INSTALLATION MANUAL
PRIMUS 503F
PRIMUS 503CF
PRIMUS 603F
PRIMUS 603CF
PRIMUS 683F
PRIMUS 693C
PRIMUS 693M
PRIMUS 753T

Advertisement

loading
Need help?

Need help?

Do you have a question about the infinity PRIMUS 503F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Harman infinity PRIMUS 503F

Summary of Contents for Harman infinity PRIMUS 503F

  • Page 1 INSTALLATION MANUAL PRIMUS 503F PRIMUS 603F PRIMUS 683F PRIMUS 693M PRIMUS 503CF PRIMUS 603CF PRIMUS 693C PRIMUS 753T...
  • Page 2 PRIMUS 503F 4-1/2" (113.6mm) S 503F 4-1/2" (113.6mm) MUS 503F 5-1/8" (129.0mm) 5-1/8" (129.0mm)

  • Page 4: Specifications

    Specifications Thiele-Small Parameters • BL: 3.158 • Type: 5-1/4" (130mm) 2-way coaxial car speakers • DCR(ohms): 2.6 • Woofer: 5-1/4" Polypropylene Driver • Mms(g): 9.36 • Tweeter: 1/2" Silk Dome • Sd(cm2): 102.07 • Power Handling: 40Wrms, 120W peak • Cms(mm/N): 0.248 •...
  • Page 5 PRIMUS 603F 5" (127.0mm) S 603F 5" (127.0mm) IMUS 603F 6-1/4" (158.0mm) 6-1/4" (158.0mm)
  • Page 7 Specifications Thiele-Small Parameters • BL: 3.323 • Type: 6-1/2" (160mm) 2-way coaxial car speakers • DCR(ohms): 2.54 • Woofer: 6-1/2" Polypropylene Driver • Mms(g): 13.035 • Tweeter: 1/2" Silk Dome • Sd(cm2): 141.03 • Power Handling: 50Wrms, 150W peak • Cms(mm/N): 0.305 •...
  • Page 8 PRIMUS 683F S 683F 7-1/4" (182.6mm) PRIMUS 683F 7-1/4" (182.6mm) 8-11/16" (220.0mm) 8-11/16" (220.0mm)
  • Page 10 Specifications Thiele-Small Parameters • BL: 3.436 • Type: 6"x8" (152mm x 203mm) 2-way coaxial car speakers • DCR(ohms): 2.54 • Woofer: 6"x8" Polypropylene Driver • Mms(g): 14.862 • Tweeter: 1/2" Silk Dome • Sd(cm2): 173.8 • Power Handling: 50Wrms, 150W peak •...
  • Page 11 PRIMUS 693M S 693M 8-1/2" (214.6mm) RIMUS 693M 8-1/2" (214.6mm) 9-5/16" (236.5mm) 9-5/16" (236.5mm)
  • Page 13 Specifications Thiele-Small Parameters • BL: 3.754 • Type: 6"x9" (152mm x 230mm) 3-way car speakers • DCR(ohms): 2.65 • Woofer: 6"x9" Polypropylene Driver • Mms(g): 23.312 • Tweeter: 3/4" Silk Dome • Sd(cm2): 240.8 • Power Handling: 60Wrms, 180W peak •...
  • Page 14 PRIMUS 503CF 4-1/2" (113.6mm) 4-1/2" (113.6mm) PRIMUS 503CF PRIMUS 503CF 3-1/16" (77.4mm) 3-1/16" (77.4mm) 1-5/16" 1-5/16" (32.5mm) (32.5mm) 5-1/8" (129.0mm) 5-1/8" (129.0mm)
  • Page 16 1-1/2" (37.2mm)

  • Page 18: System Set Up: Option

    System set up: option 1...
  • Page 19 System set up: option 2...
  • Page 20 Specifications Thiele-Small Parameters • BL: 3.194 • Type: 5-1/4" (130mm) 2-way component system car speakers • DCR(ohms): 2.63 • Woofer: 5-1/4" Polypropylene Driver • Mms(g): 10.402 • Tweeter: 3/4" Silk Dome • Sd(cm2): 102.07 • Power Handling: 50Wrms, 150W peak •...
  • Page 21 PRIMUS 603CF 5" (127.0mm) 5" (127.0mm) PRIMUS 603CF PRIMUS 603CF 3-1/16" (77.4mm) 3-1/16" (77.4mm) 1-5/16" 1-5/16" (32.5mm) (32.5mm) 6-1/4" (158.0mm) 6-1/4" (158.0mm)
  • Page 23 1-1/2" (37.2mm)
  • Page 25 System set up: option 1...
  • Page 26 System set up: option 2...
  • Page 27 Specifications Thiele-Small Parameters • BL: 3.348 • Type: 6-1/2" (160mm) 2-way component system car speakers • DCR(ohms): 2.61 • Woofer: 6.5" Polypropylene Driver • Mms(g): 12.702 • Tweeter: 3/4" Silk Dome • Sd(cm2): 141.03 • Power Handling: 60Wrms, 180W peak •...
  • Page 28 PRIMUS 693C 8-1/2" (214.6mm) 8-1/2" (214.6mm) 8-1/2" (214.6mm) PRIMUS 693C PRIMUS 693C PRIMUS 693C 3-1/16" (77.4mm) 3-1/16" (77.4mm) 3-1/16" (77.4mm) 1-5/16" 1-5/16" 1-5/16" (32.5mm) (32.5mm) (32.5mm) 9-5/16" (236.5mm) 9-5/16" (236.5mm) 9-5/16" (236.5mm)
  • Page 29 6x 8x...
  • Page 30 1-1/2" (37.2mm)
  • Page 32 System set up: option 1...
  • Page 33 System set up: option 2...
  • Page 34 Specifications Thiele-Small Parameters • BL: 3.767 • Type: 6"x9" (152mm x 230mm) 2-way component system car speakers • DCR(ohms): 2.59 • Woofer: 6"x9" Polypropylene Driver • Mms(g): 22.718 • Tweeter: 3/4" Silk Dome • Sd(cm2): 240.8 • Power Handling: 80Wrms, 240W peak •...
  • Page 35 PRIMUS 753T 3-1/16" (77.4mm) 1-1/2" (37.2mm) 1-5/16" (32.5mm)
  • Page 40 Specifications • Type: 3/4" (19mm) edge-driven silk dome tweeters • Tweeter: 3/4” Silk Dome • Power Handling: 40Wrms, 120W peak • Sensitivity (2.83V@1m): 91dB • Frequency Response (-6dB): 2kHz – 20kHz • Nominal Impedance: 3.0 ohms • Crossover Point: 5kHz@12dB/octave...
  • Page 41 © 2022 HARMAN International Industries, Incorporated. All rights reserved. Infinity is a trademark of HARMAN International Industries, Incorporated, registered in the United States and/or other countries. Features, specifications and appearance are subject to change without notice. CA_Infinity Primus Speakers Gen 2 503F 603F 683F 693M 503CF 603CF 693C 753T_OM_Global_online_SOP_V2_EN...
