- Page 1 EVOCHARGE 50A EV CHARGING STATIONS QUICK INSTALLATION GUIDE EVSE 50 | HOME 50 ATTENTION: Read and follow all instructions, warnings, dangers, and notifications before installing. Return this guide to the owner after installation. 701061 REV B...
- Page 2 IMPORTANT SAFETY INFORMATION Read and follow all instructions, warnings, dangers, and notifications before installing and using EvoCharge EVSE Products. THIS CHARGING STATION MUST BE INSTALLED BY A LICENSED ELECTRICIAN. Failure to follow these guidelines may result in death, injury, or property damage and will void the product warranty. Save these instructions.
- Page 3 701061 REV B CAUTION • Copper wire must be used and sized to follow NFPA 70 NEC wiring code guidelines. • Children should not operate and must be supervised when around the equipment. • Do not touch EVSE Connector’s end terminals with fingers or sharp metallic objects, such as wire, tools, or needles.
- Page 4 50A Quick Install Guide Prepare the Charger • Remove T10 fasteners located on the bottom of the front cover. • Pull firmly up on the bottom of the front cover and disengage tabs located mid-panel. • Remove the six T25 fasteners holding down the sealed enclosure cover.
- Page 5 701061 REV B Installation of Mounting Bracket and Cable Holster Charger and holster must be mounted to a solid surface, directly to wood stud or concrete/brick wall. Use the included mounting screws when mounting to a wood stud wall. Screw suggestion: •...
- Page 6 50A Quick Install Guide Mount Charger to Bracket • Slide the charger onto the mounting bracket. • Fix the charger on the mounting bracket with T10 screw and screw washer. Wiring the Charger WARNING: Failure to disconnect power prior to installation can lead to serious injury or death.
- Page 7 701061 REV B Setting the Amperage of the Charger • Verify the power to the unit is off. • Adjust the amperage output dial as needed. • Using the table below, find the switch setting that corresponds to the desired charger rating (maximum amperage).
- Page 8 50A Quick Install Guide Electrical Wiring to the Charger CAUTION: Use copper conductors only. Fix wire on the corresponding terminal block position. The wiring instructions are printed in front of the terminal block (L2/G/L1). • Table 1 provides a reference for the minimum conductor size for the circuit from the panel to the EVSE via raceway (NEC 310.16).
-
Page 9: Complete Installation
701061 REV B Terminal block wiring position Complete Installation • Carefully re-install the sealed enclosure cover and front cover. • Powering the charging station: - Turn the breaker on. - After start up sequence of approximately 3 minutes, LED indicator light will illuminate green (EVSE) or white (Home 50). - Page 10 ENERGY STAR products are third-party certified by an EPA-recognized Certification Body. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, ® Inc. and any use of such marks by EvoCharge, Inc. is under license. Other trademarks and trade names are those of their respective owners.
- Page 11 2. This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by EVOCHARGE INC. could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 12 For any installation questions, contact us at: 888-653-0160 evochargesupport@phillipsandtemro.com evocharge.com For more resources and product documents...
