Model No. WCTL34308.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
1-888-936-4266
CALL TOLL-FREE:
Mon.–Fri., 8:00 until 17:00 EST
(excluding holidays)
OR E-MAIL US:
customerservice@iconcanada.ca
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
All manuals and user guides at all-guides.com
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Weslo WCTL34308.0
Summary of Contents for Weslo WCTL34308.0
- Page 1 All manuals and user guides at all-guides.com Model No. WCTL34308.0 USER'S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you...
-
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decals may not be shown at actual size. WESLO is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
All manuals and user guides at all-guides.com IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and in- structions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product. - Page 4 All manuals and user guides at all-guides.com 18. The treadmill is capable of high speeds. 23. When folding or moving the treadmill, make Adjust the speed in small increments to sure that the storage latch is holding the avoid sudden jumps in speed. frame securely in the storage position.
-
Page 5: Before You Begin
BEFORE YOU BEGIN All manuals and user guides at all-guides.com Thank you for selecting the WESLO CADENCE J 3.8 ing this manual, please see the front cover of this man- ® treadmill. The CADENCE J 3.8 treadmill combines ad- ual. To help us assist you, note the product model vanced technology with innovative design to let you number and serial number before contacting us. -
Page 6: Assembly
All manuals and user guides at all-guides.com ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. - Page 7 All manuals and user guides at all-guides.com 2. Have a second person hold the Base (52) in the position shown. Identify the Left Upright (53) (the Right Upright [54] has a large hole near the lower end). Hold the Left Upright (53) so the two small holes for the latch assembly are on top as shown.
- Page 8 All manuals and user guides at all-guides.com 5. See the left inset drawing. Identify the two Frame Spacers (11). Open the included packet of grease, and apply grease to both sides of both Frame Spacers. Then, identify the outer side of each Frame Spacer.
- Page 9 All manuals and user guides at all-guides.com 7. Set the Console (91) face-down on a soft sur- face to avoid scratching the Console. Hold the Console Wire Right Handrail (33), which has a large hole in the location shown, near the Console. Bracket Next, insert the console wire and tie into the hole in the side of the Right Handrail (33).
- Page 10 All manuals and user guides at all-guides.com 9. Attach the Console (91) to the Right Upright (54) and the Left Upright (53) with six Handrail Bolts (8) and six Handrail Star Washers (5). Make sure that no wires are pinched. Start all six Handrail Bolts before tightening any of them.
- Page 11 All manuals and user guides at all-guides.com 12. Attach the Latch Housing (48) to the Left Upright (53) with two Latch Screws (10); start both Latch Screws before tightening them. Make sure that the large hole in the Latch Housing is on the indicated side. Remove the knob from the pin.
-
Page 12: Operation And Adjustment
All manuals and user guides at all-guides.com OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT plug. Plug the power cord into a surge suppressor, and plug the surge suppressor into an appropriate outlet that is properly installed and grounded in Your treadmill features a walking belt coated with high- performance lubricant. -
Page 13: Console Diagram
All manuals and user guides at all-guides.com CONSOLE DIAGRAM Pulse Sensor Clip FEATURES OF THE CONSOLE HOW TO TURN ON THE POWER IMPORTANT: If the treadmill has been exposed to The treadmill console offers a selection of features cold temperatures, allow it to warm to room tem- designed to make your workouts more effective. -
Page 14: How To Use The Manual Mode
All manuals and user guides at all-guides.com Follow your progress with the track and the HOW TO USE THE MANUAL MODE displays. The track—The track Insert the key into the console. represents a distance of 1/4 mile (400 meters). See HOW TO TURN ON THE POWER on page As you walk or run on the treadmill, the indica- tors around the track will... - Page 15 All manuals and user guides at all-guides.com be shown. For the most accurate heart rate The console can dis- reading, hold your thumb on the pulse sensor play speed and dis- for at least 15 seconds. tance in either miles or kilometers.
- Page 16 All manuals and user guides at all-guides.com one of the displays to alert you, and then the HOW TO USE A SPEED PROGRAM speed of the walking belt will change. The pro- gram will continue until all 30 periods are com- Insert the key into the console.
-
Page 17: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL All manuals and user guides at all-guides.com HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If you do not do this, you may damage the treadmill when you fold it. - Page 18 All manuals and user guides at all-guides.com HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Next, lower the frame until it is past the latch pin.
-
Page 19: Troubleshooting
All manuals and user guides at all-guides.com TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a. - Page 20 All manuals and user guides at all-guides.com PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 12. b. If the walking belt is overtightened, treadmill perfor- 2–3 in.
-
Page 21: Exercise Guidelines
All manuals and user guides at all-guides.com EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning any time. During the first few minutes of exercise, your exercise program, consult your physician. -
Page 22: Part List
PART LIST—Model No. WCTL34308.0 All manuals and user guides at all-guides.com R0608A To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description Colored Patch Frame Bolt... - Page 23 All manuals and user guides at all-guides.com Key No. Qty. Description Key No. Qty. Description Incline Motor Nut, Lower Jam Nut Belt Guide Controller Screw 5 mm Hex Key – 8" Black Wire, M/F Frame Endcap – 4" Black Wire, M/F Releasable Tie –...
-
Page 24: Exploded Drawing
EXPLODED DRAWING A—Model No. WCTL34308.0 All manuals and user guides at all-guides.com R0608A... - Page 25 EXPLODED DRAWING B—Model No. WCTL34308.0 All manuals and user guides at all-guides.com R0608A...
- Page 26 EXPLODED DRAWING C—Model No. WCTL34308.0 All manuals and user guides at all-guides.com R0608A...
- Page 27 EXPLODED DRAWING D—Model No. WCTL34308.0 All manuals and user guides at all-guides.com R0608A...
-
Page 28: Ordering Replacement Parts
All manuals and user guides at all-guides.com ORDERING REPLACEMENT PARTS To order replacement parts, see the front cover of this manual. To help us assist you, please be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
