page 13
INSTALLATION STEP 4 – Install Retractable Reel 1. Locate a wall stud and use a 1/4” bit to drill a pilot hole for each mounting hole. The (3) mounting holes are positioned 1.625” away from each other. 2. Prepare mounting hole by Fastening lag screw into top of 1.625”...
Page 14
INSTALLATION STEP 5 – Install Retractable Reel 1. Place reel mounting bracket over mounting holes and fasten lag screw. 2. Continue fastening lag screws into each mounting hole. WARNING: All lag screws MUST be used to install the charging unit to the vertical wall stud.
Page 15
INSTALLATION STEP 6 – Adjust Vehicle Connector Position 1. Adjust retractable reel ball stop position by using a screwdriver to loosen both fasteners. 2. Adjust the ball stop to a position that enables a convenient vehicle connector rest position. 3. Fasten and secure the ball stop to vehicle charge cable.
Page 16
INSTALLATION STEP 7 – Adjust Reel Retraction Rate (if required) 1. Depending on the cable stop placement from installation step 6, the retraction rate of the reel may need adjustment. This can be accomplished by manually adjusting the number of charge cable wraps around the reel.
Page 17
Green Ground to turning ON the supply power. Blue Pilot Control WARNING: EVoCharge recommends installation Step 8 to be completed by a qualified electrician. The connection to the existing EVSE must be in accordance with all applicable state, local and national electrical codes and standards.
OPERATION – Enable Charging 1. Retract charge cable to the desired length and install charge connector into vehicle charge port. CAUTION: Extend and retract the charge cable by applying force to the cable only; do not apply force to the vehicle connector. NOTE: A red warning tag is applied to the charge cable at the maximum recommended cable extension length.
Page 19
OPERATION – Disable Charging 1. Remove charge connector from vehicle and pull slightly on the charge cable to retract the cable onto the reel and place charge connector in its stowed position. CAUTION: When retracting the charge cable into its stowed position, it is recommended to control the speed of the cable and connector retraction by keeping tension on the cable and guiding onto the retractable reel.
Page 20
EVoReel Electric Vehicle Cable Management sales@evocharge.com (800) 930-9450 For the latest user manual version, please visit www.evocharge.com/download.html...
