Installation Manual
JBL Professional Intellivox - DS/DSX 115, 180,
280, 380, 430 & 500 models
(Part Nos. 587000, 587001, 587020, 587021, 587040, 587041, 587060,
587061, 587080, 587081, 587120, 587121, 587140, 587141, 587160,
587161, 587180, 587181, 587300, 587301, 587350, 587351, 587480,
587481)

Advertisement

Table of Contents
loading

Summary of Contents for Harman JBL Professional Intellivox DS 115

  • Page 1 Installation Manual JBL Professional Intellivox - DS/DSX 115, 180, 280, 380, 430 & 500 models (Part Nos. 587000, 587001, 587020, 587021, 587040, 587041, 587060, 587061, 587080, 587081, 587120, 587121, 587140, 587141, 587160, 587161, 587180, 587181, 587300, 587301, 587350, 587351, 587480, 587481)
  • Page 2: Reference To Statements Of Conformity

    REFERENCE TO EC STATEMENT OF CONFORMITY USER’S NOTICE AND DISCLAIMER: This document confirms that products manufactured by Harman Professional Kft bearing the CE label meet all the No part of this manual including the software described requirements in the EMC Directive 2014/30/EU, LV...
  • Page 3: Table Of Contents

    JBL Intellivox Installation Manual TABLE OF CONTENTS Reference to Statements of Conformity …………………… 2 User’s Notice and disclaimer ……………………………… 2 1. Important Safety Instructions …………………………… 4 2. Introduction ……………………………………………… 5 Applicable models and variants …………………… 5 What’s in the packaging …………………………… 6 3.
  • Page 4: Important Safety Instructions

    JBL Intellivox Installation Manual 1.IMPORTANT SAFETY INSTRUCTIONS This symbol is intended to alert you to the 12) Use only with the cart, stand, tripod, bracket presence of uninsulated dangerous voltages or table specified by the manufacturer, or sold within the product’s enclosure that may be of with the apparatus.
  • Page 5: Introduction

    JBL Intellivox Installation Manual 2.INTRODUCTION This manual describes the recommended installation APPLICABLE MODELS, AND VARIANTS procedure for the JBL Intellivox DS / DSX range of loud- The various models in the Intellivox range are fitted with speakers. different numbers of drive units. The JBL Intellivox is a type of loudspeaker known as an This manual applies to the following JBL active DSP-controlled loudspeaker array, which utilises...
  • Page 6: What's In The Packaging

    JBL Intellivox Installation Manual A standard option applicable to all models is the position within the housing of the electronics module, which may fig.2 either be at the top or bottom of the housing. The position is relevant to the installation procedure as the “acoustic centre”...
  • Page 7: Installation Guide

    JBL Intellivox Installation Manual 3. INSTALLATION GUIDE PREPARING FOR INSTALLATION SIGNAL AND CONTROL CABLES Before starting to install the Intellivox loudspeaker, a • In addition to the mains supply, some or all of the fol- number of points should be considered. lowing cables (shown in fig 4) will need to be run to the loudspeaker position.
  • Page 8: Connector And Wiring Details

    JBL Intellivox Installation Manual necessary to upload the correct settings for each unit to CONNECTOR AND WIRING DETAILS obtain the desired acoustic coverage. Once this has been All connections to the Intellivox (except mains power) are done, there is no longer an operational need to have the made via the connector block at one end of the electronics Intellivox connected to a PC because all settings are stored module.
  • Page 9: Ac Mains

    JBL Intellivox Installation Manual A pre-made IEC mains cable (with the appropriate plug for the territory) may be used if one of a suitable length is available. Otherwise, use the mating IEC cable socket supplied, and wire to the intended mains outlet. Note that this connector is only suitable for use with stranded “appliance”...
  • Page 10: Wago Connectors

    JBL Intellivox Installation Manual WAGO CONNECTORS 3) Using the wire insertion tool supplied as shown below, open the clamp contact in the connector shell by pressing All other Intellivox connections are made via the four on- inwards towards the shell. board WAGO Type 231 multi-pin connectors.
  • Page 11: Audio Inputs

    JBL Intellivox Installation Manual AUDIO INPUTS The Intellivox is normally supplied with two transform- If the source equipment has a well-designed balanced er-balanced line inputs. Selection of Input 1 or Input 2 as output and the wiring strategy shown below is used, there audio source is made from the WinControl software should be no problems with hum or other extraneous noise.
  • Page 12: Network Connection

    JBL Intellivox Installation Manual NETWORK CONNECTION CAT-5 type UTP or FTP cable is NOT suitable. Please refer to the Appendix section of this manual for cable specifica- The RS-485 network connection should be permanently tions. wired in any of the following situations: •...
  • Page 13: Fault Monitoring/Fan Control Connector

    JBL Intellivox Installation Manual FAULT MONITORING/FAN CONTROL CONNECTOR Fault Monitoring The Intellivox includes a single-pole changeover relay The pinout of this connector is as follows: whose contacts are accessible on the Failure Relay connector. The conditions under which the relay operates are defined as part of the device configuration in WinControl.
  • Page 14 JBL Intellivox Installation Manual Fan Control Please note that the FAN- signal is a PWM (Pulse Width Modulated) signal. This control An external cooling fan should be installed if the ambient results in a temperature dependent fan speed. temperature is expected to exceed 40 °C and/or the It implies that this signal cannot be used to directly drive Intellivox will be exposed to direct sunlight.
  • Page 15: External Ambient Spl/Temperature Sensor

    JBL Intellivox Installation Manual EXTERNAL AMBIENT SPL/TEMPERATURE SENSOR External Ambient SPL Sensor The pinout of this connector is as follows: The Intellivox incorporates an autogain algorithm which intelligently alters the volume of the audio according to the ambient noise level. An internal microphone is fitted to monitor the ambient noise level in the gaps in programme material.
  • Page 16: Mechanical Installation

    JBL Intellivox Installation Manual MECHANICAL INSTALLATION Acoustic Centre Mounting an Intellivox loudspeaker is a straightforward procedure, but it is essential to understand that the height of the unit above floor level is extremely critical. The “correct operational height” is defined as part of the acoustical design process and the installer should make sure that he/she has this information before commencing to mount the Intellivox.
  • Page 17: Mounting Options

    JBL Intellivox Installation Manual Mounting Options the rear of the enclosure by the four M5 pan head screws instead of the standard brackets. Two versions of swivel The Intellivox has two or three (depending on the model) bracket are available, permitting the Intellivox to be rotated attachment points at the rear of the enclosure;...
  • Page 18: Mounting Procedure

    JBL Intellivox Installation Manual Mounting Procedure The general mounting procedure using the standard the Intellivox enclosure with the M5 x 12 pan-head brackets is described below. It is assumed that all neces- screws and shakeproof washers supplied. The 10 mm sary cabling is already prepared with connectors fitted dia.
  • Page 19: Unit Checks

    JBL Intellivox Installation Manual 4.UNIT CHECKS After installation and connection are complete, the install- CONNECTING THE PC TO THE INTELLIVOX er should upload the settings file into the Intellivox and If connecting directly to the Intellivox, use the 5-pin XLR verify correct operation with WinControl software.
  • Page 20: Settings File Upload

    JBL Intellivox Installation Manual SETTINGS FILE UPLOAD • Apply mains power to the Intellivox, turn on the PC and Click File > Load settings…, which will open the two launch WinControl. Open Options > Communica- dialogue boxes shown below, Load control parameters tions options, and confirm that the Off-line box is settings Control parameters...
  • Page 21 JBL Intellivox Installation Manual • The File Name field (at the top of the • Select the correct settings file and click Open. Then in Load control pa- dialogue box) indicates the last-used dialogue box, rameters settings Load control parameters settings settings file name.
  • Page 22: Appendix

    JBL Intellivox Installation Manual 5. APPENDIX OPTIONAL ACCESSORIES Listed below are a number of additional components which may be required for an individual installation. Mating connectors and components for external wiring: CONNECTOR DESCRIPTION ORDER SKU Mains power IEC socket 6A 17824103 Audio Input WAGO 6-pin female...
  • Page 23 JBL Intellivox Installation Manual Available input modules: DESCRIPTION ORDER SKU 1 x Line Level and 1 x 70V/100V IVX-381001 Dual 70V/100V with DC blocking IVX-381005 Network accessories: DESCRIPTION ORDER SKU Program Set (inc. WinControl CD, USB interface, cable) DUR386612 202007/IvxIM_v2.3...
  • Page 24: Common Analogue Grounding Issues

    JBL Intellivox Installation Manual COMMON ANALOGUE GROUNDING ISSUES SOFTWARE AND FIRMWARE UPDATES Correctly connecting the Intellivox to ground has several The WinControl application is freely available and can be benefits: downloaded from our website; http://www.jblpro.com. We advise installers, users and engineers to check our 1.
  • Page 25: Failure Monitoring On 70 V/100 Vconnection

    JBL Intellivox Installation Manual FAILURE MONITORING ON 70 V/100 V Configuring PCB960 CONNECTION. The impedance between pin 1 and 2 of the audio input If the Intellivox is equipped with an input module that connector has two states: supports direct interfacing to a 70 V/100 V signal, a sim- •...
  • Page 26: Configuring Pcb124

    JBL Intellivox Installation Manual Configuring PCB124 The impedance between pin 1 and 2 of the audio input connector has two states: • High impedance (approximately 140 kOhm @ DC). • Low impedance (approximately 2.2 kOhm @ DC). The states are switched by a separate change-over contact of the Intellivox’s internal Failure Relay.
  • Page 27: Failure Relay Configuration

    JBL Intellivox Installation Manual FAILURE RELAY CONFIGURATION NOTE: Relay shown in INTERNAL RELAY energised state - i.e., ‘no fault’. Intellivox units equipped with input board PCB124 (see fig.17) support configuration of the internal Failure Relay for either volt-free or impedance-sensing (10k / 20k Ω) operation.
  • Page 28 JBL Professional 8500 Balboa Boulevard Northridge, CA 91329 U.S.A. © Copyright 2020 JBL Professional www.jblpro.com...
